4 10Gb Fiber Optic to Ethernet 32 Port Industrial Grade IP40 Aggregation Switch

32-Port IP40 Industrial Aggregation Switch with 4×10G Fiber uplinks. High-speed, rugged build for demanding networks. Shop now at NEOTECH UAE!

✅ Overview

Engineered for high-density, high-performance industrial networking, this 32-Port Industrial Aggregation Switch with 4×10Gb Fiber uplinks delivers powerful bandwidth in mission-critical deployments. Certified with IP40 protection, it’s ideal for demanding applications like smart cities, transportation, and industrial control systems where uptime and reliability are non-negotiable.

✅ Product Description

This robust Layer 2 aggregation switch features 32 Ethernet ports for copper connections and 4 x 10Gb SFP+ fiber uplinks, enabling seamless aggregation of edge devices to core infrastructure. Designed for DIN-rail mounting in harsh industrial environments, the fanless, rugged IP40-rated housing ensures heat dissipation without moving parts—ideal for vibration-prone or remote locations.

It supports full wire-speed forwarding and advanced traffic optimization features like flow control and broadcast storm protection. Designed to meet industrial performance and environmental standards, this unmanaged powerhouse ensures uninterrupted high-speed data flow, even under extreme temperatures or electrical interference.

✅ Key Features

• 32 x 10/100/1000 Mbps RJ45 Ethernet Ports

• 4 x 10Gb SFP+ Fiber Optic Uplinks

• IP40-rated industrial-grade aluminum chassis

• High-speed data aggregation up to 176Gbps

• Wide working temperature: -40°C to 75°C

• DIN-rail or wall-mountable, compact design

• Redundant power input for reliability

• Surge & ESD protection for harsh conditions

✅ Specifications

• Ethernet Ports: 32 x 10/100/1000 Mbps

• Uplink Ports: 4 x 10G SFP+ Fiber

• Switching Capacity: Up to 176 Gbps

• Forwarding Rate: 130.95 Mpps

• Input Voltage: 12~58V DC (dual redundant)

• Cooling: Fanless, passive

• Operating Temp: -40°C to 75°C

• Protection Rating: IP40

• Mounting: DIN-rail or wall

• Material: Industrial-grade metal enclosure

✅ Supported OS/Application/Industries

• OS Compatibility: Universal, unmanaged plug & play

• Use Cases: Aggregation switch in surveillance, automation, core uplink

• Industries: Manufacturing, Transport, Smart Cities, Energy, Railways

✅ Benefits & Compatibility

• Supports high-bandwidth aggregation over long distances

• Seamless copper-to-fiber transition with SFP+ modules

• Low power draw and high heat tolerance

• Plug-and-play simplicity with no software setup

• Compatible with all standard Ethernet and SFP+ fiber devices

✅ Purpose of Use

This switch is designed to aggregate high-speed edge traffic and distribute it to backbone or data center systems, ideal for connecting multiple PoE switches, NVRs, or PLCs in industrial networks.

✅ How to Use

1. Mount switch on DIN-rail or wall bracket

2. Connect Ethernet edge devices to the 32 RJ45 ports

3. Insert 10G SFP+ modules and fiber links into uplinks

4. Power on via DC input

5. Begin use—no configuration required

✅ Packaging/Weight/Dimension

• Weight: ~4.5 kg

• Dimensions: Approx. 440mm x 250mm x 45mm

• Packaging Includes: 1x Switch, Power Terminal Block, User Guide, Mount Kit

✅ Warranty and FAQs

Warranty: 12 months limited industrial warranty
FAQs:
Q1: Does this switch support VLANs?
A1: No, it's unmanaged.
Q2: Can I use single-mode or multi-mode fiber?
A2: Yes, via appropriate SFP+ module.
Q3: Is it fanless?
A3: Yes, for silent and dust-free operation.

✅ Performance, Quality, Durability, and Reliability

With lightning-fast uplinks and industrial reliability, this switch ensures zero downtime in high-stakes environments. Its passive cooling, wide voltage tolerance, and durable build offer unmatched long-term stability.

✅ Best Price Guarantee

We price-match all verified sellers in the UAE. You're always getting the best deal with NEOTECH.

✅ Shop Today & Receive Your Delivery Across the UAE!

Get quick, secure delivery in Dubai, Sharjah, Abu Dhabi, Ajman & all Emirates. Hassle-free logistics from order to installation.

✅ Request for Customer Reviews and Testimonials

If this switch powered your data network, tell us about it! Your reviews help others trust rugged industrial networking gear.

✅ After Sales Support

Need help? Our UAE-based support team is always ready to assist with power setup, fiber compatibility, or anything in between.

✅ Get in Touch

Want a project quote, bulk discount, or technical clarification? Contact our expert team now via phone, email, or chat.

✅ Stock Availability

This model is high in demand. Please confirm availability with us before placing large or time-sensitive orders.

✅ Disclaimer

All data is for reference only and may change without notice. Product photos are for illustration. Always verify specs with our sales team before purchase.
