DEWOD P201 RK3128 Android System 1+4G Android Motherboard

DEWOD P201 RK3128 Android motherboard with 1GB RAM + 4GB storage. Compact, stable & ideal for kiosks & IoT. Shop now at NEOTECH UAE.

Overview

The DEWOD P201 RK3128 Android Motherboard is a compact and cost-effective embedded solution designed for kiosks, IoT devices, and industrial applications. Featuring the RK3128 Quad-Core Cortex-A7 processor, it provides stable Android performance in a lightweight and power-efficient motherboard design.

Product Description

Built with 1GB RAM and 4GB onboard storage, the P201 motherboard delivers reliable performance for small-scale Android projects. Supporting HD video playback, multiple I/O interfaces, and wireless connectivity, it is an excellent choice for POS terminals, digital signage, vending machines, and automation systems.

Key Features

• Rockchip RK3128 Quad-Core Cortex-A7 processor

• 1GB RAM + 4GB storage (expandable)

• Android 7.1 operating system

• Compact motherboard design for embedded integration

• HDMI, LVDS, and eDP display outputs

• Multiple I/O ports: USB, LAN, RS232, GPIO

• Energy-efficient, fanless performance

Specifications

• CPU: Rockchip RK3128 Quad-Core Cortex-A7

• GPU: Mali-400MP2

• Memory: 1GB DDR3 RAM

• Storage: 4GB eMMC (expandable via microSD)

• Operating System: Android 7.1

• Video Output: HDMI, LVDS, eDP

• Connectivity: USB, LAN, RS232, GPIO

• Power Supply: DC 5V / 12V

• Form Factor: Compact embedded motherboard

Supported OS / Applications / Industries

• Operating System: Android 7.1

• Applications: POS systems, Vending kiosks, IoT devices, Smart displays, Digital signage

• Industries: Retail, Healthcare, Transportation, Education, Industrial automation

Benefits & Compatibility

• Low-power RK3128 CPU ensures stable and efficient operation

• Compact design fits small kiosks and embedded projects

• Expandable storage for flexible application deployment

• Compatible with NEOTECH’s entry-level Android solutions, POS devices, and digital signage systems

Purpose of Use

Best for budget-friendly kiosks, digital advertising, vending terminals, small-scale IoT devices, and embedded automation projects.

How to Use

1. Install the motherboard in kiosk/embedded housing.

2. Connect to display via HDMI, LVDS, or eDP.

3. Load Android OS applications.

4. Begin operation for POS, signage, or IoT functions.

Packaging / Weight / Dimensions

• Packaging: Anti-static developer box

• Weight: ~0.25 kg

• Dimensions: ~105 × 85 mm (compact board)

Warranty & FAQs

• Warranty: 1-year standard manufacturer warranty

• FAQs:

  • Can it play HD video? Yes, supports 1080p decoding.

  • Is it Android-compatible? Yes, Android 7.1 supported.

  • Can I expand storage? Yes, via microSD.

Performance, Quality, Durability & Reliability

The DEWOD P201 motherboard offers reliable RK3128 performance with low power consumption, making it suitable for long-term industrial and commercial use. Its compact size and fanless design ensure durability and efficiency.

Best Price Guarantee

NEOTECH provides the best UAE market price. Found it cheaper? We’ll match it.

Shop Today & Receive Your Delivery Across the UAE

Available now with fast delivery to Dubai, Abu Dhabi, Sharjah, and all Emirates.

Request for Customer Reviews and Testimonials

Already using this board? Share your project experience to help other developers.

After Sales Support

NEOTECH provides SDKs, documentation, and technical assistance for RK3128-based boards.

Get in Touch

Explore more at NEOTECH Android development boards and embedded IoT solutions.

Stock Availability

The DEWOD P201 RK3128 Android Motherboard is in stock and ready for dispatch.

Disclaimer

Specifications may change without notice. Images shown are for reference only.
