mPLUS2: Compact 58 mm panel-mount thermal printer with IP54 front, USB & RS-232. Flush installation for control panels. Order today!
Overview
The Custom America mPLUS2 is a scaled-down panel printer engineered for tight spaces. Its 58×58 mm flush-mount design and IP54-rated front ensure dust- and splash-resistant operation. USB and RS-232 ports enable immediate plug-and-play integration, boosting uptime in any control environment.
Product Description
Built for HMIs, kiosks, and self-service terminals where space is limited, the mPLUS2 delivers crisp 203 DPI prints on 58 mm-wide media at up to 80 mm/s. The rugged, sealed metal housing stands up to harsh conditions, while built-in paper-end and near-end sensors alert you before outages. An optional auto cutter provides precise receipt trimming, reducing operator intervention.
Key Features
-
Mini Flush Panel Design – Fits 58×58 mm cut-out for clean integration
-
IP54 Front Seal – Protection against dust and splashes
-
Thermal Printing – 203 DPI clarity at up to 80 mm/s
-
Dual Interfaces – USB 2.0 & RS-232 connectivity
-
Paper Sensors – End-of-paper and near-end detection
-
Optional Auto Cutter – Clean, precise receipt trimming
Specifications
-
Print Method: Thermal line printing
-
Resolution: 203 DPI
-
Speed: Up to 80 mm/s
-
Media Width: 58 mm
-
Panel Cut-Out: 58 × 58 mm
-
Interfaces: USB 2.0, RS-232
-
Power: 24 V DC, 1.5 A
-
Material: Sealed metal chassis with IP54-rated front
-
Dimensions: 58 × 58 × 85 mm (depth)
-
Weight: 0.8 kg
-
Operating Temp: 0–50 °C
Supported OS / Application / Industries
-
OS: Windows, Linux, Android
-
Applications: Industrial HMI logs, kiosk receipts, ticketing
-
Industries: Manufacturing, Utilities, Transportation, Self-service
Benefits & Compatibility
-
Space-Saving Integration: Compact footprint fits tight panels
-
High Uptime: IP-rated front and sealed housing minimize service calls
-
Easy Maintenance: Front-load media access with sensor alerts
-
Flexible Connectivity: USB & RS-232 adapt to diverse systems
Purpose of Use
Perfect for:
-
Control-panel event logging
-
Factory-floor report printing
-
Access-control ticket dispensing
-
Self-service and kiosk terminals
How to Use
-
Create a 58×58 mm cut-out.
-
Insert printer and secure with brackets.
-
Connect 24 V DC power and USB/RS-232 cable.
-
Install driver or use native HMI support.
For integration tips, contact our team.
Packaging / Weight / Dimension
-
Includes: mPLUS2 unit, mounting brackets, power cable, USB & RS-232 cables, quick-start guide
-
Packed Weight: 1.2 kg
-
Box Size: 100 × 100 × 120 mm
-
Protection: Foam inserts and sealed carton
Warranty and FAQs
FAQs:
-
Can I access media without removing panel? Yes, front-load design allows easy roll changes.
-
Does it support logos? Yes, up to 203 DPI graphic printing.
-
Is the cutter built-in? Optional—specify part code AC-mCUT when ordering.
More at our Support Center.
Performance, Quality, Durability & Reliability
Tested for 20 km of media feed and 300 k cutter cycles, the mPLUS2 meets IEC vibration standards. Its sealed design delivers reliable 24/7 operation in dusty, humid environments.
