Secure entry with the Granding QR300 QR Code Access Reader featuring Wiegand 26/34 support. Easy install, multi-format scans, robust design. Buy now UAE!
Overview
The Granding QR300 is a next-gen QR code access control reader. It supports Wiegand 26/34 outputs for seamless integration with most door controllers. Built for durability and speed, it streamlines authentication at high-traffic entrances.
Product Description
QR300 combines a high-resolution imager with powerful firmware to decode QR codes, barcodes, and NFC badges. Its dual-mode Wiegand interface (26-bit and 34-bit) lets you connect to legacy or modern access panels. The IP65-rated housing and tamper alarms ensure reliable, secure operations indoors or outdoors.
Key Features
-
Fast QR, 1D barcode & NFC badge reads
-
Configurable Wiegand 26-bit & 34-bit output
-
IP65 weatherproof and vandal-resistant
-
Built-in tamper and door-sense inputs
-
LED & buzzer for status feedback
-
12 VDC power or PoE support
-
Anti-climb design with stainless steel trim
-
Firmware upgradable via microUSB
-
Multi-protocol support: ASCII, TTL, Wiegand
Specifications
-
Reader Type: 2D imaging engine
-
Read Formats: QR Code, EAN-13/8, Code128, NFC (optional)
-
Output Modes: Wiegand 26, Wiegand 34, TTL
-
Power: 12 VDC @ 300 mA or PoE (802.3af)
-
Enclosure: IK08 vandal resistant, IP65 ingress rated
-
Temp Range: −20 °C to 60 °C
-
Dimensions: 120 × 68 × 18 mm
-
Weight: 200 g
-
Mounting: Surface or flush (with backbox)
Supported OS / Application / Industries
Integration Platforms: Works with Windows, Linux, and embedded access controllers.
Applications: Corporate offices, residential gates, parking barriers, gym access.
Industries: Security, Real Estate, Hospitality, Education, Healthcare.
Benefits & Compatibility
-
Seamless Integration: Works with legacy Wiegand panels and cloud-based control systems.
-
High Throughput: Reads codes in under 200 ms.
-
Durable Design: IP65 and IK08 for harsh environments.
-
Flexible Deployment: Power via 12 VDC or PoE.
-
Scalable: Link multiple QR300 units to a centralized NEOTECH Access Manager.
Purpose of Use
Use the QR300 to grant or deny entry via QR codes, printed badges, or mobile passes. Ideal for secure lobbies, parking gates, turnstiles, and time-attendance stations.
How to Use
-
Mount the reader at 1.2 m height near your access point.
-
Connect 12 VDC or PoE and data cables to your controller.
-
Configure Wiegand mode, code formats, and LED behavior via the web UI.
-
Enroll codes or integrate with your credential database.
-
Test reads and door actions; adjust tilt and illumination as needed.
Packaging / Weight / Dimensions
-
Packaging: Protective carton with foam inserts
-
Included: QR300 reader, mounting screws, backbox template, quick-start guide
-
Dimensions: 120 × 68 × 18 mm
-
Weight: 200 g
Warranty & FAQs
Warranty: 1-year limited hardware warranty; extended plans available.
FAQs:
-
Q: Can it decode damaged QR codes?
A: Yes, advanced imaging handles low-contrast and partial codes.
-
Q: Is NFC standard?
A: NFC read is optional; select model with NFC module.
-
Q: How do I switch Wiegand mode?
A: Use the onboard DIP switches or web UI.
-
Q: Can I use PoE?
A: Yes—supports IEEE 802.3af PoE.
Performance, Quality, Durability & Reliability
Tested for 1 million cycles and rated IK08 for impact. The IP65 seal protects against dust and moisture. Anti-tamper sensors trigger alarms if housing is breached.
Best Price Guarantee
NEOTECH offers the most competitive pricing in the UAE. Find a lower qualified quote on the QR300? We’ll match or beat it to keep your rollout cost-effective.
Shop Today & Receive Your Delivery Across the UAE
Order the Granding QR300 now for fast dispatch from our UAE warehouse. Bulk and turnkey integration packages available with priority logistics.
Request for Customer Reviews and Testimonials
Deployed the QR300 in your facility? Share your review to help peers and improve NEOTECH’s solutions.
After Sales Support
From installation to firmware updates, NEOTECH’s support team is available via email, phone, or live chat to ensure uptime.
Get in Touch
Need configuration help or a site survey? Contact NEOTECH access control specialists for expert guidance and rapid quotes.
Stock Availability
✔ In Stock – Ready to ship from UAE warehouse
⏳ Limited quantities; confirm availability for large deployments before ordering.
Disclaimer
Specifications subject to change without notice. Images are illustrative. Confirm final specs and pricing with NEOTECH sales before purchase.
