Overview
The PowerSwap Nucleus CLASSIC is a rugged, rack‑mountable lithium uninterruptible power system (UPS) designed to protect critical infrastructure. Its hot‑swap battery modules and smart controller deliver continuous power to servers, telecom gear, security cameras, and IoT devices, eliminating downtime during outages or maintenance.
Product Description
Built around high‑density lithium‑iron‑phosphate cells, the Nucleus CLASSIC packs reliable backup into a compact, 2U chassis. Each battery pack slides in tool‑free, allowing live replacement without interrupting load. An intuitive LCD displays runtime, charge status, and system alerts. Network‑grade monitoring via SNMP, Modbus, or HTTP ensures remote visibility. Multiple DC outputs and configurable voltage profiles make it ideal for edge, rack, and wall‑mount applications.
Key Features
-
2U rack‑mount chassis with optional wall brackets
-
Hot‑swap LiFePO₄ battery modules (120 Wh each)
-
Up to 480 Wh capacity with four slots
-
Wide‑range AC input: 90–264 VAC auto‑sensing
-
Configurable DC outputs: 12 V, 24 V, 48 V (up to 200 W total)
-
Integrated smart charge controller with taper‑charge algorithm
-
Front‑panel LCD for real‑time telemetry and alarms
-
Network management: SNMP v1/2c, Modbus TCP, HTTP/HTTPS
-
Dry‑contact alarm and audible buzzer
-
IP20 steel enclosure for industrial environments
Specifications
| Attribute |
Details |
| Battery Modules |
120 Wh each, 4 slots (max 480 Wh) |
| Output Capacity |
200 W continuous, 400 W peak |
| AC Input |
90–264 VAC, 47–63 Hz |
| DC Outputs |
Configurable 12 V/24 V/48 V |
| Efficiency |
> 92 % at full load |
| Operating Temp |
0 – 50 °C |
| Dimensions (HxWxD) |
88 × 482 × 300 mm (2U rack) |
| Weight (empty) |
6.5 kg |
Supported Applications & Industries
Applications: Network closets, micro data centers, CCTV/security systems, edge computing gateways, POS terminals.
Industries: Telecom, retail, finance, healthcare, industrial automation, smart buildings.
Benefits & Compatibility
-
Maintains critical loads through blackouts and brownouts
-
Live battery swaps prevent service disruption
-
Scales capacity by adding modules as demand grows
-
Integrates with NEOTECH’s rack PDUs and DC distribution units
-
Remote alerts via email, SNMP traps, and dry‑contact closures
-
Fits standard 19″ racks or wall cabinets for flexible deployment
Purpose of Use
Deploy the Nucleus CLASSIC wherever small‑form‑factor UPS protection is needed. Its live‑swap capability and remote management make it perfect for unmanned sites, branch offices, and mission‑critical edge locations.
How to Use
-
Mount in a 19″ rack or wall cabinet using included brackets
-
Connect AC input and configure DC output voltages
-
Insert charged battery modules until they click in
-
Access the web GUI or SNMP to set thresholds and alerts
-
Monitor load status and hot‑swap modules when indicated
Packaging / Weight / Dimensions
Package Includes: Nucleus CLASSIC chassis, mounting brackets, startup guide, safety instructions.
Chassis Weight: 6.5 kg (empty); 1.2 kg per battery module.
Box Dimensions: 550 × 380 × 200 mm.
Warranty & FAQs
Warranty: 2‑year limited manufacturer warranty
FAQ:
• Q: Can I mix old and new modules?
No. Always replace with same‑model packs.
• Q: How long at full load?
Approx. 2.4 hours at 200 W with four modules.
• Q: Is remote firmware update supported?
Yes, via HTTP or SNMP utilities.
Performance, Quality, Durability & Reliability
Engineered with industrial‑grade cells and PCBs, the Nucleus CLASSIC endures over 2,000 cycle life at 80 % depth of discharge. Its steel enclosure and conformal‑coated boards resist vibration, dust, and moisture in harsh environments.
