ATP247 automatic thermal printer mechanism—auto-feed, 80 mm roll, 203 dpi, auto-cutter ready. Shop at NEOTECH.
Overview
Automate your self-service workflow with the ATP247. This direct-thermal engine handles 80 mm rolls, auto-feeds paper, and prints crisp 203 dpi receipts or tickets at up to 150 mm/s. Integrated auto-cutter and jam-free path ensure 24/7 uptime in kiosks, ATMs, vending, and ticketing terminals.
Internal Link: Explore our Thermal Mechanisms series.
External Link: Learn about thermal printing standards on the IPC website.
Product Description
The ATP247 blends industrial performance with plug-and-play simplicity. Its auto-feed roller system pulls paper smoothly, while the auto-cutter delivers clean full or partial cuts on demand. An MTBF of 30,000 hrs and a sealed design resist dust and debris. Mount it in tight enclosures with its compact 210 × 130 × 115 mm frame.
Key Features
-
Auto-feed roller for continuous printing
-
80 mm paper width on 12.7 mm core
-
203 dpi high-resolution thermal head
-
150 mm/s max print speed
-
Auto-cutter ready (full/partial cut)
-
RS232, USB & TTL interfaces
-
Jam-free paper path design
-
MTBF ≥ 30,000 hrs reliability
Specifications
| Parameter |
Details |
| Model |
ATP247 |
| Print Width |
80 mm |
| Print Speed |
Up to 150 mm/s |
| Resolution |
203 dpi |
| Core Diameter |
12.7 mm |
| Interfaces |
RS232, USB 2.0, TTL |
| Cutter Option |
Full-cut / Partial-cut |
| MTBF |
≥ 30,000 hours |
| Operating Temp. |
0 °C–50 °C |
| Dimensions |
210 × 130 × 115 mm |
| Weight |
1.3 kg |
Supported OS / Applications / Industries
-
OS: Windows, Linux, Android (via SDK)
-
Apps: ATM firmware, kiosk controllers, POS systems
-
Industries: Banking, Retail, Transportation, Vending, Self-Service
Benefits & Compatibility
-
Seamless integration via RS232/USB/TTL
-
Low maintenance with jam-free design
-
High uptime thanks to robust MTBF
-
Clean cuts for professional receipts
-
Compact build fits tight enclosures
Purpose of Use
Ideal for embedding in ATMs, kiosks, ticket dispensers, and any self-service terminal requiring automatic paper handling and clean cuts.
How to Use
-
Mount ATP247 in your device chassis
-
Connect RS232, USB, or TTL cable to host
-
Load an 80 mm thermal roll (12.7 mm core)
-
Power on and run test print via SDK
-
Auto-feed and auto-cut engage during printing
Packaging / Weight / Dimension
-
Includes: ATP247 mechanism, interface cables, mounting kit, user manual
-
Unit size: 210 × 130 × 115 mm
-
Unit weight: 1.3 kg
-
Package weight: ~1.6 kg
Warranty & FAQs
Performance, Quality, Durability & Reliability
With an industrial-grade thermal head, auto-feed mechanism, and sealed chassis, the ATP247 delivers consistent print density, jam-free operation, and long-life performance under heavy use.
Best Price Guarantee
Found a lower price on a comparable automatic printer mechanism? NEOTECH will match it—no hassle.
Shop Today & Delivery Across the UAE!
Order the ATP247 now for express shipping to Dubai, Abu Dhabi, Sharjah, and beyond. Track in real time.
Customer Reviews & Testimonials
Installed your ATP247? Drop a quick review on our site and help others choose smart.
After-Sales Support
Need integration tips or troubleshooting? Our UAE support team is a call or email away. If remote help falls short, we’ll guide you through an easy RMA.
Get in Touch
For bulk quotes, custom firmware, or SDK access, contact our sales team for samples, demos, and pro advice.
Stock Availability
Check live inventory with our sales team before ordering—lead times may vary for custom builds.
Disclaimer
Specs, pricing, and availability are subject to change without notice. Images are illustrative; actual mechanism may vary. Always verify details with NEOTECH before purchase.
