Thermal printer module-EP25

Discover the NEOTECH EP25 58 mm thermal printer module with auto cutter, paper sensor & USB/TTL. Quiet, fast & reliable printing for kiosks and POS.

Overview

The NEOTECH EP25 packs high-speed thermal printing into a compact 58 mm module. Ideal for POS terminals, ticket kiosks and handheld devices, it delivers crisp text, logos and barcodes at up to 200 mm/s. With built-in paper-end and cover-open sensors plus an auto-cutter, the EP25 keeps operations smooth and jam-free. Low noise (< 55 dB) and energy-efficient design make it perfect for 24/7 environments.

Product Description

Engineered for durability and easy integration, the EP25 features a direct-thermal print head at 203 DPI, supporting full and partial cuts via its auto-cutter. Multiple interfaces—USB 2.0, RS-232 and TTL—ensure broad compatibility with legacy and modern systems. Precision winding and smooth edges minimize jams, while eco-friendly, inkless printing reduces maintenance. Its small footprint (120 × 100 × 80 mm) fits tight installations without compromise.

Key Features

• Print speed up to 200 mm/s for rapid output

• 203 DPI resolution for sharp text and images

• Auto-cutter with full & partial cut modes

• Dual sensors: paper-end & cover-open alerts

• Interfaces: USB 2.0, RS-232 & TTL for versatile use

• Low noise operation (< 55 dB) for quiet spaces

• Compact size (120 × 100 × 80 mm) for tight integrations

• Inkless, eco-friendly thermal technology

Specifications

• Printing Method: Direct Thermal

• Print Width: 58 mm ± 0.5 mm

• Resolution: 203 DPI

• Speed: Up to 200 mm/sec

• Paper Roll Diameter: ≤ 40 mm

• Core Diameter: 12 mm

• Interfaces: USB 2.0, RS-232, TTL

• Cutter: Auto full/partial

• Sensors: Paper-End, Cover-Open

• Operating Voltage: DC 24 V ± 5%

• Noise Level: < 55 dB

• Dimensions: 120 × 100 × 80 mm

• Weight: 0.9 kg

Supported OS / Applications / Industries

• OS: Windows, Linux, Android (via USB OTG)

• Applications: Retail POS, Ticketing Kiosks, Mobile Terminals

• Industries: Hospitality, Transportation, Banking, Events

Benefits & Compatibility

• Plug-and-play setup—minimal driver install

• Inkless design eliminates ribbon costs

• Fits any printer accepting 58 mm rolls with 12 mm core

• Low noise and power-efficient for continuous duty

Purpose of Use

Perfect for on-demand receipts, tickets and vouchers in high-traffic, self-service environments. Keeps checkout and kiosk workflows seamless.

How to Use

1. Mount a 58 mm roll onto the 12 mm core spindle.

2. Thread paper through the feed path; close the cover.

3. Connect via USB, RS-232 or TTL to your host.

4. Send print commands from your software; enjoy clean cuts.

Packaging / Weight / Dimensions

• Net Weight: 0.9 kg

• Box Size: 140 × 120 × 90 mm

• Includes:

  • 1 × EP25 Printer Module

  • 1 × USB Cable

  • 1 × RS-232 Cable

  • 1 × Power Adapter

  • 1 × Quick Start Guide

Warranty and FAQs

Warranty: 12-month return-to-base coverage

FAQs:
Q1. Can EP25 print graphics?
Yes—supports bitmap logos at 203 DPI.
Q2. How do I know when paper is low?
The paper-end sensor alerts your system.
Q3. Is it noisy?
No—operates under 55 dB for a quiet environment.

For more help, visit our Support Center or Contact Us.

Performance, Quality, Durability, and Reliability

• MTBF over 120,000 hours for nonstop performance

• Tested across 0–50 °C and high-humidity cycles

• Anti-jam path and precision winding for consistent feeds

• 4.7★ rating from integrators worldwide

Best Price Guarantee

We’ll match any lower official price. Shop confidently with NEOTECH’s price-match promise.

Shop Today & Receive Your Delivery Across the UAE!

Order your EP25 now for fast, tracked delivery to Dubai, Abu Dhabi, Sharjah and beyond.

Request for Customer Reviews and Testimonials

Tried the EP25? Share your feedback on speed, reliability or integration—your review helps us improve!

After Sales Support

Our team offers 24/7 remote troubleshooting and RMA processing to keep your operations running.

Get in Touch

For bulk quotes or technical advice, WhatsApp +971-4-123-4567 or email sales@neodgital.com. We’re here to assist.

Stock Availability

EP25 modules are in stock for immediate dispatch. For large-volume orders, please confirm availability before ordering.

Disclaimer

All info is subject to change without notice. Images are illustrative. Verify specs, pricing and stock with NEOTECH before purchase.
