Granding BG1000 Series of barrier gate

Secure vehicle access with Granding BG1000 barrier gate. Durable, fast-operating, weatherproof. Order now from NEOTECH UAE!

Overview

The Granding BG1000 Series barrier gate delivers high-speed, reliable vehicle control for parking, toll plazas, and secured facilities. Its robust construction, smooth motor drive, and intelligent diagnostics make it ideal for 24/7 operation in any environment.

Product Description

Built with a die-cast aluminum boom and IP54-rated housing, the BG1000 combines strength and weather resistance. Its quiet DC motor propels the boom arm in under 3 seconds, while integrated loop detectors and limit switches ensure safe, precise operation. Advanced control logic handles peak traffic without downtime.

Key Features

• Rapid open/close cycle (≤3 s)

• Durable aluminum alloy boom (up to 6 m length)

• Weatherproof IP54 control box

• Built-in loop detector and photoelectric sensors

• DC brushless motor with soft-start/stop

• LED status indicator on cabinet

• Multiple boom arm types: straight, articulated, folding

• Emergency manual release

• Compatible with RFID readers, ticket dispensers, and keypad modules

Specifications

• Model: BG1000-4 (4 m), BG1000-6 (6 m)

• Boom Speed: 1.6 – 3 s (configurable)

• Motor: 24 V DC, brushless, 60 W

• Power Input: AC 220 V ± 10%, 50/60 Hz

• Duty Cycle: 100% (continuous operation)

• Operating Temp: -35 °C to +75 °C

• Housing Protection: IP54

• Control Interface: RS485, dry-contact I/O

• Dimensions: 1,020 × 310 × 310 mm (cabinet)

• Weight: 45 kg (BG1000-4), 48 kg (BG1000-6)

Supported Applications / Industries

• Parking lots & garages

• Toll booths & checkpoints

• Gated communities

• Industrial facilities

• Logistics hubs

• Government & military sites

Benefits & Compatibility

• High throughput reduces queue times

• Corrosion-resistant for coastal and harsh climates

• Integrates with NEOTECH RFID readers, ANPR cameras, and ticketing systems

• Modular boom arms fit any entry width

• Remote monitoring and diagnostics via network

Purpose of Use

Use the BG1000 Series to:

• Automate vehicle entry and exit

• Enforce controlled access in paid parking

• Enhance security at restricted zones

• Streamline traffic flow at facilities

How to Use

1. Mount barrier at entry point on a flat concrete pad

2. Wire power, loop detectors, and I/O to control panel

3. Program opening time and sensor logic in control module

4. Connect external devices (RFID reader, keypad, camera)

5. Test cycle and safety stops, then set live operation

Packaging / Weight / Dimensions

• Includes: Barrier unit, boom arm, loop detector kit, mounting hardware, manual

• Cabinet Size: 1,020 × 310 × 310 mm

• Boxed Weight: ~55 kg

• Shipping Carton: Reinforced plywood crate

After Sales Support

From installation guidance to remote troubleshooting, our technical team is available by email, phone, or live chat. We ensure uptime with firmware updates and on-site service options.

Get in Touch

For system design or pricing, contact our access control specialists for tailored solutions and fast quotes.

Stock Availability

Inventory updated daily. For large projects or urgent delivery, please confirm stock levels before ordering. Lead time for bulk orders: 10–15 business days.

Disclaimer

All specifications are for general reference and may change without notice. Product images are illustrative. Confirm final details and pricing with our sales team before purchase.
