Rugged Bixolon XM7-40R 4″ RFID & thermal-transfer label printer with 4.3″ touchscreen, 203/300 dpi, 10 ips. Order today at NEOTECH UAE!
Overview
The Bixolon XM7-40R combines robust industrial design with built-in UHF RFID encoding and dual-mode thermal printing. Its 4.3″ color touchscreen and intuitive menu cut setup time, while a durable metal frame stands up to dust, shocks and high-volume workflows. Print sharp barcodes, text and RFID tags at up to 10 ips—ideal for asset tracking, compliance labels and warehouse operations.
Product Description
Engineered for nonstop operation, the XM7-40R supports both direct thermal and thermal-transfer media up to 104 mm (4") wide. Tool-free, drop-in ribbon and label loading slashes downtime; 512 MB SDRAM and 512 MB flash memory power large batch jobs and complex RFID encoding without lag. Standard USB, Serial and Gigabit Ethernet handle wired connections; optional Wi-Fi and Bluetooth modules enable mobile printing. With Printer Twin™ technology, you can clone profiles across your fleet in seconds—keeping everyone on the same page.
Key Features
-
UHF RFID Print & Encode: Auto-calibrates RFID inlays for precise, low-waste tag production
-
Dual-Mode Printing: Thermal transfer & direct thermal for versatile media support
-
4.3″ Color Touchscreen: Full-color previews and simple menu navigation
-
High Throughput: Up to 10 ips (254 mm/sec) at 203 dpi; switch to 300 dpi for fine detail
-
Rugged Metal Chassis: Built to withstand dust, vibration and drops
-
Universal Connectivity: USB, Serial, Gigabit Ethernet; optional Wi-Fi & Bluetooth
-
Printer Twin™: Instant profile cloning across multiple printers
-
Tool-Free Maintenance: Quick-swap platen roller and printhead
Specifications
| Attribute |
Details |
| Print Method |
Thermal-Transfer & Direct Thermal |
| Max Print Width |
104 mm (4″) |
| Max Print Length |
4 000 mm |
| Resolution |
203 dpi (standard), 300 dpi (optional) |
| Speed |
Up to 10 ips (254 mm/sec) |
| Memory |
512 MB SDRAM, 512 MB Flash |
| Media Roll Ø |
≤ 203 mm |
| Core Ø |
38.1–76.2 mm |
| Display |
4.3″ full-color touchscreen TFT |
| Power |
100–240 V AC adapter |
| Dimensions (W×D×H) |
269 × 490 × 324 mm |
| Weight |
14.2 kg |
| RFID Frequency |
UHF 865–868 MHz (EU), 902–928 MHz (US) |
Supported OS / Applications / Industries
-
OS: Windows, macOS, Linux (CUPS)
-
Software: BPL-Z™, BPL-E™, SLCS™, BarTender® UltraLite
-
Use Cases: Asset tagging, pallet IDs, laboratory labeling, RFID encoding
-
Industries: Logistics, manufacturing, healthcare, retail, government
Benefits & Compatibility
-
Streamlines inventory & asset management with combined RFID/barcode printing
-
Integrates via CSV/API into ERP/WMS for seamless workflows
-
Fleet-wide consistency using Printer Twin™ profile sync
-
Broad media compatibility cuts changeover time
-
Industrial-grade reliability reduces maintenance and downtime
Purpose of Use
Ideal for on-demand printing of compliance labels, shipping tags, pallet IDs and RFID-embedded asset tags—ensuring traceability and regulatory adherence in high-volume industrial settings.
How to Use
-
Mount on bench or rack.
-
Drop in labels & ribbon; close cover.
-
Calibrate media and RFID inlays via touchscreen.
-
Design labels in your host software or on-device templates.
-
Press “Print” and use the built-in cutter or optional peeler.
Pro Tip: Use Printer Twin™ to clone configurations across your entire fleet in seconds.
Packaging / Weight / Dimensions
-
Unit Weight: 14.2 kg
-
Box Dimensions: 580 × 380 × 420 mm
-
Package Includes: XM7-40R printer, AC adapter, power cord, starter ribbon, quick-start guide
Warranty and FAQs
Warranty: 1 year parts and labor.
FAQs:
-
Can I print high-resolution graphics? Yes, switch to 300 dpi mode.
-
Does it support peel-off? Yes, add the optional peeler module.
-
How do I update firmware? Use SLCS™ utility over Ethernet or USB.
Performance, Quality, Durability, and Reliability
Rated for 25 km of thermal media with a cutter tested to 1 million cuts. Operates reliably from 5 °C to 40 °C. Metal housing and sealed controls resist dust, shocks and vibration, ensuring maximum uptime.
