Overview
NEOTECH’s Industrial Touch Panel PC 8″–18.5″ combines an embedded IPC with a sleek PCT capacitive touchscreen, engineered for control rooms, factory floors, and kiosks. Its fanless, sealed design blocks dust and moisture, delivering silent, reliable performance. Choose from five screen sizes to match any HMI, SCADA, or digital signage application. Rugged, low-maintenance, and optimized for nonstop operation in demanding environments.
Product Description
Powered by an embedded Intel® Atom™ or Celeron® processor, this touch panel PC features a true-flat, multi-touch display in sizes from 8″ to 18.5″. The IP65-rated front bezel and die-cast aluminum chassis resist water, dust, and shock. Fanless cooling ensures zero-noise operation and minimal upkeep. Rich I/O—USB, COM, LAN, audio, and optional PoE—plus modular mini-PCIe and M.2 slots let you tailor connectivity. Ideal for CNC controls, SCADA systems, POS terminals, or interactive kiosks running Windows or Linux.
Key Features
-
8″, 10″, 12″, 15″, 18.5″ PCT capacitive multi-touch panel
-
Embedded Intel® Atom™ x7-E3950 or Celeron® J3455 CPU
-
Fanless thermal design for silent, maintenance-free use
-
IP65 front panel; IP40 rear enclosure
-
Wide-range DC input (9–36 V)
-
I/O: 2×LAN, 4×USB, 2×COM, audio jack; optional PoE
-
Expansion: mini-PCIe & M.2 slots
-
Panel, VESA, or wall mounting options
Specifications
| Feature |
Details |
| Display |
8″–18.5″ PCT capacitive multi-touch |
| CPU |
Intel® Atom™ x7-E3950 / Celeron® J3455 |
| Memory |
2–8 GB DDR3L |
| Storage |
32–256 GB SSD |
| Power Input |
9–36 V DC |
| I/O Ports |
4×USB, 2×LAN, 2×COM, audio, optional PoE |
| Expansion |
1×mini-PCIe, 1×M.2 SATA |
| Protection |
Front IP65; back IP40 |
| Mounting |
Panel, VESA, wall |
| OS Support |
Windows 10 IoT Enterprise, Linux Ubuntu |
Supported OS / Applications / Industries
OS: Windows 10 IoT Enterprise, Ubuntu/Debian Linux
Applications: HMI/SCADA, CNC automation, POS kiosks, digital signage
Industries: Manufacturing, logistics, retail, energy, utilities
Benefits & Compatibility
-
Dust & water resistance boosts uptime in harsh sites
-
Silent fanless design for noise-sensitive areas
-
Modular I/O adapts to any industrial workflow
-
Wide voltage range fits variable power supplies
-
Standard drivers ensure plug-and-play on Windows/Linux
Purpose of Use
Ideal for user interfaces on assembly lines, warehouse control stations, customer self-service terminals, or real-time data displays where rugged, low-maintenance computing is critical.
How to Use
-
Cut panel opening and secure with mounting clamps.
-
Connect 9–36 V DC power and peripheral cables.
-
Install OS via USB or onboard M.2 slot.
-
Calibrate the touchscreen in your HMI software.
Tip: Use SSD storage for faster boot times in mission-critical scenarios.
Packaging / Weight / Dimensions
-
Packaging: Foam-lined, corrugated box
-
Weight: ~2.8 kg (18.5″ model)
-
Dimensions: Varies by size (e.g., 415×290×50 mm for 18.5″)
-
Includes: Power adapter, mounting kit, quick-start guide
Warranty & FAQs
Warranty: 1-year replacement warranty. RMA initiated upon issue validation.
FAQs:
-
Q: Can it run in dusty environments?
A: Yes, IP65 front and fanless design keep dust out.
-
Q: Is PoE supported?
A: Optional PoE module available for network-powered setups.
Learn more on our Support Page.
Performance, Quality, Durability & Reliability
Tested to IEC-compliant standards for vibration, shock, and temperature. Achieves 99.9% uptime in 0–50 °C without fans. SSD storage resists motion-induced errors. Built for 24/7 industrial operations.
