Versatile EloPOS Z-Series AIO POS with touchscreen, printer, scanner & MSR. Available in 10″, 15″ & 21.5″. Fanless, flexible OS. Order UAE-wide.
Overview
The EloPOS Z-Series combines display, payment and peripherals into a single, fan-free chassis. Available in 10″ (Z1), 15″ (Z3) and 21.5″ (Z5) touchscreen variants, it integrates a thermal printer, barcode scanner window, magnetic-stripe reader and optional RFID/NFC—streamlining checkout workflows in retail, hospitality and healthcare.
Product Description
Designed for speed and reliability, each Z-Series model pairs a true-flat projected-capacitive touchscreen with an efficient processor (Intel® Celeron® N-series or onboard ARM for Android), 4–8 GB of memory and 64–128 GB onboard storage. A built-in 80 mm thermal printer and omnidirectional scanner window handle receipts and barcode scanning, while a 3-track MSR slot streamlines card payments. PoE+ power and VESA mounting simplify deployment. Run Windows IoT, Android or Ubuntu for seamless integration into your POS ecosystem.
Key Features
-
Sizes: 10″ (Z1), 15″ (Z3), 21.5″ (Z5) FHD true-flat PCAP touch
-
Processing: Intel® Celeron® N5105 or ARM-based CPU (Android model)
-
Memory & Storage: 4 GB DDR4 (up to 8 GB); 64 GB eMMC–128 GB SSD
-
Printer: Built-in 80 mm direct-thermal printer, 203 dpi
-
Scanner: Omnidirectional 1D/2D barcode window
-
MSR: 3-track encrypted magnetic-stripe reader
-
Optional I/O: RFID/NFC reader, customer display, PIN pad ports
-
Connectivity: PoE+ (802.3at), dual GbE, Wi-Fi 6, BT 5.2, USB-C, 4× USB 3.2, COM
-
Design: Fanless, IP22 front; VESA 100×100 mm mount; Kensington lock
Specifications
| Spec |
Z1 (10″) |
Z3 (15″) |
Z5 (21.5″) |
| Display |
10.1″ HD PCAP |
15″ FHD PCAP |
21.5″ FHD PCAP |
| Processor |
Celeron® N5105 |
Celeron® N5105 |
Celeron® N5105 |
| RAM |
4 GB DDR4 |
4 GB DDR4 |
8 GB DDR4 |
| Storage |
64 GB eMMC |
64 GB eMMC |
128 GB SSD |
| Printer |
80 mm thermal |
80 mm thermal |
80 mm thermal |
| Scanner |
1D/2D window |
1D/2D window |
1D/2D window |
| MSR |
3-track MSR |
3-track MSR |
3-track MSR |
| Network |
PoE+, GbE, Wi-Fi6, BT5.2 |
PoE+, GbE, Wi-Fi6, BT5.2 |
PoE+, GbE×2, Wi-Fi6 |
| I/O |
USB-C, 3× USB, COM |
USB-C, 4× USB, COM |
USB-C, 4× USB, COM |
| Dimensions (W×H×D) |
260×200×30 mm |
359×245×40 mm |
532×350×50 mm |
| Weight |
~1.2 kg |
~3.5 kg |
~6 kg |
Supported OS / Applications / Industries
-
OS: Windows 10 IoT Enterprise, Android 11, Ubuntu 20.04 LTS
-
Applications: Retail POS, QSR ordering, healthcare check-in, ticketing
-
Industries: Retail, hospitality, healthcare, transportation, entertainment
Benefits & Compatibility
-
Space-Saving All-In-One: Display, payments, printing and scanning in a single terminal
-
Silent Reliability: Fanless design prevents dust and noise for 24/7 uptime
-
Easy Deployment: PoE+ power/data over one cable and VESA mount support
-
Integrated Workflow: MSR, printer, scanner and optional RFID/NFC reduce peripherals
-
Flexible Platform: Choose Windows, Android or Linux to match your software stack
Purpose of Use
Ideal for end-to-end checkout, self-ordering and kiosk scenarios where hardware consolidation, reliability and clean aesthetics drive efficiency and guest satisfaction.
How to Use
-
Mount & Power: Install via VESA bracket; connect PoE+ or DC 12 V.
-
Configure OS: Complete Windows IoT/Android/Ubuntu setup; install POS/kiosk app.
-
Attach Peripherals: All payment and scanning modules are built-in; just plug in cash drawer or PIN pad.
-
Network & Secure: Connect Ethernet or Wi-Fi; enable TPM and optional PIN-pad encryption.
-
Go Live: Launch your application—transactions, printing and scanning work out of the box.
Pro Tip: Use PoE switch remote power-cycling for hands-off maintenance.
Packaging / Weight / Dimensions
-
Includes: Z-Series unit, PoE injector (if ordered), DC adapter, VESA kit, quick-start guide
-
Package Weight:
-
Z1: ~1.8 kg
-
Z3: ~4.5 kg
-
Z5: ~7 kg
-
Box Dimensions: Vary by model; designed for safe shipping.
Warranty and FAQs
Warranty: 1-year hardware & peripherals advance replacement
FAQs:
Performance, Quality, Durability, and Reliability
Industrial-grade components, sealed thermal design and fanless cooling ensure consistent performance under continuous loads—minimizing service calls and maximizing uptime.
Best Price Guarantee
Found a lower UAE-based quote on EloPOS Z-Series? We’ll match it—no questions asked. Shop confidently with NEOTECH.
Shop Today & Receive Your Delivery Across the UAE!
Fast, secure delivery to Dubai, Abu Dhabi, Sharjah and all emirates. Bulk or project orders? Ask about priority dispatch.
Request for Customer Reviews and Testimonials
Deployed Z-Series? Share your feedback to help peers and guide our next-gen terminal designs.
After Sales Support
Our live-chat and support portal provide 24/7 technical assistance—keeping your POS network online and transactions seamless.
Get in Touch
Visit the EloPOS Z-Series product page on NEOTECH’s website to submit an inquiry—our specialists will connect with you within one business day.
Stock Availability
Inventory updates daily. For urgent or volume orders, confirm availability before checkout; lead times for custom modules may be 10–15 business days.
Disclaimer
Specifications and pricing subject to change without notice. Images are illustrative. Verify all technical and commercial details with NEOTECH before purchase.
