HCC-EU80 80mm kiosk thermal printer with USB and serial ports. High-speed, 8 dots/mm resolution. Built for kiosks & terminals. Fast UAE delivery.
✅ Overview
The HCC-EU80 Thermal Kiosk Printer is a compact, high-speed solution for ticketing, receipt generation, and automated terminals. With support for 80mm thermal paper, 8 dots/mm resolution, and dual interface (USB + Serial), it ensures clean, fast, and stable printing in embedded applications.
✅ Product Description
The HCC-EU80 is a high-performance embedded kiosk printer module designed for self-service systems, vending kiosks, and smart terminals. Offering 8 dots/mm (203dpi) resolution and support for standard ESC/POS commands, it delivers reliable and crisp thermal output for text, logos, barcodes, and 2D codes.
The printer features both USB and RS232 serial interfaces, ensuring flexible integration into a wide range of industrial or OEM hardware. Engineered for space-sensitive kiosk environments, it includes front-loading paper design, high-speed printing, and automatic cutting options to meet continuous usage demands.
✅ Key Features
-
🖨️ 80mm Thermal Paper Width – Full-size ticket and receipt output
-
📏 8 Dots/mm Resolution – 203dpi sharpness for professional print clarity
-
🔌 USB + Serial Interfaces – Flexible integration with PCBs and terminals
-
🧠 ESC/POS Compatible – Seamlessly integrates with POS/kiosk software
-
✂️ Auto Cutter Support – Full or partial cut after each transaction
-
📦 Compact Embedded Design – Optimized for small kiosk spaces
-
⚡ Fast Printing – Designed for high-throughput kiosks
✅ Specifications
-
Print Technology: Direct Thermal
-
Resolution: 8 dots/mm (203dpi)
-
Print Speed: Up to 220mm/sec
-
Paper Width: 80mm
-
Print Width: Max 72mm
-
Interfaces: USB, RS232 Serial
-
Command Set: ESC/POS
-
Cutter: Auto cutter (optional based on model)
-
Dimensions: 140 x 130 x 100 mm
-
Weight: Approx. 1.2 kg
✅ Supported OS / Applications / Industries
-
Operating Systems: Windows, Linux
-
Applications: Self-service kiosks, ticket printers, POS vending terminals
-
Industries: Public Transport, Healthcare, Retail, Banking, Hospitality
✅ Benefits & Compatibility
-
🔄 Integrates with Arduino, Raspberry Pi, SBCs, and PC-based terminals
-
🔌 Dual interface ensures versatile hardware pairing
-
🧾 Supports standard 80mm thermal rolls (easy replacement)
-
🧠 ESC/POS support allows plug-and-play integration with POS frameworks
-
📲 Supports QR code, logo, barcode, and multilingual text printing
✅ Purpose of Use
Built for self-service ticketing, order confirmation, queue management, and ATM-style kiosks requiring consistent thermal printing with minimal maintenance.
✅ How to Use
-
Mount the module into kiosk frame or vending unit
-
Connect via USB or RS232 to host board
-
Load 80mm thermal roll (auto-feed available)
-
Use POS or embedded control software with ESC/POS commands
-
Output prints instantly with optional auto-cut function
✅ Packaging / Weight / Dimension
-
Weight: 1.2 kg
-
Dimensions: 140 x 130 x 100 mm
-
What’s Included: Printer module, cables, thermal paper roll (sample), driver/manual
-
Box Type: Anti-static, OEM-ready secure packaging
✅ Warranty and FAQs
Warranty: 12-month coverage for hardware components
FAQs:
-
Can it print QR codes? Yes
-
Does it work with Raspberry Pi? Yes, using USB or serial pins
-
Is an auto cutter included? Available based on model variant
For help, visit our NEOTECH Support Page
✅ Performance, Quality, Durability, and Reliability
Engineered for 24/7 usage, the HCC-EU80 performs reliably under high-throughput conditions, with clean output, minimal paper jams, and long print head life.
✅ Best Price Guarantee
Get the lowest price in the UAE for HCC-EU80. We match verified quotes and offer bulk pricing for OEM orders.
✅ Shop Today & Receive Your Delivery Across the UAE!
Fast dispatch to Dubai, Sharjah, Abu Dhabi, and all UAE cities. Secure packaging ensures safe arrival to your development center or integration site.
✅ Request for Customer Reviews and Testimonials
Already using the HCC-EU80 in your kiosk or device? Share your experience to help others choose confidently.
✅ After Sales Support
We provide integration support, wiring guidance, ESC/POS troubleshooting, and driver help post-purchase. NEOTECH is committed to your success.
✅ Get in Touch
Need tech specs or interface recommendations? Contact our team via the NEOTECH Contact Page.
✅ Stock Availability
Standard models are in stock. Custom or high-volume orders may require 10–15 business days. Please confirm availability before placing large orders.
✅ Disclaimer
Specs, pricing, and configuration are subject to change without notice. Always verify compatibility and technical requirements with NEOTECH before purchase.
