Unmanaged 5-Port Industrial Ethernet Switch with 100Fx SC fiber uplink, 2Km range, and wide temp support. Ideal for harsh networks. Buy now at NEOTECH UAE.
✅ Overview
Engineered for extreme temperatures and rugged deployments, this 5-Port Industrial Ethernet Switch features 4 copper ports and 1 SC-type fiber port. Supporting a multi-mode transmission range of up to 2Km, it ensures rock-solid performance in outdoor and factory settings. Perfect for long-range connectivity without signal degradation.
✅ Product Description
This 5-port unmanaged industrial Ethernet switch provides a compact, rugged networking solution ideal for factory automation, transportation, and outdoor monitoring. It offers 4 x 10/100 Mbps RJ45 ports and 1 x 100 Mbps SC fiber uplink (multi-mode, 2Km).
With extended operating temperatures (-40°C to 75°C) and electro-optical transmission, it handles harsh conditions where commercial switches fail. The plug-and-play setup makes it perfect for edge network deployments, remote cameras, and control systems needing long-distance data transmission with fiber optics.
✅ Key Features
-
4× 10/100Base-TX RJ45 Ethernet Ports
-
1× 100Base-FX SC Multi-Mode Fiber Port (2Km)
-
Wide temp operation: -40°C to 75°C
-
No configuration required—true plug-and-play
-
Surge and ESD protection for field use
-
Rugged fanless metal design
-
DIN-rail or wall-mount ready
✅ Specifications
-
Copper Ports: 4 x 10/100Base-TX (Auto-Negotiation)
-
Fiber Uplink: 1 x 100Base-FX SC Multi-Mode (1310nm, 2Km)
-
Switching Capacity: 1 Gbps
-
Forwarding Rate: 0.744 Mpps
-
Operating Temp: -40°C to 75°C
-
Input Voltage: 12–48V DC
-
Housing: Industrial-grade aluminum alloy
-
Mounting: DIN-rail or wall-mount
-
Dimensions: Approx. 110mm x 80mm x 30mm
✅ Supported OS/Application/Industries
-
OS Compatibility: OS-independent
-
Applications: Fiber uplinks for surveillance, SCADA, or industrial IoT
-
Industries: Oil & Gas, Railways, Renewable Energy, Smart Cities, Utilities
✅ Benefits & Compatibility
-
Ideal for long-distance fiber-to-copper bridging
-
Plug-and-play ease for non-tech installations
-
Fiber SC port supports up to 2Km transmission
-
Vibration-resistant, maintenance-free design
-
Wide voltage & temperature tolerance ensures uptime
✅ Purpose of Use
Designed to bridge copper-based control networks to long-distance fiber uplinks, it’s a reliable switch for remote industrial field devices or edge data nodes in smart grids.
✅ How to Use
-
Mount the switch on DIN-rail or wall
-
Connect 10/100 devices to RJ45 ports
-
Link fiber cable to SC port for uplink
-
Power via 12–48V DC input
-
Run instantly—no setup required
✅ Packaging/Weight/Dimension
-
Dimensions: 110 x 80 x 30 mm
-
Weight: ~0.4 kg
-
In the Box: Switch unit, power terminal block, mounting accessories, user manual
✅ Warranty and FAQs
Warranty: 12-month limited replacement
FAQs:
Q1: Is this switch managed?
A1: No, it’s completely unmanaged.
Q2: Can the SC fiber port connect to a switch with LC?
A2: You’ll need an SC-to-LC adapter or matching transceiver.
Q3: Does it support PoE?
A3: No, this model does not have PoE.
✅ Performance, Quality, Durability, and Reliability
With stable fiber performance over 2 kilometers and ESD/EMI resilience, this switch outperforms standard gear in high-vibration, high-temperature, and mission-critical environments.
✅ Best Price Guarantee
Buy with confidence. We offer the most competitive price in the UAE. Find it lower elsewhere? We'll match it.
✅ Shop Today & Receive Your Delivery Across the UAE!
Order now for fast delivery to Dubai, Abu Dhabi, Sharjah, and across all UAE regions. NEOTECH ensures reliable, safe, and timely shipping.
✅ Request for Customer Reviews and Testimonials
Used this model in a remote deployment? Share your story and help others trust reliable fiber-based industrial connectivity.
✅ After Sales Support
From setup advice to warranty service, we’ve got you. Our support team is here to help you maximize performance and uptime.
✅ Get in Touch
Need fiber connectivity guidance or help choosing the right switch? Contact our team today. We’re just a message or call away.
✅ Stock Availability
We work hard to maintain real-time inventory. For bulk or urgent orders, contact us directly to confirm availability.
✅ Disclaimer
Specs and visuals may change without notice. Verify details with our team before ordering. Product is for general information only and may vary slightly.
