Elo 2202L: 22″ Full HD PCAP touchscreen with narrow bezel, bonded glass, IP54 front, USB-C video/touch/power. Ideal for retail & kiosks. Order today!
Overview
The Elo 2202L pairs a bright 22″ Full HD panel with 10-point projected-capacitive touch in an ultra-narrow-bezel design. Its bonded glass and IP54-sealed front deliver spill-proof, accurate interactions—perfect for retail checkouts, self-service kiosks, and hospitality stations.
Product Description
Built for continuous commercial use, the Elo 2202L features optical bonding that enhances contrast, eliminates internal reflections and prevents fogging. Tempered anti-glare glass protects against scratches and spills, while its PCAP sensor reads gloved or bare-finger inputs with sub-10 ms response. Connectivity options include single-cable USB-C for video, touch and up to 60 W power delivery, plus HDMI and DisplayPort with USB-A for peripherals. A VESA 100×100 mm mount ensures flexible installation on walls, stands or counters.
Key Features
-
Ultra-Narrow Bezel – Maximizes usable screen area
-
22″ Full HD – 1920×1080 resolution at 300 cd/m²
-
10-Point PCAP Touch – Fast, precise multi-touch gestures
-
Optical Bonding – Boosts contrast and removes glare
-
IP54-Sealed Front – Dust- and splash-resistant
-
USB-C Single-Cable – Video, touch and power (60 W PD)
Specifications
| Specification |
Details |
| Display |
22″ TFT LCD, 1920×1080 (16:9) |
| Touch Technology |
Projected-capacitive, 10-point multi-touch |
| Brightness |
300 cd/m² |
| Contrast Ratio |
1000:1 |
| Viewing Angles |
178° H / 178° V |
| Glass |
4 mm bonded, anti-glare tempered |
| Front Seal |
IP54 |
| Video Inputs |
USB-C ×1 (video/touch/PD), HDMI 1.4 ×1, DP 1.2 ×1 |
| USB Ports |
USB-A ×2 |
| Mounting |
VESA 100×100 mm |
| Dimensions (W×H×D) |
511 × 327 × 47 mm |
| Weight |
4.5 kg |
| Power |
100–240 VAC in; USB-C PD out up to 60 W |
| Operating Temp |
0 °C – 40 °C |
Supported OS / Applications / Industries
-
OS Compatibility: Windows, Linux, Android (HID-compliant)
-
Applications: POS terminals, self-service kiosks, digital signage, wayfinding
-
Industries: Retail, hospitality, healthcare, banking, transport
Benefits & Compatibility
-
Rapid Deployment: USB-C single-cable cuts install time
-
Low Maintenance: Sealed glass front resists spills and dust
-
Engaging UX: True multi-touch fosters customer self-service
-
Versatile Mounting: Fits any VESA 100×100 bracket or stand
Purpose of Use
Ideal for:
-
High-volume retail checkouts & line-busting
-
Table-side ordering in cafés & restaurants
-
Patient check-in in clinics & hospitals
-
Interactive directories and information kiosks
How to Use
-
Mount via VESA 100×100 bracket or compatible stand
-
Connect USB-C for video, touch, and power—optionally HDMI/DP + USB-A
-
Calibrate touch via your OS settings if needed
-
Launch your POS, kiosk, or signage application
Packaging / Weight / Dimension
-
Includes: Elo 2202L monitor, power adapter, USB-C cable, HDMI cable, quick-start guide
-
Packed Weight: 6.0 kg
-
Box Size: 580 × 380 × 140 mm
Warranty and FAQs
FAQs:
-
Can I rotate to portrait? Yes—supports 90° rotation via VESA mount.
-
Is it glove-compatible? Yes; PCAP reads through gloves.
-
Does USB-C power the unit? Yes, up to 60 W PD over USB-C.
Performance, Quality, Durability & Reliability
Tested for 24/7 operation, the Elo 2202L meets ISO 9241-307 for touch durability and MIL-STD-810G for shock. Optical bonding prevents condensation and ghost touches, ensuring consistent performance in busy environments.
Best Price Guarantee
Found a lower UAE price on the Elo 2202L? We’ll match it—guaranteed. Get enterprise-grade reliability at the best value.
Shop Today & Receive Your Delivery Across the UAE!
Enjoy next-day shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates. Secure checkout and live tracking ensure on-time delivery.
Request for Customer Reviews and Testimonials
Deploying Elo 2202L in your business? Share your experience to guide others. Submit a review
After Sales Support
From installation guidance to firmware updates, Elo experts are on call via email, phone, or live chat—keeping your touchscreen fully operational.
Get in Touch
Need deployment advice or volume quotes? Contact our Elo specialists for tailored solutions and rapid responses.
Stock Availability
Stocks update daily. For urgent orders, confirm availability with our sales team before checkout. Custom bezel or glass options may require 7–10 business days.
Disclaimer
All specifications and pricing are for general informational purposes and subject to change without notice. Product images are illustrative. Verify final details with our sales team before ordering.
