Yaomatec M23 Right Angle Panel Mount Signal Connector Receptacle

Secure your control signals with Yaomatec’s M23 right-angle panel-mount connector. IP65, 7-pin, solder-free. Shop wholesale at NEOTECH UAE!

Overview

The Yaomatec M23 Right-Angle Panel-Mount Signal Receptacle delivers reliable, space-saving connections for sensors, actuators, and fieldbus devices. Its right-angle design and IP65 sealing ensure durable signal integrity in tight enclosures and harsh environments.

Product Description

This M23-series female receptacle features 7 gold-plated crimp contacts in a rugged zinc-diecast body. The 90° exit profile minimizes cable stress and maximizes panel space. A built-in EPDM gasket and metal coupling nut deliver IP65 protection against dust and splashes. Ideal for factory automation, robotics, and machine-tool interfaces, it mates with standard M23 male plugs—no soldering required.

Key Features

• M23 right-angle, 7-pin female receptacle

• Gold-plated crimp contacts for low-loss signals

• Zinc-diecast housing with corrosion-resistant plating

• Integrated EPDM gasket for IP65 panel sealing

• Locking coupling nut prevents vibration loosening

• 90° cable exit saves panel depth

• Wide temp range: –40 °C to +85 °C

• UL94 V-0, CE, and RoHS compliant

Specifications

• Series: M23 (IEC 61076-2-101)

• Contacts: 7 gold-plated, crimp-style

• Impedance: Signal/logic level

• Housing: Zinc-diecast with nickel finish

• Sealing: IP65 mated (panel side)

• Temperature Range: –40 °C to +85 °C

• Voltage Rating: 250 VAC/DC

• Current Rating: 4 A per contact

• Mounting: Panel cut-out Ø23 mm, secured with nut

• Cable Exit: 90° downward

Supported Applications / Industries

• Industrial automation PLC I/O

• Robotics and motion control

• Packaging and assembly lines

• Conveyor and material-handling systems

• Test & measurement equipment

• Renewable-energy inverters

Benefits & Compatibility

• Space-saving design in crowded control cabinets

• Rugged sealing keeps out dust & moisture

• Quick assembly with crimp contacts—no solder needed

• Standard M23 interface works with NEOTECH cables & sensors

• Vibration-resistant coupling ensures uninterrupted signals

Purpose of Use

Use this receptacle to:

• Connect field-bus and I/O cables in tight panels

• Interface sensors, encoders, and actuators

• Simplify machine rebuilds with modular connectors

• Maintain uptime in wash-down or dusty areas

How to Use

1. Crimp wires to gold-plated contacts using an M23 crimp tool

2. Insert contacts into the receptacle until they lock

3. Mount receptacle through panel cut-out and tighten nut with gasket

4. Mate with M23 male plug and hand-tighten coupling nut

5. Verify IP65 seal and signal continuity

Packaging / Weight / Dimensions

• Includes: M23 receptacle, EPDM gasket, mounting nut, quick-start guide

• Body Size: 35 × 23 × 18 mm (L×W×H)

• Panel Cut-out: Ø23 mm

• Weight: 25 g each

• Packaging: Bulk blister pack
