L2 Gigabit Managed Industrial Network Switch 10/100/1000M 4 Port Ethernet with 2 SFP Uplink Ring Network Redundant

4-port L2 industrial switch with 2 SFP uplinks, ring network redundancy & rugged design. Buy now at NEOTECH. Fast UAE-wide delivery available.

✅ Overview

This L2 Gigabit Managed Industrial Switch offers 4x 10/100/1000M Ethernet ports and 2x SFP uplink slots with advanced ring redundancy, ideal for stable and secure industrial networking applications. Built to last, it delivers reliable, real-time communication even in challenging environments.

✅ Product Description

Designed for industrial automation and high-availability networks, this Layer 2 Managed Gigabit Switch supports real-time redundancy via ring protocols like ERPS or STP/RSTP. The switch provides 4x RJ45 Gigabit Ethernet ports and 2x SFP uplink ports, delivering flexible deployment across copper and fiber infrastructures.

With full web-based, CLI, and SNMP management, VLAN support, QoS, IGMP snooping, and robust security features, this unit ensures seamless network performance. Its rugged metal case, DIN rail mounting, and wide voltage/power tolerance make it suitable for factories, automation lines, and surveillance networks.

✅ Key Features

• 4x 10/100/1000 Mbps RJ45 Ports

• 2x 1G SFP Uplink Slots (LC, SX/LX Supported)

• Layer 2 Managed with SNMP/Web/CLI Control

• Ring Redundancy (ERPS, STP, RSTP)

• VLAN, QoS, IGMP Snooping, Port Mirroring

• Redundant Power Input (12–58V DC)

• Fanless, DIN-Rail Mountable, Industrial Design

• Operating Temp: -40°C to +75°C

✅ Specifications

• Switching Capacity: 12 Gbps

• Forwarding Rate: 8.93 Mpps

• MAC Table: 8K entries

• Jumbo Frame Support: Yes (9K)

• VLANs: Up to 256 VLAN IDs

• Power Input: Dual DC 12~58V (Reverse Polarity Protected)

• Mounting: DIN-Rail & Wall Mount

• Housing: IP30-rated Aluminum

• Protection: Surge 6kV, ESD 6kV

• Certifications: CE, FCC, RoHS

✅ Supported OS/Application/Industries

• OS Compatibility: Web UI-based, CLI, SNMP v1/v2c/v3

• Applications: Ring Topology Redundant Networks, IP Surveillance, Industrial Automation

• Industries: Transportation, Power Grid, Oil & Gas, Smart Factories, Utilities

✅ Benefits & Compatibility

• Keeps network online via ring failover under 20ms

• Easily integrates with SCADA, HMI, PLC systems

• Fiber SFP slots allow for long-distance, interference-free connections

• Secure traffic segmentation with VLAN and QoS

• Remote management from any browser

✅ Purpose of Use

Built for rugged environments needing fail-safe Ethernet redundancy, this switch is perfect for field monitoring, rail networks, and industrial control panels.

✅ How to Use

1. Mount the switch securely on a DIN rail

2. Connect endpoint devices to RJ45 ports

3. Use SFP ports for fiber uplinks or ring topology

4. Configure via web UI or SNMP for VLAN, redundancy & QoS

5. Monitor network live via SNMP or browser

✅ Packaging / Weight / Dimension

• Weight: Approx. 0.95 kg

• Size: 135mm x 105mm x 40mm

• Included: Switch Unit, Power Terminal Block, DIN Kit, User Manual

✅ Warranty and FAQs

• Warranty: 3-Year Manufacturer Warranty
  FAQs:

• Does this support ERPS for ring topology? → Yes

• Is fiber hot-swappable? → Yes, with compatible SFP modules

• Is PoE available? → No, this model does not offer PoE output

🔗 Visit our Industrial Switch Support

✅ Performance, Quality, Durability, and Reliability

With wide operating temperature, fanless reliability, and ring network support, this unit ensures network uptime and resilience in the most demanding industrial settings.

✅ Best Price Guarantee

NEOTECH offers competitive UAE pricing. Find it cheaper elsewhere from an authorized supplier? We’ll match it and provide added support.

✅ Shop Today & Receive Your Delivery Across the UAE!

We deliver fast to Dubai, Abu Dhabi, Sharjah, and all Emirates. Same-day shipping for in-stock models.

✅ Request for Customer Reviews and Testimonials

Used this switch in a ring network or automation panel? Share your experience and help others deploy with confidence.

✅ After Sales Support

We provide full lifecycle support—remote configuration help, firmware updates, and ring network design consultation.

✅ Get in Touch

Need compatibility help or project pricing?
📞 Connect with NEOTECH

✅ Stock Availability

Confirm current stock levels before placing an order. Bulk or custom orders: 10–15 business day lead time.

✅ Disclaimer

Specs and design may change without notice. Confirm details with NEOTECH before final purchase.
