two inch Thermal Printer Mechanism-ATP205

Reliable ATP205 2″ thermal printer mechanism—fast 150 mm/s, 203 dpi, auto-cutter ready. Perfect for kiosks, POS, and embedded apps.

Overview

Meet the ATP205, a compact 2 inch (58 mm) direct-thermal print engine built for seamless integration. It delivers 203 dpi clarity at up to 150 mm/s, with optional auto-cutter support. Ideal for ticketing kiosks, POS devices, and embedded systems, the ATP205 keeps your service fast and jam-free around the clock.

Product Description

The NEOTECH ATP205 is a high-performance thermal printing mechanism designed to slot into any compact device. Its direct-thermal head requires no ribbons—just load a 58 mm roll on a 12.7 mm core and you’re set. The precision stepper motor and optimized paper path ensure smooth feeds and perfect cuts (with cutter option). Rated for industrial use, it’s your go-to for reliable, low-maintenance printing.

Key Features

• 2″ (58 mm) width on 12.7 mm core

• 150 mm/s max print speed

• 203 dpi high-resolution thermal head

• Auto-cutter ready (full/partial cut)

• RS232 & USB interfaces

• Jam-free paper path design

• Metal chassis for durability

• MTBF ≥ 20,000 hours

Specifications

Supported OS / Applications / Industries

• OS: Windows, Linux, Android via SDK

• Apps: Kiosk firmware, POS systems, ticket machines

• Industries: Retail, Hospitality, Transportation, Healthcare, Vending

Benefits & Compatibility

• Plug-and-play integration with standard controllers

• Low maintenance: no ribbons, jam-resistant path

• High uptime: industrial-grade MTBF

• Compact footprint fits tight spaces

• Clean cuts for professional receipts and tickets

Purpose of Use

Perfect for embedding in ATMs, self-service kiosks, vending machines, and any compact POS or ticketing device that needs reliable 2″ printing.

How to Use

1. Mount ATP205 in your device chassis

2. Connect RS232 or USB cable to host board

3. Load 58 mm thermal roll (12.7 mm core)

4. (If needed) Attach auto-cutter module

5. Supply 5 V DC power and configure via SDK

6. Run test print; replace cutter blade per schedule

Packaging / Weight / Dimension

• Includes: ATP205 mechanism, interface cables, mounting screws, user guide

• Module size: 100×80×60 mm

• Module weight: 450 g

• Package weight: ~600 g

Warranty & FAQs

• Warranty: 12-month limited

• FAQs

  • Q: Which paper sizes work?
    A: 58 mm thermal rolls on 12.7 mm core.

  • Q: How to enable cutting?
    A: Attach optional cutter kit and enable via SDK.

  • Q: Can it print graphics?
    A: Yes—bitmaps and 1D/2D barcodes at 203 dpi.

Performance, Quality, Durability & Reliability

Featuring a precision stepper motor and optimized paper path, the ATP205 delivers consistent print density, jam-free feeds, and long-life performance under heavy use.

Best Price Guarantee

See a lower price on an equivalent print mechanism? NEOTECH will match it—no drama.

Shop Today & Receive Your Delivery Across the UAE!

Order the ATP205 now for express shipping to Dubai, Abu Dhabi, Sharjah, and beyond. Keep your kiosks and POS devices online and efficient.

Request for Customer Reviews & Testimonials

Installed your ATP205? Drop a quick review and let others know how it powers your device.

After-Sales Support

Need help with integration or troubleshooting? Our UAE support team is one call or email away. If remote fixes don’t work, we’ll guide you through a hassle-free RMA.

Get in Touch

For bulk quotes, custom firmware or SDK access, contact NEOTECH’s engineering team. We’ll provide samples, demos, and pro support.

Stock Availability

Confirm real-time stock with our sales team before ordering—lead times may vary for custom cutter kits.

Disclaimer

Specifications, pricing, and availability are subject to change without notice. Product images are illustrative; actual mechanism may vary. Verify all details before purchase.
