Modular EloPOS Z-Series AIO POS: touchscreen, thermal printer, scanner, MSR & PoE+. Sleek, fanless design for retail. Order UAE-wide.
Overview
EloPOS Z-Series is a next-gen, modular point-of-sale platform designed for dynamic retail environments. With true-flat projected-capacitive touchscreens in 10″, 15″ or 21.5″ sizes, integrated receipt printing, barcode scanning and magnetic-stripe reading, it consolidates every checkout function into one silent, fanless chassis.
Product Description
At the heart of Z-Series is a choice of Intel® Celeron® N-series CPUs (or ARM for Android models), 4–8 GB memory and 64–128 GB storage. An 80 mm direct-thermal printer, omnidirectional barcode window and encrypted 3-track MSR slot handle receipts, scanning and card payments without extra peripherals. Snap-in modules (RFID/NFC, customer display) let you swap I/O on the fly. PoE+ power/data and VESA-mount versatility make installation a breeze. Run Windows IoT, Android or Ubuntu with pre-certified drivers for true plug-and-play.
Key Features
-
Modular Peripherals: Hot-swap MSR, barcode, RFID/NFC and customer-display modules
-
Fanless Chassis: Silent operation, zero dust ingress, 24/7 uptime
-
PoE+ Power & Data: Single-cable deployment reduces clutter
-
Multi-Size Touch: 10″, 15″ or 21.5″ FHD PCAP touchscreens with 10-point support
-
High-Efficiency CPUs: Intel® Celeron® N5105 or ARM-based processors for Android
-
Integrated I/O: 80 mm printer, scanner window and 3-track MSR included
-
Secure & Managed: TPM 2.0, secure boot and Kensington lock slot
Specifications
| Model |
Z1 (10″) |
Z3 (15″) |
Z5 (21.5″) |
| Display |
10.1″ HD PCAP |
15″ FHD PCAP |
21.5″ FHD PCAP |
| CPU |
Celeron® N5105 |
Celeron® N5105 |
Celeron® N5105 |
| Memory |
4 GB DDR4 |
4 GB DDR4 |
8 GB DDR4 |
| Storage |
64 GB eMMC |
64 GB eMMC |
128 GB SSD |
| Printer |
80 mm direct-thermal |
80 mm direct-thermal |
80 mm direct-thermal |
| Scanner |
1D/2D window |
1D/2D window |
1D/2D window |
| MSR |
3-track encrypted |
3-track encrypted |
3-track encrypted |
| Network |
PoE+, GbE, Wi-Fi 6, BT 5.2 |
PoE+, GbE, Wi-Fi 6, BT 5.2 |
PoE+, Dual GbE, Wi-Fi 6, BT 5.2 |
| I/O |
USB-C, 3× USB, COM |
USB-C, 4× USB, COM |
USB-C, 4× USB, COM |
| Dimensions (W×H×D) |
260×200×30 mm |
359×245×40 mm |
532×350×50 mm |
| Weight |
~1.2 kg |
~3.5 kg |
~6 kg |
| Front Protection |
IP22 |
IP22 |
IP22 |
Supported OS / Applications / Industries
-
Operating Systems: Windows 10 IoT Enterprise, Android 11, Ubuntu 20.04 LTS
-
Applications: Retail POS, quick-service ordering, loyalty kiosks, ticketing
-
Industries: Retail, hospitality, healthcare, transportation, entertainment
Benefits & Compatibility
-
All-In-One Efficiency: Consolidates printing, scanning and payment in one unit
-
Zero-Noise Operation: Fanless design for silent, reliable 24/7 service
-
Future-Ready Modularity: Swap or upgrade peripherals without downtime
-
Simplified Cabling: PoE+ delivers power and network over a single Ethernet link
-
Cross-Platform Flexibility: Certified for Windows, Android and Linux
Purpose of Use
Ideal for end-to-end checkout, self-ordering and kiosk scenarios where hardware consolidation, reliability and clean aesthetics drive customer satisfaction and operational efficiency.
How to Use
-
Mount & Power: Install via VESA; connect PoE+ or DC 12 V.
-
Configure OS: Complete your chosen OS setup; install POS/kiosk software.
-
Snap-In Modules: Insert MSR, scanner or RFID/NFC modules as needed.
-
Network & Secure: Plug in Ethernet or configure Wi-Fi/Bluetooth; enable TPM.
-
Go Live: Boot in seconds and start transactions.
Pro Tip: Use PoE switch management for remote reboot and firmware updates.
Packaging / Weight / Dimensions
-
Includes: Z-Series unit, PoE injector (optional), DC adapter, VESA kit, quick-start guide
-
Package Weight:
-
Z1: ~1.8 kg
-
Z3: ~4.5 kg
-
Z5: ~7 kg
Warranty and FAQs
Warranty: 1-year advance-replacement on all hardware and modules.
FAQs:
Performance, Quality, Durability, and Reliability
Industrial-grade internals, sealed thermal design and fanless cooling ensure consistent performance under continuous loads—minimizing service calls and maximizing uptime.
Best Price Guarantee
Spotted a lower UAE-based quote on EloPOS Z-Series? We’ll match it—no questions asked. Shop confidently with NEOTECH.
Shop Today & Receive Your Delivery Across the UAE!
Fast, secure delivery to Dubai, Abu Dhabi, Sharjah and all emirates. Bulk or project orders? Ask about priority dispatch.
Request for Customer Reviews and Testimonials
Deployed Z-Series? Share your feedback to help peers and guide our next-gen terminal designs.
After Sales Support
Our live-chat and support portal provide 24/7 technical assistance—keeping your POS network online and transactions seamless.
Get in Touch
Visit the EloPOS Z-Series product page on NEOTECH’s website to submit an inquiry—our specialists will connect with you promptly.
Stock Availability
Inventory updates daily. For urgent or volume orders, confirm availability before checkout; lead times for custom module configurations may be 10–15 business days.
Disclaimer
Specifications and pricing subject to change without notice. Images are illustrative. Verify all technical and commercial details with NEOTECH before purchase.
