Rugged Elo I-Series 5 Steel 15″ touch PC – Intel® Core™, PoE+, IP54 front, MSR, RFID, USB-C. Ideal for retail, hospitality. Order UAE-wide.
Overview
The Elo Touch I-Series 5 Steel combines industrial-grade durability with high-performance computing in a sleek 15″ all-in-one. Its stainless-steel chassis, IP54-rated front and fanless design ensure reliable operation in demanding retail, hospitality and healthcare environments—while its modular I/O lets you tailor peripherals to your workflow.
Product Description
Powered by a choice of Intel® Core™ i3/i5 processors, 8 GB DDR4 and a 128 GB SSD (expandable), the I-Series 5 Steel delivers instant-on responsiveness for point-of-sale, wayfinding or self-service applications. Its true-flat PCAP touchscreen, integrated magnetic-stripe reader (MSR), optional RFID/NFC reader and customer-facing display streamline transactions. PoE+ support, USB-C power delivery and VESA mounting simplify installation, while Windows 10 IoT or Ubuntu provide flexible software options.
Key Features
-
Industrial Chassis: Brushed stainless-steel front panel; IP54 water/dust protection
-
Fanless Performance: Intel® Core™ i3/i5 (10th Gen) up to 3.6 GHz; silent, dust-proof operation
-
Interactive Display: 15″ Full HD (1920×1080) PCAP, 10-point multi-touch
-
Modular I/O: Built-in 3-track MSR, optional RFID/NFC, customer display, printer port
-
Connectivity: PoE+ (802.3at), GbE, Wi-Fi 6, Bluetooth 5.1, USB-C PD, 4× USB 3.2, COM ports
-
Secure Boot: TPM 2.0, Kensington lock slot, tamper-resistant enclosure
-
Flexible OS: Pre-loaded Windows 10 IoT Enterprise or Ubuntu 20.04 LTS
Specifications
| Specification |
Detail |
| CPU Options |
Intel® Core™ i3-10110U (2C/4T) or i5-10210U (4C/8T) |
| Memory |
8 GB DDR4-2666 (expandable to 16 GB) |
| Storage |
128 GB SSD; M.2 slot for NVMe expansion |
| Display |
15″ FHD (1920×1080), PCAP, 10-point touch |
| I/O |
MSR, optional RFID/NFC, customer VFD, printer RJ-11 |
| Ports |
PoE+ (802.3at), 2× GbE, Wi-Fi 6, BT 5.1, USB-C PD, 4× USB 3.2, 2× RS-232 |
| Audio/Video |
HDMI-out, line-out, integrated speaker |
| Security |
TPM 2.0, Kensington lock |
| Mounting |
VESA 100×100 mm; tabletop stand |
| Dimensions (W×H×D) |
353 × 272 × 42 mm |
| Weight |
~4.5 kg |
| Operating Temp. |
0–40 °C |
Supported OS / Applications / Industries
-
Operating Systems: Windows 10 IoT Enterprise, Ubuntu 20.04 LTS
-
Applications: POS checkout, self-service kiosks, digital signage, patient check-in
-
Industries: Retail, hospitality, healthcare, transportation, industrial
Benefits & Compatibility
-
Durable Design: Steel front and IP54 rating guard against spills and dust
-
Simplified Cabling: PoE+ and USB-C PD reduce cord clutter and enable remote power cycling
-
Modular Expansion: Add MSR, RFID, customer display or printer interface as needed
-
Quiet Operation: Fanless cooling ensures silent 24/7 uptime in customer-facing areas
-
Enterprise Integration: TPM security and VESA mounting support secure deployments
Purpose of Use
Ideal for high-traffic, mission-critical environments: seamless POS transactions, secure visitor check-ins, intuitive wayfinding and interactive signage—where reliability and hygiene are paramount.
How to Use
-
Install Mount: Attach to wall or stand via VESA bracket.
-
Connect Power: Use PoE+ or USB-C PD for data and power over one cable.
-
Attach Peripherals: Plug in MSR, RFID or customer display modules into side I/O.
-
Configure Network: Connect GbE or set up Wi-Fi/Bluetooth profiles.
-
Deploy OS & Apps: Use pre-installed Windows IoT or Ubuntu; install your retail or kiosk software.
Pro Tip: Leverage PoE switch management for remote reboot and firmware updates.
Packaging / Weight / Dimensions
-
Includes: I-Series 5 Steel unit, wall/stand mount, PoE injector (if ordered), quick-start guide
-
Package Weight: ~6 kg
-
Box Dimensions: 420 × 360 × 150 mm
Warranty and FAQs
Warranty: 2-year advance replacement for unit and peripherals.
FAQs:
Performance, Quality, Durability, and Reliability
Combining industrial-grade Intel® CPUs, stainless-steel construction and fanless cooling, the I-Series 5 Steel delivers consistent performance even under continuous loads—maintaining uptime and reducing service calls.
Best Price Guarantee
Found a lower UAE-based quote on the Elo I-Series 5 Steel? We’ll match it—no questions asked. Shop confidently with NEOTECH.
Shop Today & Receive Your Delivery Across the UAE!
Enjoy fast, secure delivery to Dubai, Abu Dhabi, Sharjah and all emirates. Bulk or project orders? Ask about priority dispatch.
Request for Customer Reviews and Testimonials
Deployed Elo I-Series 5 Steel? Share your story to help peers and shape our next-gen solutions.
After Sales Support
Our live-chat and support portal provide 24/7 technical assistance—keeping your terminals responsive and your operations running smoothly.
Get in Touch
Visit our Elo I-Series 5 Steel product page on NEOTECH’s website to submit an inquiry—our experts will connect with you within one business day.
Stock Availability
Inventory updates daily. For urgent or volume orders, confirm availability before checkout; lead times for custom modules may be 10–15 business days.
Disclaimer
Specifications and pricing subject to change without notice. Images are illustrative. Verify all technical and commercial details with NEOTECH before purchase.
