DIN Rail 10/100/1000M Gigabit PoE 8 Port Industrial Media Converter

DIN rail 8-port PoE media converter with 10/100/1000Mbps speed. Industrial-grade, rugged, reliable—ideal for powering IP devices in harsh environments.

✅ Overview

The DIN Rail 8-Port Gigabit PoE Industrial Media Converter is designed for high-speed data and power delivery in mission-critical networks. It supports 10/100/1000Mbps auto-negotiation, offers multiple PoE outputs, and is hardened for industrial-grade performance in extreme conditions.

✅ Product Description

Built for heavy-duty applications, this 8-port industrial-grade media converter combines high-speed Ethernet switching and Power over Ethernet (PoE) in a single DIN rail-mountable unit. With eight RJ45 ports—four or more supporting IEEE 802.3af/at PoE—it powers cameras, wireless access points, and IoT sensors without separate power cables.

Its fanless design, metal IP40 enclosure, and wide temperature tolerance allow stable operation in factories, tunnels, smart cities, and outdoor installations. Supporting plug-and-play use, it delivers unmatched reliability and uptime for demanding industrial deployments.

✅ Key Features

• ⚡ 8 x 10/100/1000Mbps RJ45 ports

• 🔌 4/8 ports support IEEE 802.3af/at PoE (up to 30W per port)

• 🌐 Full Gigabit switching capacity

• 🔗 Optional 1–2 SFP uplink slots for fiber expansion

• ❄️ Industrial operating temp: -40°C ~ +75°C

• 🧱 Rugged IP40-rated aluminum alloy housing

• 🛠️ DIN rail & wall mount support

• 💡 LED indicators for status and power

• 🔒 Surge (6KV) and ESD (8KV) protection built-in

✅ Specifications

• Ethernet Ports: 8 x RJ45, 10/100/1000Mbps

• PoE Ports: 4 to 8 ports with IEEE 802.3af/at support

• PoE Output: Up to 30W per port | Total PoE budget up to 120W

• Uplink Slots: Optional 1–2 SFP 1000Mbps

• Backplane Bandwidth: 20Gbps

• Input Power: 48–57V DC (terminal block)

• Protection: Surge (6KV), ESD (8KV), lightning protection

• Mounting: DIN rail and wall

• Temperature Range: -40°C ~ +75°C

• Dimensions: Approx. 155 x 105 x 45 mm

• Weight: ~850g

✅ Supported OS / Applications / Industries

• OS Compatibility: Plug-and-play, OS-agnostic

• Applications: IP surveillance, industrial IoT, smart lighting, automation control, outdoor PoE deployments

• Industries: Energy, logistics, smart cities, railways, manufacturing, telecom infrastructure

✅ Benefits & Compatibility

• 🔧 No config required—plug and operate

• 🔋 PoE eliminates need for separate power cables

• 🧱 Durable for harsh, remote environments

• 🌐 Supports long-range fiber uplinks with SFP modules

• 📶 Compatible with PoE IP cameras, VoIP phones, APs, controllers

✅ Purpose of Use

Ideal for large-scale industrial PoE deployments, this converter powers and connects multiple Ethernet devices in a compact DIN-mounted footprint. Perfect for remote access points, outdoor security networks, and smart city installations.

✅ How to Use

1. Mount to DIN rail or secure wall plate

2. Connect RJ45 devices (PoE & non-PoE)

3. Insert SFP uplinks if required

4. Provide 48–57V DC input via terminal block

5. Power up—LED indicators confirm network and power status

✅ Packaging / Weight / Dimension

• Includes: Converter, mounting kit, terminal block, user guide

• Net Weight: ~850g

• Package Dimensions: ~18 x 12 x 6.5 cm

• Casing: Anti-rust aluminum shell with fanless cooling

✅ Warranty and FAQs

• Warranty: 1-year industrial-grade warranty

• Returns: NEOTECH RMA process applies

• Support: Technical assistance via phone or email

• FAQs: Browse common install/setup questions on our Support Page

✅ Performance, Quality, Durability, and Reliability

This media converter excels in demanding environments. It offers 24/7 uptime, stable PoE performance, and seamless high-speed switching in rugged conditions. Fully compliant with industrial standards and tested for long-term deployments.

✅ Best Price Guarantee

We price match within the UAE. Get the best deal on reliable industrial networking—only at NEOTECH.

✅ Shop Today & Receive Your Delivery Across the UAE!

We deliver to all major UAE cities including Dubai, Sharjah, Abu Dhabi, and more. Order now for fast, secure shipping and full support.

✅ Request for Customer Reviews and Testimonials

Already deployed this unit? Drop a review! Share your setup and help others choose with confidence.

✅ After Sales Support

Our team is always here post-purchase—whether you need fiber module advice, power planning, or troubleshooting.

✅ Get in Touch

Need help with fiber compatibility or power requirements? Contact our technical team for expert guidance and pre-sales support.

✅ Stock Availability

Stock moves fast—check with us to confirm availability for bulk or time-sensitive projects.

✅ Disclaimer

Specifications and visuals are for reference only and may change without notice. Confirm details with NEOTECH before final purchase.
