10.1 Inch Embedded Industrial Tablet Comput Intel Core Processor I3-i5-i7 Intel Core Processor

10.1″ IP65 embedded tablet PC with Intel® Core™ i3/i5/i7, 8–16 GB DDR4, M.2 NVMe SSD, dual LAN, USB 3.0, fanless design—built for 24/7 industrial use.

Overview

This 10.1″ embedded industrial tablet delivers laptop-class Intel® Core™ performance in a fanless, IP65-sealed chassis. Designed for panel-mount or vehicle-dash installations, it provides reliable 24/7 operation in harsh factory, logistics, and mobile-work environments.

Product Description

Powered by your choice of Intel® Core™ i3-7100U, i5-7200U, or i7-7500U CPUs and up to 16 GB DDR4, this all-in-one unit integrates a glove-friendly 10-point capacitive touchscreen, user-installable M.2 2280 NVMe SSD, and dual Intel® Gigabit LAN ports. Four USB 3.0 ports and HDMI output connect cameras, sensors, and displays. The fully passive cooling system eliminates fans, and sealed I/O covers block dust and water. Mount via VESA 75 × 75 mm or panel-cut bracket for seamless integration.

Key Features

• CPU Options: Intel® Core™ i3-7100U / i5-7200U / i7-7500U

• Display: 10.1″ 1920 × 1200 IPS, 10-point PCAP touch (glove-compatible)

• Cooling: Fully fanless, passive-cooled design

• Rugged Rating: IP65 front; IP40 rear; MIL-STD-810G shock & vibration

• Memory & Storage: 8 GB default DDR4 (up to 16 GB via SO-DIMM) + M.2 NVMe SSD slot

• Networking: 2× Intel® I210 Gigabit Ethernet; Wi-Fi 6 & Bluetooth 5.0 (optional)

• I/O Ports: 4× USB 3.0; HDMI 1.4; RS-232/422/485; audio in/out

• Power: 12 V DC terminal block; optional hot-swap battery packs

• Mounting: VESA 75 × 75 mm or panel-cut kit included

Specifications

Supported OS / Applications / Industries

• Operating Systems: Windows 10 IoT/Pro, Ubuntu Linux

• Applications: HMI/SCADA, machine vision, mobile diagnostics

• Industries: Manufacturing, logistics, utilities, transportation

Benefits & Compatibility

• Zero Maintenance: Fanless design eliminates filter changes

• Seamless Integration: Standard VESA/panel-mount and I/O simplify installation

• Robust Connectivity: Dual LAN and USB 3.0 support high-speed peripherals

Purpose of Use

Ideal as an embedded HMI on automated machinery, a dash-mounted controller in vehicles, or a panel-cut operator interface in control cabinets.

How to Use

1. Mount via VESA bracket or panel-cut kit.

2. Wire 12 V DC, Ethernet, and I/O cables through sealed connectors.

3. Install optional RAM and M.2 SSD as required.

4. Boot Windows or Linux and launch your control software.

Packaging / Weight / Dimensions

• Packaging: Foam-lined box with anti-static wrap

• Net Weight: ~0.9 kg

• Gross Weight: ~1.4 kg (with accessories)

• Box Size: 320 × 240 × 80 mm

Warranty and FAQs

• Warranty: 12-month limited hardware warranty

• FAQs:

  • Q: Can I field-upgrade RAM?
    A: Yes; one SO-DIMM slot supports up to 16 GB.

  • Q: Does touch work with gloves?
    A: Yes; PCAP supports standard industrial gloves.

Performance, Quality, Durability, and Reliability

Tested to MIL-STD-810G for shock and vibration. The IP65-sealed, fanless chassis ensures reliable operation from –10 °C to 60 °C without moving-part failures.

Best Price Guarantee

Find a lower price on an identical unit? We’ll match it—guaranteed to protect your budget.

Shop Today & Receive Your Delivery Across the UAE!

Order now for express, insured delivery to all emirates. In-stock units ship same-day for rapid deployment.

Request for Customer Reviews and Testimonials

Share your installation successes to help peers and guide our next-gen designs.

After Sales Support

Our support team offers remote diagnostics, firmware updates, and spare-part ordering. Expect a response within one business day.

Get in Touch

For volume pricing or custom configurations, email sales@cesipc.com. We’re ready to assist.

Stock Availability

Units are in stock and ready to ship. Confirm availability with our sales team before ordering to avoid delays.

Disclaimer

All specifications and images are for reference only and may change without notice. Verify final details with your CESIPC sales representative prior to purchase.
