Overview
The Elo 1564L pairs a crisp 15″ HD panel with 10-point projected-capacitive (PCAP) touch in an 18 mm open-frame chassis. Built for OEMs and system integrators, it snaps into kiosks, ticketing terminals, and embedded applications. Its fanless, passive-cooling design and edge-to-edge tempered glass deliver silent, 24/7 reliability.
Product Description
Purpose-built for continuous, high-traffic use, the 1564L features a 1366×768 IPS display and drift-free PCAP sensor that works with fingers, gloves, or stylus. Standard HDMI and VGA video inputs plus USB touch I/O make setup plug-and-play. The slim metal housing supports bezel, faceplate, or rear-mount kits without adding bulk. Say goodbye to external boxes—everything you need is built in.
Key Features
-
15″ HD (1366×768) IPS panel
-
10-point projected-capacitive multi-touch
-
Edge-to-edge tempered, anti-glare safety glass
-
Slim 18 mm open-frame metal chassis
-
HDMI 1.4 & VGA video inputs
-
USB 2.0 touch interface (plug-and-play)
-
VESA 100×100 mm mounting pattern
-
Fanless, passive-cooling design for silent 24/7 use
Specifications
| Specification |
Details |
| Display Size |
15″ diagonal |
| Resolution |
1366×768 (HD) |
| Touch Technology |
10-point PCAP (USB 2.0) |
| Brightness |
350 cd/m² |
| Contrast Ratio |
1000:1 |
| Viewing Angle |
178° H / 178° V |
| Video Inputs |
HDMI 1.4, VGA (DB-15) |
| Touch I/O |
USB 2.0 Type B |
| Mounting |
VESA 100×100 mm, flush-mount kits |
| Power Input |
5 V DC via USB (optional adapter) |
| Operating Temp. |
0 °C to 50 °C |
| Weight |
~2.4 kg (unpackaged) |
Supported OS / Applications / Industries
OS Compatibility: Windows, macOS, Linux (plug-and-play via HDMI/USB)
Applications: Self-service kiosks, POS stations, wayfinding, ticketing, digital menu boards
Industries: Retail, hospitality, healthcare, transportation, manufacturing
Benefits & Compatibility
-
Modular Integration: Open-frame design adapts to any bezel or enclosure
-
Silent Operation: Passive cooling vents eliminate fan noise
-
Durable Surface: Tempered glass resists scratches and spills
-
Plug-and-Play I/O: Standard HDMI/VGA and USB for fast deployment
-
Fleet Management: Compatible with EloView® for remote monitoring
Purpose of Use
Ideal for OEMs and integrators, the Elo 1564L transforms standard chassis into interactive experiences. It excels in self-service kiosks, ticketing terminals, and embedded HMIs where uptime and reliability are mission-critical.
How to Use
-
Mount via VESA 100×100 mm or flush-mount kit.
-
Connect HDMI or VGA for video.
-
Plug USB for touch data.
-
Power via USB port or optional 5 V DC adapter.
-
Calibrate touch with Elo Touch Tools if needed.
Packaging / Weight / Dimensions
-
Unit Weight: ~2.4 kg
-
Carton Size: 520 × 360 × 120 mm
-
Includes: 1564L display, HDMI & USB cables, mounting brackets, quick-start guide
Warranty and FAQs
Warranty: 1-year limited hardware; extensions up to 3 years available.
FAQs:
-
Q: Can it detect gloved touch?
A: Yes, PCAP supports gloves and stylus.
-
Q: Is it suitable for 24/7 use?
A: Yes, passive-cooling design enables continuous operation.
-
Q: How to protect against dust?
A: Use sealed bezel kits for full environmental protection.
Performance, Quality, Durability & Reliability
Constructed with industrial-grade aluminum and ANSI-rated tempered glass, the 1564L withstands shock, vibration, and heavy use. Passive vents maintain optimal temperature, while rigorous burn-in testing guarantees mission-critical uptime.
