✅ Overview

This 16-Port Industrial Unmanaged Gigabit Switch delivers high-speed, stable network performance for outdoor and industrial settings. It supports 12V/24V power input, DIN rail mounting, and is housed in a rugged IP-rated casing for long-term reliability.

✅ Product Description

The 16-Port Full Gigabit Unmanaged Industrial Switch provides plug-and-play connectivity with robust performance in outdoor and industrial environments. Designed for simplicity and endurance, it features 16x 10/100/1000 Mbps RJ45 ports, fanless cooling, and an extended operating temperature range.

This switch is ideal for environments where managed capabilities aren't required but consistent uptime is essential. With industrial-grade protections and flexible 12V/24V DC input support, it's suitable for traffic control systems, IP surveillance, and factory floors.

✅ Key Features

• 16x 10/100/1000 Mbps Auto-Negotiation RJ45 Ports

• Industrial-Grade Unmanaged Plug-and-Play Operation

• Wide Voltage Input: 12V/24V DC Supported

• Extended Temperature Range: -40°C to +75°C

• IP30-Rated Metal Housing for Outdoor/Harsh Use

• Surge & ESD Protection on All Ports

• Fanless Design with High MTBF

• DIN-Rail and Wall-Mount Options Included

✅ Specifications

• Ethernet Ports: 16x RJ45 Gigabit

• Switching Capacity: 32 Gbps

• Forwarding Rate: 23.8 Mpps

• MAC Table: 8K entries

• Power Input: 12V–24V DC (dual input, polarity-protected)

• Surge Protection: 6kV

• Mounting: DIN-Rail & Wall Mount

• Enclosure: IP30-rated Aluminum Alloy

• Operating Temp: -40°C to +75°C

• Certifications: CE, FCC, RoHS

✅ Supported OS/Application/Industries

• OS Compatibility: Plug-and-play, no configuration needed

• Applications: IP Cameras, Access Control, Outdoor Surveillance

• Industries: Traffic Monitoring, Factory Automation, Energy, Transport

✅ Benefits & Compatibility

• Delivers full Gigabit throughput with no software needed

• Powers up easily from 12V or 24V vehicle/battery/DC sources

• Built for dusty, outdoor, and vibration-heavy environments

• Works with PoE extenders (PoE not supplied)

• Compatible with industrial NVRs, gateways, and PLCs

✅ Purpose of Use

Perfect for high-density edge environments where managed switch features aren’t required. Ideal for remote sites, enclosures, field stations, and outdoor cabinets.

✅ How to Use

1. Mount securely on DIN rail or flat surface

2. Connect up to 16 Ethernet devices

3. Power the unit via 12V or 24V DC input

4. Begin immediate plug-and-play operation—no config needed

5. Monitor link status via LED indicators

✅ Packaging / Weight / Dimension

• Weight: Approx. 1.35 kg

• Dimensions: 160mm x 118mm x 45mm

• Included: Switch, Power Terminal Block, Mounting Kit, Quick Install Sheet

✅ Warranty and FAQs

• Warranty: 3-Year Manufacturer Warranty
  FAQs:

• Is this switch managed? → No, it's unmanaged and configuration-free

• Does it support PoE? → No PoE output, but compatible with PoE extenders

• Can I mount it outdoors? → Yes, inside an IP-rated enclosure or cabinet
