Secure entry with GL-AC04 IP66 Touch Access Reader—Tuya/TTLock app, Wi-Fi & BLE, rugged build. Order now for rock-solid control!
Overview
Granding GL-AC04 is an IP66-rated touch-key access controller. It pairs BLE and 2.4 GHz Wi-Fi to the Tuya and TTLock apps. Manage PINs and virtual keys in real time. Its hardened glass and metal housing endure rain, dust, and sun.
Product Description
This sleek reader uses a capacitive touch keypad with anti-peep scramble. It connects over BLE or Wi-Fi for remote setup and log monitoring. Relay output drives any electric lock. PoE or 12 V DC power keeps wiring neat. GL-AC04 blends enterprise reliability with plug-and-play ease.
Key Features
-
IP66 Weatherproof: Dust-tight, heavy-rain proof
-
Hybrid Connectivity: Bluetooth 4.2 & Wi-Fi 802.11 b/g/n (2.4 GHz)
-
App Integration: Tuya Smart & TTLock for remote PIN/token management
-
High Capacity: 1 000 PIN codes & 1 000 BLE tokens
-
Relay Output: 3 A @ 30 V DC for locks or alarms
-
Power Options: PoE (802.3af) or 12 V DC input
-
Anti-Peep Keypad: Randomized PIN scramble for extra security
-
Auto-Lock Delay: Configurable via app or keypad
Specifications
| Parameter |
Details |
| Keypad |
Capacitive, backlit, glass panel |
| Connectivity |
BLE 4.2; Wi-Fi IEEE 802.11 b/g/n |
| User Capacity |
1 000 PINs; 1 000 BLE tokens |
| Relay Output |
3 A @ 30 V DC |
| Power |
PoE (802.3af) or 12 V DC |
| Operating Temp. |
–20 °C to +60 °C |
| Ingress Protection |
IP66 |
| Dimensions |
120 × 60 × 20 mm |
| Weight |
180 g |
Supported OS / Application / Industries
-
Apps: Tuya Smart, Smart Life, TTLock (iOS/Android)
-
Integrations: MQTT, Home Assistant via Tuya bridge
-
Use Cases: Office entry, villa gates, apartment lobbies
-
Industries: Corporate, residential, hospitality, education
Benefits & Compatibility
Purpose of Use
Deploy GL-AC04 to secure high-traffic doors. Issue PINs or BLE tokens to staff and visitors. Track every entry and exit in your cloud dashboard for compliance.
How to Use
-
Mount the unit using the supplied bracket.
-
Power via PoE injector or 12 V DC adapter.
-
Pair in the Tuya/TTLock app by scanning QR code.
-
Enroll PINs or BLE tokens in the app or on the keypad.
-
Configure auto-lock delay and relay behavior.
Packaging / Weight / Dimensions
-
Includes: GL-AC04 reader, mounting bracket, screws, quick-start guide
-
Package Size: 140 × 90 × 30 mm
-
Gross Weight: 300 g
Warranty & FAQs
Warranty: 2-year coverage on electronics and housing
FAQs:
-
Offline use? → PIN entry works without network.
-
External reader support? → Wiegand IN/OUT available.
-
BLE security? → AES-128 encryption ensures data safety.
-
Alarm integration? → Relay can trigger sirens or strobes.
Performance, Quality, Durability & Reliability
Built with industrial-grade PCB and scratch-resistant glass. Tested to IP66, –20 °C/+60 °C extremes, and 10 000 keypad cycles. PoE port meets IEEE 802.3af standards.
Best Price Guarantee
NEOTECH offers the lowest UAE price on GL-AC04 controllers. Ask us about volume and system-integration discounts.
Shop Today & Receive Your Delivery Across the UAE
Order by 4 PM for same-day dispatch to Dubai, Abu Dhabi, Sharjah, and all Emirates. Express B2B shipping available.
Request for Customer Reviews and Testimonials
Installed GL-AC04 at your site? Share your review to guide peers toward smarter, safer access control!
After Sales Support
From setup to troubleshooting, our tech team is on call via email, phone or live chat. We’ve got your back post-purchase.
Get in Touch
Need advice on Kyocera toner? Contact our print experts for personalized recommendations and fast replies.
Stock Availability
Stocks update daily. For urgent orders, confirm availability before checkout. Bulk requests may need 10–15 business days.
Disclaimer
All details are for general info and may change without notice. Images are illustrative. Verify specs and pricing with our sales team before ordering.
