Overview
The Touch Dynamic Orion Ultra CPU Processor is a fanless, industrial-grade compute module built to run 24/7 in harsh environments. Engineered for edge analytics, machine vision, and IoT gateways, it delivers desktop-class performance in a compact, dust-proof enclosure.
Product Description
At its heart lies an Intel® Core™ i7-1185G7 quad-core processor paired with up to 32 GB DDR4 memory and dual M.2 NVMe SSD slots. The Orion Ultra’s passive-cooled design eliminates moving parts, reducing failure risk in dusty or vibration-prone settings. Flexible I/O expansion—USB 3.2, Gigabit LAN, serial ports, GPIO—lets you tailor the module to any industrial control or automation application.
Key Features
-
Intel® Core™ i7-1185G7 (4 cores/8 threads, up to 4.8 GHz)
-
Fanless, IP50-rated aluminum housing for dust resistance
-
Dual M.2 NVMe SSD slots for high-speed storage (2242/2280)
-
Up to 32 GB DDR4 SO-DIMM support
-
Rich I/O: 4×USB 3.2, 2×USB 2.0, 2×Gigabit LAN, 2×RS-232/422/485, 8-ch GPIO
-
Wide power input: 9–36 VDC with surge protection
-
Operating temperature: –20 °C to 60 °C
-
VESA & DIN-rail mounting options
Specifications
| Specification |
Details |
| CPU |
Intel® Core™ i7-1185G7, 4C/8T, 3.0–4.8 GHz |
| Memory |
1× DDR4 SO-DIMM, up to 32 GB |
| Storage |
2× M.2 NVMe slots (2242/2280) |
| LAN |
2× Gigabit RJ45 (Intel® I210-AT) |
| USB |
4× USB 3.2 Gen1, 2× USB 2.0 |
| Serial |
1× RS-232, 1× RS-422/485 |
| GPIO |
8 channels (5 V/12 V selectable) |
| Power Input |
9–36 VDC terminal block; 18 W max |
| Enclosure |
IP50-rated aluminum, fanless |
| Dimensions |
150×102×40 mm (W×D×H) |
| Weight |
0.7 kg |
Supported OS / Applications / Industries
-
OS: Windows 10 IoT, Ubuntu LTS, Yocto Linux
-
Applications: Edge AI inference, SCADA, data acquisition, network edge computing
-
Industries: Manufacturing, utilities, transportation, smart cities, warehousing
Benefits & Compatibility
-
Zero-fan design eliminates mechanical failures
-
High-performance CPU tackles AI workloads and real-time analytics
-
Flexible I/O integrates with sensors, actuators, and legacy serial devices
-
Compact form factor simplifies deployment in tight control cabinets
-
Pairs seamlessly with Touch Dynamic Industrial PCs and IoT gateways
Purpose of Use
-
Run machine-vision inference at the line edge
-
Collect and preprocess sensor data for SCADA systems
-
Host containerized edge apps (Docker/Kubernetes)
-
Serve as a firewall/VPN gateway in harsh environments
-
Manage local HMI and operator panels
How to Use
-
Mount Orion Ultra via VESA or DIN-rail bracket.
-
Insert DDR4 SO-DIMM and M.2 SSDs.
-
Wire power (9–36 VDC) and network.
-
Connect USB or serial devices.
-
Install chosen OS image and deploy your application.
Packaging / Weight / Dimensions
-
Includes: Orion Ultra CPU module, power terminal block, mounting brackets, quick-start guide
-
Net Weight: 0.7 kg
-
Box Dimensions: 180×140×60 mm
Warranty & FAQs
Warranty: 3-year limited
FAQs:
-
Can I use ECC memory?
✔ Only non-ECC DDR4 SO-DIMMs are supported.
-
Is Wi-Fi available?
✔ Use a USB Wi-Fi adapter in one of the USB 3.2 ports.
-
Does it support RAID?
✔ RAID requires software configuration; BIOS does not support hardware RAID.
Performance, Quality, Durability & Reliability
Tested to MIL-STD-810G for shock/vibration, the Orion Ultra delivers 99.9% uptime in –20 °C to 60 °C environments. Its aluminum chassis doubles as a heatsink, ensuring stable operation under full CPU load.
Best Price Guarantee
We match any lower quote for the Orion Ultra CPU Processor—no questions asked.
Shop Today & Receive Delivery Across the UAE
Order now for fast shipping to Dubai, Abu Dhabi, Sharjah, and beyond. We handle customs and last-mile logistics for a smooth rollout.
Request for Customer Reviews and Testimonials
Deployed Orion Ultra? Share your review to help peers make data-driven decisions.
After Sales Support
Our tech team is on call via email, phone, or live chat for setup, firmware updates, and troubleshooting.
Get in Touch
Have questions about edge computing or integration? Contact our solution architects for fast, tailored guidance.
Stock Availability
Stocks update daily. For urgent orders, confirm availability before checkout. Bulk requests may need 7–10 business days.
Disclaimer
All specifications and images are for general information and may change without notice. Verify final details and pricing with our sales team before ordering.
