48× 10 GbE (SFP+), 8× 40 GbE QSFP+ uplinks, 1.2 Tbps switching, < 1 µs latency, redundant PSUs/fans, L2/L3, SDN APIs, CLI/Web UI.
Overview
The 10 GbE Aggregation Switch unites edge leafs into a fast, scalable fabric. It packs 48 SFP+ ports plus eight 40 GbE QSFP+ uplinks in 1 RU. Ideal for spine-leaf, DMZ, and converged data-center aggregation.
Product Description
• 48× 10 GbE SFP+ host ports for server or leaf links
• 8× 40 GbE QSFP+ uplinks (breakout to 4× 10 Gb) for spine or core
• Switching Capacity: 1.2 Tbps full-duplex line-rate
• Latency: < 1 µs port-to-port for HPC and VN-Fs
• Resiliency: Dual hot-swap PSUs & fans for 24/7 uptime
• Features: L2/L3 routing, MLAG, VXLAN EVPN, QoS, ACLs
• Management: CLI, Web UI, SNMPv3, RESTCONF/NETCONF APIs
Scale your data center with low latency and high throughput.
Key Features
-
High Port Density: 48× 10 GbE in 1 RU
-
Flexible Uplinks: 8× 40 GbE QSFP+ breakout support
-
Line-Rate Performance: 1.2 Tbps, 900 Mpps forwarding
-
Advanced Fabric: VXLAN, MLAG, BGP EVPN for seamless scale
-
Redundant Design: PSUs/fans hot-swap for non-stop ops
-
Automation Ready: RESTCONF/NETCONF & Python scripting
Specifications
| Spec |
Detail |
| Host Ports |
48× 10 GbE SFP+ |
| Uplink Ports |
8× 40 GbE QSFP+ (4×10 Gb breakout) |
| Switching Cap. |
1.2 Tbps full-duplex |
| Forwarding Rate |
900 Mpps |
| Latency |
< 1 µs |
| PSUs |
2× 750 W hot-swap redundant |
| Fans |
4× hot-swap, front-to-back airflow |
| OS |
Layer 2/Layer 3, VXLAN EVPN, MLAG |
| Mgmt |
CLI, Web UI, SNMPv3, RESTCONF/NETCONF |
| Dimensions |
44.5×440×350 mm (H×W×D) |
| Weight |
~7 kg |
| Power Draw |
~350 W typical; eco-mode available |
| Operating Temp. |
0 °C–45 °C |
Supported Use Cases & Industries
-
Use Cases: Spine-leaf fabrics, TOR aggregation, virtualization backhaul, HPC clusters
-
Industries: Cloud providers, enterprise DC, telco, research labs
Benefits & Compatibility
-
Low Latency: < 1 µs for demanding workloads
-
Scalable Fabric: VXLAN EVPN & MLAG for seamless growth
-
High Availability: Redundant PSUs/fans, ECC memory
-
Programmable: Automation via RESTCONF/NETCONF & Python
-
Future-Proof: Breakout uplinks support 10/25/40 GbE
Purpose of Use
Ideal as a leaf-to-spine aggregation layer in data-center and campus deployments.
How to Use
-
Rack-mount the 1 RU switch.
-
Install 10 GbE SFP+ modules in ports 1–48.
-
Link with QSFP+ uplinks to spine/core.
-
Configure VLANs, MLAG, and EVPN via CLI/Web.
-
Automate using RESTCONF or NETCONF APIs.
Packaging & Dimensions
Warranty & FAQs
Warranty: 5-year advanced replacement.
FAQs:
-
Q: QSFP+ breakout supported?
A: Yep, 4×10 Gb per QSFP+.
-
Q: PoE support?
A: No—designed for pure data fabrics.
Performance & Reliability
Built for 99.999% uptime with redundant modules and enterprise ASIC for low-latency forwarding.
