Create stunning see‑through signage with Planar LookThru 55" Transparent OLED. Full HD, 120% NTSC, frameless glass. Order now at NEOTECH UAE.
Overview
Planar LookThru brings truly see‑through digital signage to life with a virtually frameless, 55" transparent OLED panel. Its emissive OLED technology eliminates backlights and enclosures, rendering vibrant graphics overlaid on any backdrop. Perfect for retail, museums and corporate environments, LookThru captivates audiences with a seamless blend of digital content and real‑world context Planar.
Product Description
This transparent OLED display leverages Planar’s ERO‑OLED™ process and optically bonded Corning® Gorilla® Glass for ruggedness and touchscreen compatibility. With Full HD resolution and over 120% NTSC color gamut, LookThru delivers high‑contrast video and graphics even in brightly lit spaces. Its thin (7 mm) glass form factor mounts as a single portrait or landscape display, or tiles into eye‑catching video walls Planar.
Key Features
-
55" diagonal transparent AMOLED panel Planar
-
Full HD (1920 × 1080) resolution Planar
-
120% NTSC color gamut for vibrant hues Planar
-
500 cd/m² peak white brightness Planar
-
Wide 360° viewing with no off‑axis loss Planar
-
Planar ERO‑OLED™ with Gorilla Glass surface
-
Frameless glass design, 7 mm thickness
-
HDMI × 4, DisplayPort × 1 inputs
-
Control via IR, RS‑232, USB, LAN, Crestron module
-
Flexible mounting: tabletop, straight or ceiling
-
Tiling components for flat/corner video walls
Specifications
| Attribute |
Details |
| Model |
LO552 (standard), LO552‑S (straight) |
| Viewable Size |
55" diagonal |
| Resolution |
1920 × 1080 (Full HD) |
| Display Type |
Active Matrix OLED |
| Color Gamut |
>120% NTSC |
| Brightness |
500 cd/m² peak white |
| Surface |
ERO‑OLED™ with Gorilla Glass |
| Inputs |
HDMI × 4, DisplayPort × 1 |
| Control & Monitoring |
IR, RS‑232, USB, LAN, Crestron |
| Dimensions (W×H×D) |
1223.4 × 680.4 × 7.1 mm |
| Mount Options |
Tabletop, ceiling, straight mount |
| Tiling Components |
Flat/corner edge & center pieces |
| Power |
100–240 VAC auto‑switching |
Supported Applications & Industries
Applications: Retail window displays, museum exhibits, corporate signage, award cases, interactive kiosks.
Industries: Retail, hospitality, museums, corporate campuses, trade shows.
Benefits & Compatibility
-
Enables immersive see‑through installations without blocking views
-
Integrates with NEOTECH Video Wall Controllers for tiled arrays
-
Works with NEOTECH OLED Accessories including tiling kits and mounts
-
Touchscreen capable for interactive experiences
-
Unified control via HDMI, DP, IR/RS‑232 and LAN
-
Durable for high‑traffic public environments
Purpose of Use
Ideal for showcasing products behind glass while overlaying dynamic digital content. Use in storefronts, museum vitrines, or conference venues to draw attention without obscuring real objects.
How to Use
-
Unpack and choose orientation (portrait/landscape).
-
Mount display using included tabletop, straight or ceiling hardware.
-
Connect HDMI/DisplayPort to your media player.
-
Configure control via IR, RS‑232 or LAN.
-
For video walls, install edge/center tiling components and daisy‑chain inputs.
Packaging / Weight / Dimensions
Package Includes: Display panel, power cord, tabletop mount, straight/ceiling mount hardware, tiling accessories (as ordered).
Display Weight: 28 kg (approx.).
Package Dimensions: 1370 × 860 × 130 mm.
Warranty & FAQs
Warranty: 3‑year limited manufacturer warranty.
FAQ:
• Can displays tile? Yes—use Planar tiling components for flat or corner configurations Planar.
• Is it touch‑enabled? Yes, Gorilla Glass surface supports touch overlays.
• Suitable for outdoor use? Designed for indoor environments; avoid direct sunlight.
Performance, Quality, Durability & Reliability
Engineered for continuous use, LookThru uses self‑emissive OLED technology for uniform brightness and color accuracy over a wide temperature range. Gorilla Glass bonding adds impact resistance and supports interactive touch modules.
Best Price Guarantee
NEOTECH offers the lowest UAE pricing on Planar LookThru displays. Found a better price? We’ll match it and credit 5 % back to your account.
Shop Today & Receive Your Delivery Across the UAE
Order now for express delivery to Dubai, Abu Dhabi, Sharjah and beyond. Stock available in UAE warehouses for same‑day dispatch.
Request for Customer Reviews and Testimonials
Installed a Planar LookThru display? Share your installation story and get featured. Your feedback helps others visualize possibilities.
After Sales Support
NEOTECH’s UAE support team provides setup assistance, firmware updates, and accessory sourcing. Reach our experts via phone, email or live chat.
Get in Touch
Need help designing your next transparent signage project? Contact our display specialists for tailored advice and rapid response.
Stock Availability
In stock and ready to ship. Limited quantities—reserve your Planar LookThru today to avoid delays.
Disclaimer
All trademarks are property of their owners. Specifications subject to change without notice. Images shown are for illustrative purposes.
