EMV L1 RFID MSR Contact Smart Card Reader Module for E-Payment HCC-T10-DC

EMV L1 certified RFID MSR smart card reader module for secure e-payment and identity systems. Compact, reliable & versatile. Shop NEOTECH now.

✅ Overview

Meet the NEOTECH HCC-T10-DC—an all-in-one card reader module combining EMV L1 compliance, RFID, MSR, and IC smart card support. This compact powerhouse is purpose-built for embedded e-payment terminals, ID verification kiosks, and custom POS setups. Fast, accurate, and highly secure, it’s the ideal solution for businesses building smart, scalable payment systems.

✅ Product Description

The NEOTECH HCC-T10-DC Smart Card Reader Module is engineered for next-gen payment terminals, integrating full support for RFID (13.56 MHz), magnetic stripe, and IC smart cards. It’s EMV L1 certified, ensuring globally accepted secure transaction standards. With seamless RS232 and USB connectivity, it’s developer-friendly and ready for integration into vending machines, ticketing kiosks, ATMs, and digital check-in systems.

Built for versatility and long-term reliability, it features precision reading heads, anti-vandal design, and plug-and-play software compatibility across major OS. Whether you're deploying public-facing terminals or designing secure card access systems, this device fits the bill—literally.

✅ Key Features

• EMV L1 Certified for global payment trust

• All-in-one: RFID, IC, and Magnetic Stripe (MSR) support

• 13.56 MHz RFID Reader (ISO 14443 A/B)

• Magnetic Head reads Tracks 1/2/3 (ISO 7811)

• Contact IC: ISO 7816, T=0 / T=1

• High-speed USB & RS232 interface options

• Easy firmware upgrade via software tools

• Designed for long lifecycle (500K+ operations)

• Ideal for kiosks, ATMs, access control, POS

✅ Specifications

• Standards: EMV L1, ISO 7816, ISO 7811, ISO 14443 A/B

• RFID Frequency: 13.56 MHz

• Magnetic Stripe: Bi-directional, Tracks 1/2/3

• IC Support: Contact type (T=0, T=1 protocols)

• Interface: USB 2.0 / RS232

• Power Supply: DC 5V ±5%

• Operating Temp: -10°C to +60°C

• Dimensions: 104mm x 68mm x 24mm

• Weight: 170g

✅ Supported OS / Application / Industries

• OS: Windows, Linux, Android (on request)

• Applications:

  • e-Payment Terminals

  • Public Transit Ticketing

  • ATM & Banking Systems

  • Government ID Verification

  • Vending & Kiosk Solutions

• Industries: Banking, Retail, Hospitality, Transport, Public Services

✅ Benefits & Compatibility

• Supports wide range of card types for seamless user access

• High-speed, secure card reading for frictionless checkouts

• Integrates easily into custom systems and OEM designs

• Global compatibility with secure payment protocols

• Resistant to wear and vandalism—ideal for public-facing use

✅ Purpose of Use

This module is designed to securely read RFID, MSR, and IC cards for identity verification, digital payments, and automated entry systems in embedded environments.

✅ How to Use

1. Connect via USB or RS232

2. Insert, swipe, or tap card (depending on type)

3. Device authenticates and transfers data to host system

4. LED/status confirms successful read

5. System processes ID or payment accordingly

✅ Packaging / Weight / Dimension

• What’s Included: Reader module, cables, quick-start guide

• Weight: 170g

• Size: 104 x 68 x 24 mm

• Box: Sealed anti-static packaging with foam protection

✅ Warranty and FAQs

• Warranty: 1-Year NEOTECH support

• FAQs:

  • Q: Can it support all 3 card types? Yes, RFID, IC, MSR

  • Q: Can it be integrated into POS machines? Absolutely

  • Q: Is it SDK-compatible? Yes, SDK provided for devs

For extended support, visit neodgital.com/support

✅ Performance, Quality, Durability & Reliability

Tested over 500,000 cycles, the HCC-T10-DC ensures reliable long-term use in high-traffic setups. Its stable read accuracy and rugged build make it the go-to choice for critical payment environments.

✅ Best Price Guarantee

You won’t find it cheaper in Dubai. If you do—let us know. NEOTECH offers the best tech-to-price ratio, guaranteed.

✅ Shop Today & Receive Your Delivery Across the UAE!

From Dubai to Abu Dhabi, get your smart card reader delivered fast. NEOTECH ships UAE-wide with trusted logistics. Order now—don’t wait!

✅ Request for Customer Reviews and Testimonials

Already using the HCC-T10-DC? Drop a short review. Let others know how it helped level up your payment terminal.

✅ After Sales Support

We don’t ghost you after the sale. Get full technical support from our local team via chat, phone, or email.

✅ Get in Touch

Planning a system integration or bulk purchase? Contact us. We’ll help you get it done.

✅ Stock Availability

We aim to keep this product ready-to-ship. Still, check with our team before placing high-volume or time-sensitive orders.

✅ Disclaimer

Specs, images, and pricing are subject to change without notice. Product visuals are for reference only. Please confirm all details before purchase with our sales team.
