V4500: Rugged fixed-mount 1D/2D scanner with Ethernet & USB, IP65, 60 FPS for high-volume lines. Perfect for conveyors & kiosks. Order in UAE.
Overview
The V4500 delivers industrial-grade barcode capture for nonstop production environments. Its omnidirectional imager and IP65-rated housing ensure reliable 1D/2D reads at up to 60 frames/sec—even in dusty or wet conditions.
Product Description
Engineered for relentless throughput, the V4500 combines a 2 MP global-shutter sensor with optimized optics to decode linear and matrix codes on paper, plastic, or screens. Mount it via standard M12 brackets above conveyors or at kiosks, connect over Ethernet or USB-C, and integrate seamlessly with your WMS, MES, or POS systems. Its die-cast aluminum chassis, sealed front, and industrial-grade electronics deliver operational excellence and worry-free uptime.
Key Features
-
60 FPS Area Imaging – Rapid omnidirectional 1D/2D reads for high-speed lines
-
IP65-Rated Housing – Sealed against dust and water jets for harsh environments
-
Dual Connectivity – USB-C HID & Ethernet TCP/IP for flexible deployment
-
Wide Field of View – 60° H × 45° V covers broad scan zones at any angle
-
Durable Construction – Die-cast aluminum frame and industry-grade optics
-
Status Indicators – Programmable LEDs and buzzer for instant pass/fail alerts
Specifications
-
Sensor: 2 MP global-shutter CMOS
-
Frame Rate: 60 FPS (up to 3,600 reads/min)
-
Resolution: 1280 × 720 pixels
-
Field of View: 60° H × 45° V
-
Interfaces: USB-C (HID), Ethernet (10/100 Mbps)
-
Mounting: M12-thread brackets (included)
-
Ingress: IP65 front; IP42 rear
-
Power: 5 V DC via USB-C or PoE injector
-
Dimensions: 120 × 80 × 80 mm
-
Weight: 450 g
-
Operating Temp: –20 °C to 50 °C
Supported OS / Applications / Industries
-
OS: Windows, Linux, macOS (HID/TCP)
-
Applications: Conveyor scanning, self-service kiosks, automated sorting
-
Industries: Manufacturing, logistics, retail, pharmaceuticals
Benefits & Compatibility
-
Plug-and-Play Integration: HID and TCP/IP protocols for rapid rollout
-
24/7 Reliability: IP-rated enclosure and industrial electronics minimize downtime
-
Scalable Architecture: Ethernet networking supports multi-scanner sync
-
Workflow Optimization: Wide FOV and high FPS eliminate manual rescans
Purpose of Use
Ideal for:
-
High-speed conveyor belt code capture
-
Self-checkout and ticketing kiosks
-
Automated parts tracking in manufacturing
-
Pharmaceutical label verification under clean conditions
How to Use
-
Mount the V4500 on its M12 bracket at the target height.
-
Connect via USB-C or Ethernet to your host system.
-
Configure scan parameters through your control software.
-
Position items in view—scans trigger automatically.
-
Monitor status via LEDs or integrate feedback into your dashboard.
Packaging / Weight / Dimension
-
Includes: V4500 scanner, 2× M12 brackets, USB-C cable, quick-start guide
-
Packed Weight: 700 g
-
Box Size: 180 × 120 × 100 mm
-
Protection: Molded foam insert
Warranty and FAQs
FAQs:
-
Can I power via PoE? Yes, with an optional PoE injector.
-
Does it read DPM codes? Yes—supports direct-part marks down to 10 mil.
-
How do I adjust illumination? Set LED intensity via your host’s config tool.
Performance, Quality, Durability & Reliability
Tested to 5 million scan cycles and 1.5 m drops, the V4500 meets IEC shock and vibration specs. Its sealed optics and die-cast housing ensure consistent performance in 24/7 industrial deployments.
