Elo 1004L: 10″ 1280×800 PCAP touchscreen with edge-to-edge glass, IP54 front seal, USB-C video/touch/power. Compact, robust for POS & kiosks. Order now!
Overview
The Elo 1004L packs a 10″ 1280×800 Full HD panel and 10-point projected-capacitive touch into a zero-bezel frame. Its bonded, anti-glare glass and IP54-rated front keep out dust and spills. That makes it ideal for retail counters, compact kiosks and bedside hospitality stations.
Product Description
Built for nonstop commercial use, the Elo 1004L features optical bonding that boosts contrast and eliminates reflections. The tempered glass surface resists scratches and liquids. A fast PCAP sensor reads bare-finger or gloved touches under 10 ms. Connect via USB-C for video, touch and up to 60 W power delivery, or use HDMI/DisplayPort plus USB-A for legacy gear. Install on any VESA 75×75 mm mount—wall, stand or countertop.
Key Features
-
10″ 1280×800 Display – Sharp text and vivid graphics
-
10-Point PCAP Touch – Smooth, precise multi-touch gestures
-
Optical Bonding – No internal glare, higher contrast
-
IP54-Sealed Front – Dust and splash resistant
-
Zero-Bezel Design – Maximum usable screen area
-
USB-C Single-Cable – Video, touch and power (60 W PD)
Specifications
| Spec |
Details |
| Display |
10″ TFT LCD, 1280×800 (16:10) |
| Touch Tech |
Projected-capacitive, 10-point |
| Brightness |
300 cd/m² |
| Contrast Ratio |
1000 : 1 |
| Viewing Angles |
170° H × 170° V |
| Glass |
4 mm bonded, anti-glare tempered |
| Front Seal |
IP54 |
| Video I/O |
USB-C ×1 (video/touch/PD), HDMI ×1, DP ×1 |
| USB Ports |
USB-A ×2 |
| Mounting |
VESA 75×75 mm |
| Dimensions (W×H×D) |
258 × 180 × 35 mm |
| Weight |
1.2 kg |
| Power |
100–240 VAC in; USB-C PD out up to 60 W |
| Operating Temp |
0 °C – 40 °C |
Supported OS / Applications / Industries
-
OS: Windows, Linux, Android (HID-compliant)
-
Apps: POS terminals, self-service kiosks, digital signage
-
Industries: Retail, hospitality, healthcare, banking, transportation
Benefits & Compatibility
-
Fast Setup: Single USB-C cable cuts install time
-
Durable Operation: Sealed front and bonded glass minimize maintenance
-
Engaging UX: True multi-touch fosters self-service adoption
-
Flexible Deployment: VESA mount fits walls, stands or carts
Purpose of Use
Ideal for:
-
Compact retail checkouts & line-busting
-
Table-side ordering in cafés & restaurants
-
Patient check-in stations in clinics & hotels
-
Interactive directories and wayfinding kiosks
How to Use
-
Mount via VESA 75×75 mm bracket or countertop stand.
-
Connect USB-C for video, touch & power—or HDMI/DP + USB-A.
-
Calibrate touch in your OS if needed.
-
Launch your POS, kiosk or signage application.
Packaging / Weight / Dimensions
-
Includes: Elo 1004L monitor, power adapter, USB-C cable, HDMI cable, quick-start guide
-
Packed Weight: 1.6 kg
-
Box Size: 320 × 240 × 120 mm
Warranty and FAQs
FAQs:
-
Can I rotate to portrait? Yes—supports 90° via VESA mount.
-
Is it glove-compatible? Yes; PCAP reads gloved and bare-finger touches.
-
Does USB-C power it? Yes, up to 60 W PD over USB-C.
Performance, Quality, Durability & Reliability
Tested for 24/7 use, the Elo 1004L meets ISO 9241-307 for touch durability and MIL-STD-810G for shock. Optical bonding prevents condensation and ghost touches, ensuring reliable performance in busy environments.
