BYX Smart UHF Access Reader

BYX UHF RFID access reader for fast, long-range entry. Ideal for gates, parking, and vehicle ID. Durable and secure. Order today from NEOTECH UAE.

Overview

The BYX Smart UHF Access Reader is a long-range RFID reader designed for secure vehicle and personnel access control.
Built with high-performance UHF technology, it reads RFID tags from up to 10 meters, making it perfect for parking gates, logistics depots, warehouses, and secured facilities.

Product Description

This UHF access reader supports EPC Gen2 (ISO18000-6C) tags and features fast processing, anti-collision algorithms, and weather-resistant casing.
Whether installed at an entry boom barrier, loading dock, or automated parking area, the BYX reader delivers instant, contactless access verification via RFID windshield tags or cards.

Key Features

• Long-range RFID reading (up to 10m)

• Supports EPC Gen2 / ISO18000-6C standard

• Anti-collision algorithm for multiple tag reading

• Wiegand 26/34 output for access control systems

• RS232 / RS485 / TCP/IP interfaces available

• IP66-rated weatherproof enclosure

• Triggered or continuous read modes

Specifications

• Operating Frequency: 860–960 MHz (global UHF)

• Protocol: EPC Gen2 / ISO18000-6C

• Read Range: Up to 10 meters (depending on tag and environment)

• Interfaces:

  • Wiegand 26/34

  • RS232 / RS485

  • TCP/IP (optional)

  • Trigger input (for controlled reads)

• Power Supply: 9V–24V DC

• Power Consumption: <5W

• Enclosure Rating: IP66 (outdoor-ready)

• Operating Temp: -20°C to +65°C

• Dimensions: ~260 × 260 × 65 mm

• Mounting: Pole, wall, or gate frame

Supported OS / Application / Industries

• Compatible Systems:

  • ZKTeco, Hikvision, Suprema, Paxton, BYX controllers

• Applications:

  • Vehicle gate entry

  • Parking lot automation

  • Warehouse access

  • Staff ID zone control

  • Toll booth management

• Industries:

  • Transportation

  • Logistics

  • Education

  • Government

  • Corporate security

Benefits & Compatibility

• Enables contactless, automatic access with RFID tags

• Works seamlessly with boom gates, door controllers, and parking systems

• Handles multiple tags simultaneously (anti-collision)

• Compatible with most UHF RFID windshield tags, cards, and keyfobs

• Easy integration into existing Wiegand-based access setups

Purpose of Use

Designed for environments requiring hands-free, long-range RFID authentication, such as vehicle entry gates, secure compounds, or large facility entry control.

How to Use

1. Mount reader at gate/barrier/door

2. Connect to access controller via Wiegand or serial port

3. Power on the unit and configure tag filters (if needed)

4. Use RFID tag or card – reader will auto-authenticate and trigger access

Packaging / Weight / Dimensions

• Dimensions: 260 × 260 × 65 mm

• Weight: ~1.2 kg

• Package Includes:

  • BYX UHF Access Reader

  • Power supply (optional)

  • Mounting brackets

  • Setup guide

Warranty & FAQs

• Warranty: 1-year NEOTECH hardware warranty

• FAQs:

  • Is it waterproof? – Yes, rated IP66 for outdoor use

  • Can it read multiple tags at once? – Yes, via anti-collision tech

  • Does it need a controller? – Yes, connects to an access control panel via Wiegand or RS232

Performance, Quality, Durability & Reliability

Engineered for outdoor, 24/7 operation, the BYX access reader uses industrial-grade electronics for consistent scanning in extreme weather, dusty environments, and high-traffic access points.

Best Price Guarantee

NEOTECH offers UAE’s most competitive pricing for smart UHF access readers — discounts for resellers, integrators, and volume buyers.

Shop Today & Receive Your Delivery Across the UAE

We ship fast to Dubai, Abu Dhabi, Sharjah, Ajman, and all Emirates.
International orders supported with customs clearance.

Request for Customer Reviews and Testimonials

Installed this at your gate or site? Drop a review and share your results. We’d love to feature your success story!

After Sales Support

NEOTECH provides:

• Wiring diagrams

• Integration support

• Remote technical assistance

• On-site setup (for enterprise clients)

Get in Touch

For system planning, reader-tag compatibility checks, or to schedule a demo, reach out to NEOTECH’s RFID solutions team today.

Stock Availability

✅ In stock – ships in 24–48 hours
📦 Bulk quantities available for contractors and system integrators

Disclaimer

Tag read performance depends on installation angle, tag type, and surrounding materials. Use proper mounting for best results.
