Outdoor Mini 5 Port Industrial Switch Unmanaged 10/100Mbps DIN Rail Automation Factory Compact Size

Compact 5-Port Outdoor Industrial Switch with 10/100Mbps, unmanaged, DIN-rail mount. Built for automation and factory use. Shop NEOTECH UAE now.

✅ Overview

The Mini 5-Port Industrial Ethernet Switch delivers reliable 10/100Mbps performance in a compact, rugged design. Ideal for automation networks and factory setups, it fits tight enclosures and withstands harsh environments. With unmanaged simplicity and DIN-rail mounting, it's the perfect plug-and-play solution for outdoor control systems.

✅ Product Description

This outdoor-ready 5-port industrial switch is built for tight spaces and field-level reliability. It features 5 x 10/100 Mbps RJ45 ports in an ultra-compact aluminum chassis, making it ideal for embedded factory systems, machine control panels, and field enclosures. Its fanless design and DIN-rail mount capability ensure easy installation in harsh industrial environments.

With ESD protection and wide operating temperature support, this unmanaged switch offers simple, stable Ethernet connectivity with zero configuration required.

✅ Key Features

• 5 x 10/100 Mbps RJ45 ports

• Ultra-compact size for tight enclosures

• Unmanaged—true plug-and-play

• IP-rated rugged aluminum enclosure

• DIN-rail or wall mountable

• Operating Temp: -40°C to 75°C

• Wide power input: 9–36V DC

• ESD & surge protection

• Fanless design for silent performance

✅ Specifications

• Ports: 5 x 10/100Base-TX

• Switching Capacity: 1 Gbps

• Forwarding Rate: 0.744 Mpps

• Power Input: 9–36V DC

• Cooling: Passive (fanless)

• Material: Industrial-grade aluminum alloy

• Mounting: DIN-rail or wall

• Operating Temp: -40°C to 75°C

• Dimensions: Approx. 95mm x 70mm x 25mm

• Weight: ~0.28 kg

✅ Supported OS/Application/Industries

• OS Support: Plug-and-play across all platforms

• Applications: Factory automation, remote sensors, small machines

• Industries: Industrial IoT, Process Control, Manufacturing, Energy

✅ Benefits & Compatibility

• Compact for embedded and space-constrained installations

• Compatible with legacy and modern Ethernet systems

• Perfect for low-bandwidth automation devices

• Easy to install and power in field panels

• Cost-effective choice for non-PoE industrial networking

✅ Purpose of Use

Perfect for use in control cabinets, machine-level connections, and small outdoor enclosures where basic, reliable Ethernet switching is required.

✅ How to Use

1. Mount on DIN-rail or secure flat surface

2. Connect RJ45 Ethernet devices

3. Power with 9–36V DC supply

4. Auto-negotiation kicks in—no setup required

✅ Packaging/Weight/Dimension

• Size: 95 x 70 x 25 mm

• Weight: ~0.28 kg

• Package Includes: 1x Switch, DIN-rail clip, terminal block, user manual

✅ Warranty and FAQs

Warranty: 1-Year NEOTECH hardware warranty
FAQs:
Q1: Can this be used in IP-rated outdoor enclosures?
A1: Yes, it’s compact and ideal for enclosed outdoor units.
Q2: Does it support Gigabit?
A2: No, it supports 10/100 Mbps only.
Q3: Is PoE available?
A3: No, this model is non-PoE.

✅ Performance, Quality, Durability, and Reliability

Designed for 24/7 operation in harsh industrial environments, this mini switch handles electrical interference, temperature variation, and vibration—ensuring long-term stability.

✅ Best Price Guarantee

Found it for less in the UAE? Let us know. NEOTECH will match verified pricing to ensure the best value for your budget.

✅ Shop Today & Receive Your Delivery Across the UAE!

Fast, reliable shipping across all Emirates: Dubai, Abu Dhabi, Sharjah, Ajman, and beyond. Order now for swift fulfillment.

✅ Request for Customer Reviews and Testimonials

Installed this compact switch in your automation system? Leave a review and share your experience with fellow professionals.

✅ After Sales Support

Need help with setup, power configuration, or placement? Our team is ready to assist post-purchase with any support you need.

✅ Get in Touch

For bulk pricing, technical questions, or compatibility checks, contact NEOTECH’s team of experts today.

✅ Stock Availability

Product is in stock now. For urgent or large-scale orders, please verify availability with our team.

✅ Disclaimer

Specifications and images are for reference. Please verify exact technical details before purchasing. NEOTECH is not liable for specification changes without notice.
