3inch(80mm) Thermal Printer Mechanism-ATP308

ATP308 80 mm thermal mechanism—200 mm/s, 203 dpi, auto-cutter ready, jam-free. Shop at NEOTECH.

Overview

Ramp up your self-service stations—kiosks, POS terminals, ticket booths—with the ATP308. This direct-thermal engine handles 80 mm paper, prints at 200 mm/s, and delivers 203 dpi clarity. Integrated auto-cutter and jam-free paper path ensure 24/7 uptime.

Internal Link: Browse our full Thermal Printer Mechanisms lineup.
External Link: Learn about direct-thermal printing on the IPC site.

Product Description

The ATP308 uses direct-thermal tech—no ribbons or ink required. Load an 80 mm roll on a 12.7 mm core, connect via RS232, USB 2.0, or TTL, and start printing crisp receipts or tickets in seconds. Its precision stepper motor and optimized paper path ensure smooth feeds, while the auto-cutter module delivers clean full or partial cuts on demand. Rated MTBF ≥ 35 000 hrs, it’s built for heavy-duty use.

Key Features

• 80 mm print width on a 12.7 mm core

• 200 mm/s top print speed

• 203 dpi high-resolution thermal head

• Auto-cutter ready: full or partial cuts

• RS232, USB 2.0 & TTL interfaces

• Jam-free paper path design

• Metal chassis for rugged durability

• MTBF ≥ 35 000 hrs reliability

Specifications

Supported OS / Applications / Industries

• OS: Windows, Linux, Android (via SDK)

• Apps: POS firmware, kiosk controllers, ticket printers

• Industries: Retail, Hospitality, Transportation, Vending, Self-Service

Benefits & Compatibility

• Plug-and-play via standard serial or USB

• Low maintenance: no ink & jam-resistant

• High uptime: sealed design + long MTBF

• Clean cuts: professional receipt trim

• Compact footprint: fits tight enclosures

Purpose of Use

Perfect for embedding in ATMs, self-service kiosks, vending machines, and any terminal requiring reliable 80 mm thermal output.

How to Use

1. Mount ATP308 in your device chassis

2. Connect RS232, USB, or TTL to host controller

3. Load an 80 mm thermal roll (12.7 mm core)

4. Attach optional auto-cutter module

5. Power on and send print commands via SDK

Packaging / Weight / Dimensions

• Includes: ATP308 mechanism, interface cables, mounting hardware, user manual

• Unit size: 210 × 125 × 110 mm

• Unit weight: 1.4 kg

• Package weight: ~1.7 kg

Warranty & FAQs

• Warranty: 12 months limited

• FAQs:

  • Q: Which roll sizes fit?
    A: Standard 80 mm rolls on 12.7 mm core.

  • Q: How to replace cutter blades?
    A: Snap-in blade design—see manual intervals.

  • Q: Is it dust-resistant?
    A: Sealed path resists debris.

Performance, Quality, Durability & Reliability

Built with an industrial thermal head and sealed chassis, the ATP308 delivers consistent print density, jam-free operation, and long-life performance under heavy use.

Best Price Guarantee

Found a lower price on a comparable mechanism? NEOTECH will match it—no hassle.

Shop Today & Delivery Across the UAE!

Order ATP308 now for express shipping to Dubai, Abu Dhabi, Sharjah, Ajman, and beyond. Track your order in real time.

Customer Reviews & Testimonials

Installed your ATP308? Drop a quick review on our site and help others choose smart.

After-Sales Support

Need integration tips or troubleshooting? Our UAE support team is one call or email away. If remote fixes don’t cut it, we’ll guide you through an easy RMA.

Get in Touch

For bulk quotes, custom firmware, or SDK access, contact our sales team for samples, demos, and pro advice.

Stock Availability

Confirm live inventory with our sales team before ordering—lead times may vary for cutter-enabled units.

Disclaimer

Specs, pricing, and availability subject to change without notice. Images are illustrative; actual mechanism may vary. Verify details with NEOTECH before purchase.
