Track assets reliably with BYX ISO15693 disc RFID tags. Weather-proof, long-range reads, re-programmable. Order now across the UAE!
Overview
The BYX ISO15693 Disc RFID Tag is a compact, durable credential for asset tracking and inventory management. Its slim disc shape fits onto metal, plastic, or textile surfaces. Rated for harsh environments, it delivers reliable reads up to 10 cm with any ISO15693-compatible reader.
Product Description
Engineered for industry, this disc tag embeds a 13.56 MHz chip in a rugged, epoxy-sealed housing. It resists water, dust, and chemicals (IP68). The wide read range speeds batch scans on forklifts, conveyors, or handheld readers. You can encode up to 256 bytes of custom data for serial numbers, maintenance logs, or location info. Deploy BYX discs on equipment, tools, pallets, or reusable containers to gain real-time visibility.
Key Features
-
ISO15693 (EPC V2) compliant, 13.56 MHz frequency
-
Up to 10 cm read range for hands-free scanning
-
256 bytes user memory for custom data fields
-
IP68-rated housing: waterproof, dustproof, chemical-resistant
-
Wide temperature tolerance: –40 °C to +85 °C
-
Epoxy-sealed epoxy module withstands impact and vibration
-
Reprogrammable thousands of cycles via NFC writer
-
Compact Ø 25 mm disc fits space-constrained assets
-
Low-profile design reduces snag and damage risk
-
Works with NEOTECH Mobile RFID Reader K30 and Fixed RFID Portals
Specifications
| Parameter |
Details |
| Chip Type |
NXP ICODE SLIX2 (ISO15693) |
| Frequency |
13.56 MHz |
| Memory |
256 bytes user-configurable |
| Read Range |
Up to 100 mm (reader-dependent) |
| Dimensions |
Ø 25 mm × 3 mm thickness |
| Material |
Epoxy-sealed ABS housing |
| Ingress Protection |
IP68 (1 m/30 min submersion) |
| Temp. Range |
−40 °C to +85 °C |
| Endurance |
≥ 100 000 write cycles |
| Compliance |
RoHS, CE, FCC |
Supported OS / Application / Industries
Platforms: Integrates with Windows, Linux, macOS via NEOTECH RFID middleware.
Applications: Asset tracking, tool control, automated inventory audits, returnable container management.
Industries: Manufacturing, logistics, oil & gas, pharmaceuticals, rental services.
Benefits & Compatibility
-
Hands-free batch scanning boosts throughput on forklifts or conveyors.
-
Rugged IP68 housing ensures uptime in wet, dusty, or chemical-rich sites.
-
Wide temp. tolerance suits freezer, oven, or outdoor yard use.
-
High memory capacity stores maintenance dates, serials, or location codes.
-
Reprogrammable for asset lifecycle updates.
-
Seamless integration with NEOTECH Centralized Asset Platform and Fixed RFID Readers.
Purpose of Use
Attach BYX discs to equipment, bins, pallets, or reusable containers. Use them to automate check-in/out, track maintenance cycles, and prevent loss. Ideal wherever rugged, space-saving tags are needed.
How to Use
-
Encode asset data via NEOTECH’s NFC writer or handheld reader.
-
Adhere disc to a clean, flat surface using industrial adhesive.
-
Scan with a fixed portal or handheld reader from up to 10 cm away.
-
Update tag memory on maintenance or relocation.
-
Monitor asset status in the NEOTECH software dashboard.
Packaging / Weight / Dimensions
-
Packaging: Bulk packs of 50, 100, or 500 tags in sealed foil bags.
-
Included: Tags, adhesive pads, quick-start guide.
-
Disc Size: Ø 25 mm × 3 mm.
-
Weight: ~2 g per tag.
Warranty & FAQs
Warranty: 1-year limited against manufacturing defects.
FAQs:
-
Q: Can it survive autoclave cycles?
A: Rated to +85 °C; check cycle specifics.
-
Q: Will metal surfaces affect reads?
A: Designed for direct metal mount with consistent read performance.
-
Q: How do I reprogram?
A: Use NEOTECH NFC writer station or K30 handheld reader.
-
Q: Is custom branding available?
A: Yes—laser etching or color printing on request.
Performance, Quality, Durability & Reliability
Tested for 100 000+ reads/writes and extreme climate cycles. The epoxy seal protects against impact, vibration, moisture, and chemicals. Ensures reliable operation in mission-critical deployments.
Best Price Guarantee
NEOTECH matches or beats any qualified UAE quote on BYX RFID disc tags. Maximize ROI with our price-beat promise.
Shop Today & Receive Your Delivery Across the UAE
Order BYX ISO15693 disc RFID tags now for rapid dispatch from our UAE warehouse. Bulk and custom orders get priority handling.
Request for Customer Reviews and Testimonials
Using these tags in your operation? Share a testimonial to help peers choose wisely and guide NEOTECH product improvements.
After Sales Support
Our support team is on call via email, phone, or live chat for tag programming, troubleshooting, and integration guidance post-purchase.
Get in Touch
Need custom encoding, site survey, or volume quotes? Contact NEOTECH RFID specialists for expert, rapid assistance.
Stock Availability
✔ In Stock – Ready to ship from UAE warehouse
⏳ Limited custom-print batches; confirm lead times for large orders.
Disclaimer
Specifications subject to change without notice. Images are illustrative. Confirm final specs, branding options, and pricing with NEOTECH sales before ordering.
