4U rackmount industrial server with Intel® Core™ i3/i5/i7, up to 2 TB SSD, lockable front door, redundant PSUs, and fanless cooling—built for embedded control.
Overview
This 4U rackmount industrial server combines desktop-class Intel® Core™ processing with rugged reliability. Featuring lockable front access, up to 2 TB SSD storage, and optional redundant power supplies, it delivers secure, silent operation in embedded control and automation environments.
Product Description
Designed for factory floors, control cabinets, and edge data hubs, this server chassis supports ATX or micro-ATX motherboards with Core™ i3, i5, or i7 CPUs. Four hot-swap 2.5″ SSD bays accommodate up to 2 TB of solid-state storage. A lockable front bezel prevents unauthorized access, while fanless passive-cooling maintains silent, dust-free operation. Dual 80 mm intake fans and rear exhaust optimize airflow. Standard rail kits and VESA brackets simplify 19″ rack installation.
Key Features
-
Processor Support: Intel® Core™ i3/i5/i7 (LGA1151)
-
Storage: 4× hot-swap 2.5″ SSD bays (up to 2 TB total)
-
Lockable Front: Keyed bezel secures internal drives and ports
-
Cooling: Fanless design plus 2× 80 mm intake/rear exhaust fans
-
PSU Options: Single or redundant 600 W 80 PLUS Gold power supplies
-
Expansion: 3× full-height PCIe Gen3 slots for NICs or I/O cards
-
I/O Ports: Front USB 3.0, power/reset; rear USB, VGA, serial, LAN
-
Mounting: 19″ rack rails & VESA 75×75 mm bracket included
Specifications
| Specification |
Details |
| Form Factor |
4U rackmount, ATX/mATX support |
| Motherboard |
ATX/micro-ATX up to 305 mm depth |
| CPU Socket |
LGA 1151 for Core™ i3/i5/i7 (6th–9th Gen) |
| Memory |
4× DDR4 UDIMM slots, ECC optional, up to 64 GB |
| Drive Bays |
4× hot-swap 2.5″ SSD bays; 2× internal 2.5″ fixed bays |
| PCIe Slots |
3× full-height PCIe Gen3 ×16 slots |
| Cooling Fans |
2× 80 mm front intake (hot-swap), 1× rear exhaust |
| PSU |
1× or 2× (redundant) 600 W 80 PLUS Gold (hot-swap) |
| Front I/O |
2× USB 3.0, power/reset button, HDD LED (behind door) |
| Rear I/O |
USB 2.0, VGA, COM port, dual LAN, audio in/out |
| Locking Mechanism |
Keyed front bezel locking drive bays and I/O access |
| Power Input |
100–240 VAC via IEC C14 inlet |
| Operating Temp. |
0 °C to 50 °C |
| Dimensions (WxDxH) |
482 × 600 × 177 mm |
| Weight (empty) |
~20 kg |
Supported OS / Applications / Industries
-
Operating Systems: Windows Server, Ubuntu Server, RHEL
-
Applications: Embedded control, SCADA, edge compute, network gateway
-
Industries: Manufacturing, energy, transportation, oil & gas
Benefits & Compatibility
-
Enhanced Security: Lockable front bezel prevents tampering and drive theft
-
Silent & Clean: Fanless cooling eliminates dust ingress and noise
-
High Availability: Redundant PSUs and hot-swap SSD bays minimize downtime
Purpose of Use
Ideal as an embedded control server in automation cells, an edge-compute node in IIoT networks, or a secure gateway in critical infrastructure applications.
How to Use
-
Slide rails into a 19″ rack and secure chassis.
-
Install CPU, memory, motherboard, and redundant PSUs as required.
-
Insert SSDs into hot-swap drive bays, then lock bezel.
-
Connect power, network, and I/O cables to rear ports.
-
Power On, configure BIOS/OS, and deploy your control software.
Packaging / Weight / Dimensions
-
Packaging: Reinforced foam-lined carton
-
Net Weight: ~20 kg (empty chassis)
-
Gross Weight: ~24 kg (with accessories)
-
Box Size: 600 × 350 × 260 mm
Warranty and FAQs
Performance, Quality, Durability, and Reliability
Constructed from SECC steel with powder-coat finish; tested to IEC 60068 vibration and shock standards. Hot-swap SSD bays and redundant PSUs ensure continuous operation under load.
Best Price Guarantee
Find a lower price on an identical 4U industrial server? We’ll match it—guaranteed to maximize your ROI.
Shop Today & Receive Your Delivery Across the UAE!
Order now for express delivery to all emirates. In-stock units ship same-day for rapid deployment.
Request for Customer Reviews and Testimonials
Share your deployment success to help peers and guide future enhancements to our industrial server lineup.
After Sales Support
Our support team provides rack integration assistance, firmware updates, and spare-part ordering. Expect a response within one business day.
Get in Touch
For custom configurations or volume orders, email sales@cesipc.com. Our solutions engineers are ready to assist you.
Stock Availability
Units are in stock and ready for dispatch. Confirm availability with our sales team before placing your order to avoid project delays.
Disclaimer
All specifications and images are for reference only and may change without notice. Verify final details and compatibility with your sales representative prior to purchase.
