Elo 1517L: 15″ Full HD PCAP touch with built-in barcode scanner, HD webcam & speakers, bonded glass, IP54 front, USB-C video/touch/power. Order today!
Overview
The Elo 1517L Multifunction unites a 15″ Full HD projected-capacitive touchscreen with an integrated 2D barcode scanner, 1080p webcam, and stereo speakers—all in a sleek zero-bezel, IP54-sealed front. Its edge-to-edge bonded glass delivers spill-proof, glove-friendly interaction, making it ideal for retail POS, self-service kiosks, healthcare check-in, and hospitality counters.
Product Description
Engineered for nonstop commercial use, the Elo 1517L features optical bonding for peak contrast and anti-glare performance. A 10-point PCAP sensor reads gloved or bare-finger taps in under 10 ms. The omnidirectional 2D scanner streamlines checkout and inventory tasks, while the 1080p webcam and dual 2 W speakers enable video assistance and audio prompts. A single USB-C cable carries video, touch, scanner data, audio, and up to 60 W of power. Legacy devices connect via HDMI, DisplayPort, and USB-A ports. VESA 75×75 mm mounting makes installation on arms, stands, or counters effortless.
Key Features
-
15″ Full HD Display – 1920×1080 at 300 cd/m² for crisp visuals
-
10-Point PCAP Touch – Fast, precise multi-touch gestures
-
Integrated 2D Scanner – Omnidirectional barcode capture for rapid scanning
-
Built-in Webcam – 1080p HD for video assistance and tele-service
-
Stereo Speakers – Dual 2 W audio for clear prompts
-
Optical Bonding – Enhanced contrast with no internal haze
-
IP54-Sealed Front – Dust and splash protection in heavy-traffic areas
-
Single-Cable USB-C – Video, touch, scanner, audio & power (60 W PD)
Specifications
| Specification |
Details |
| Display Size |
15″ diagonal TFT LCD |
| Resolution |
1920×1080 (16:9) |
| Touch Technology |
Projected-capacitive, 10 simultaneous touches |
| Scanner |
Omnidirectional 2D barcode imager |
| Webcam |
1080p HD |
| Speakers |
Dual 2 W stereo |
| Brightness |
300 cd/m² |
| Contrast Ratio |
1000 : 1 |
| Viewing Angles |
178° H × 178° V |
| Glass |
4 mm bonded, anti-glare tempered |
| Front Protection |
IP54 |
| Video Inputs |
USB-C ×1 (video/touch/scanner/audio/PD), HDMI ×1, DP ×1 |
| USB Ports |
USB-A ×2 |
| Audio I/O |
USB-C audio, 3.5 mm headset jack |
| Mounting |
VESA 75×75 mm |
| Dimensions (W×H×D) |
370 × 280 × 45 mm |
| Weight |
3.0 kg |
| Power |
100–240 VAC in; USB-C PD out up to 60 W |
| Operating Temp |
0 °C – 40 °C |
Supported OS / Applications / Industries
-
OS Compatibility: Windows, Linux, Android (HID-compliant)
-
Applications: POS checkout, self-service kiosks, tele-health stations, inventory management
-
Industries: Retail, hospitality, healthcare, logistics, banking
Benefits & Compatibility
-
All-in-One Efficiency: Touch, scan, video & audio in one device
-
Rapid Deployment: USB-C single-cable minimizes setup time and cable clutter
-
Hygienic & Durable: Bonded glass and sealed front simplify cleaning protocols
-
Versatile Integration: Rich I/O mix supports both new and legacy peripherals
Purpose of Use
Ideal for:
-
Fast retail checkouts and line-busting stations
-
Self-order kiosks in cafés, restaurants & hotels
-
Patient check-in and tele-medicine kiosks in clinics
-
Inventory scanning and information desks
How to Use
-
Mount via VESA 75×75 mm bracket or place on a compatible stand.
-
Connect USB-C for video, touch, scanner, audio & power; or HDMI/DP + USB-A + audio jack.
-
Calibrate touch via your OS settings if needed.
-
Launch your POS, kiosk UI or tele-service application.
Packaging / Weight / Dimensions
-
Includes: Elo 1517L monitor, power adapter, USB-C cable, HDMI cable, quick-start guide
-
Packed Weight: 4.2 kg
-
Box Size: 460 × 330 × 120 mm
Warranty and FAQs
FAQs:
-
Can the scanner operate standalone? Yes—scanner data streams over USB-C as HID input.
-
Is the webcam removable? No—it’s integrated for consistent alignment.
-
Does audio output via external devices? Yes—through 3.5 mm jack or USB-C.
Performance, Quality, Durability & Reliability
Tested for 24/7 operation; backlight uniformity ± 5 %, IK06 impact rating, and IP54 sealing ensure dependable performance under heavy use.
