4G Embedded Panel PC Waterproof Intel J6412 I3 I5 I7 Touch Screen Pc Fanless Embedded Industrial Panel PC

Rugged IP65 fanless panel PC, Intel® J6412/i3–i7, 4G LTE, capacitive touch, 8–16 GB DDR4, 64–512 GB NVMe. Win/Linux ready, zero-maintenance industrial HMI.

Overview

CESIPC’s 4G Embedded Panel PC packs choice Intel® CPUs (J6412, Core™ i3/i5/i7), built-in 4G LTE, and a glove-friendly PCAP touchscreen into a sealed, fanless IP65 chassis. Ideal for remote kiosks, field automation, and wash-down zones, it delivers always-on connectivity and silent, maintenance-free operation.

Product Description

Choose your performance tier—Celeron® J6412 (4 cores @1.5 GHz) up to Core™ i7-10510U (4 cores/8 threads, 1.8–4.9 GHz)—paired with 8–16 GB DDR4 and 64–512 GB NVMe SSD. The 10.1″ 1280×800 PCAP touchscreen works with gloves. IP65-sealed M12 I/O includes USB 3.0, GbE LAN, RS-232/485, HDMI, plus dual-band Wi-Fi, Bluetooth 5.0, and LTE-A. Passive cooling ensures silent 24/7 uptime on 9–36 V DC with surge/reverse-polarity protection, running Windows 10 IoT or Linux out-of-the-box.

Key Features

• 4G LTE Connectivity: global mobile broadband

• Intel® CPU Options: J6412, Core™ i3/i5/i7 for scalable performance

• IP65 Fanless Chassis: wash-down proof, dust-tight, no fans to service

• 10.1″ PCAP Touch: glove-friendly multi-touch precision

• Memory & Storage: 8–16 GB DDR4; 64–512 GB NVMe SSD

• M12-Sealed I/O: USB 3.0, GbE LAN, RS-232/485, HDMI out

• Wireless: Wi-Fi 802.11ac, Bluetooth 5.0, and LTE-A

• Power Input: 9–36 V DC w/ built-in surge & reverse-polarity protection

• Passive Cooling: silent, zero-maintenance operation

• OS Ready: Windows 10 IoT, Ubuntu/Debian Linux

Specifications

Supported OS / Applications / Industries

• OS: Windows 10 IoT Enterprise, Ubuntu/Debian Linux

• Use Cases: Remote kiosks, SCADA, field automation, mobile HMI

• Industries: Manufacturing, logistics, utilities, food & beverage

Benefits & Compatibility

• Always-On Connectivity: LTE + Wi-Fi ensures remote uptime

• Zero Maintenance: fanless, sealed design eliminates downtime

• Flexible Performance: scale CPU and storage to match workload

• Glove-Operable UI: works in PPE and damp environments

• Sealed I/O Ecosystem: M12 connectors for rugged peripheral integration

Purpose of Use

Ideal for outdoor kiosks, mobile diagnostics, machine-side control panels, and any application demanding field-ready compute with built-in 4G.

How to Use

1. Cut panel opening per supplied template

2. Mount using clamp brackets or VESA kit

3. Insert SIM card, connect antennas

4. Connect 9–36 V DC, Ethernet, USB/serial, HDMI

5. Boot into Windows IoT or Linux; configure LTE & Wi-Fi

6. Clean front with low-pressure spray—no fans to service

Warranty & FAQs

Warranty: 1 year standard; 3-year extension optional.
FAQs:

• Does LTE require external antenna? Yes—two SMA ports support high-gain 4G antennas.

• Can it handle chemical wash-down? IP65 seals protect against jets and mild cleansers.

After-Sales Support

24/7 remote monitoring, firmware updates, and optional on-site service ensure continuous field operation.

Get in Touch

For custom configs or volume quotes, email sales@neotech.ae or visit neotech.ae/contact.

Disclaimer

Specifications subject to change without notice. Images are illustrative—verify details with our sales team prior to deployment.
