DEWOD RK3288 Mainboard WIFI 802.11b/g/n, BT4.0, 3G EDP LVDS Interface

DEWOD RK3288 mainboard with Wi-Fi, Bluetooth 4.0, 3G, eDP & LVDS interface. High-performance Android/Linux board for kiosks & IoT. Shop now at NEOTECH UAE.

Overview

The DEWOD RK3288 Mainboard is a powerful embedded solution featuring quad-core Cortex-A17 performance, Wi-Fi 802.11b/g/n, Bluetooth 4.0, and 3G connectivity. With eDP and LVDS display interfaces, it is optimized for digital signage, kiosks, multimedia, and IoT projects.

Product Description

Powered by the Rockchip RK3288 Quad-Core Cortex-A17 @ 1.8GHz, this mainboard combines Android/Linux OS support, Mali-T764 GPU, and multiple display outputs for rich multimedia and industrial applications. With built-in wireless connectivity and expandable I/O options, it offers flexibility for developers building embedded systems, retail kiosks, and automation solutions.

Key Features

• RK3288 Quad-Core Cortex-A17 processor (1.8GHz)

• Mali-T764 GPU with 4K video decoding

• Built-in Wi-Fi 802.11b/g/n & Bluetooth 4.0

• 3G module support for mobile connectivity

• eDP & LVDS interfaces for display integration

• Multiple I/O ports: HDMI, USB, LAN, RS232, GPIO

• Android/Linux compatibility

Specifications

• CPU: Rockchip RK3288 Quad-Core Cortex-A17 @ 1.8GHz

• GPU: Mali-T764 with 4K decode support

• Memory: 2GB / 4GB DDR3 RAM

• Storage: 8GB / 16GB eMMC (expandable via microSD)

• Wireless: Wi-Fi 802.11 b/g/n, Bluetooth 4.0, 3G support

• OS Support: Android 7.1 / Linux (Ubuntu, Debian)

• Video Output: HDMI, eDP, LVDS

• Connectivity: USB, LAN, RS232, GPIO, MIPI-CSI

• Power Supply: DC 5V / 12V

• Form Factor: Embedded mainboard for integration

Supported OS / Applications / Industries

• Operating Systems: Android 7.1, Linux (Ubuntu/Debian)

• Applications: Digital signage, Kiosks, Multimedia systems, Industrial IoT, Robotics, Smart retail devices

• Industries: Retail, Transportation, Manufacturing, Healthcare, Education, Smart city projects

Benefits & Compatibility

• High-performance RK3288 CPU for multitasking and multimedia

• Wireless-ready with Wi-Fi, Bluetooth, and 3G connectivity

• Dual display support via eDP and LVDS interfaces

• Compatible with NEOTECH’s digital signage systems, interactive kiosks, and IoT controllers

Purpose of Use

Perfect for interactive kiosks, smart vending machines, industrial controllers, robotics, and digital signage displays.

How to Use

1. Install the mainboard into kiosk/embedded housing.

2. Connect display via HDMI, eDP, or LVDS.

3. Configure wireless (Wi-Fi/BT/3G) for connectivity.

4. Load Android/Linux OS and deploy applications.

Packaging / Weight / Dimensions

• Packaging: Anti-static protective developer box

• Weight: ~0.3 kg

• Dimensions: ~110 × 90 mm (compact embedded board)

Warranty & FAQs

• Warranty: 1-year standard manufacturer warranty

• FAQs:

  • Does it support 4K video? Yes, via Mali-T764 GPU.

  • Is Wi-Fi built-in? Yes, 802.11 b/g/n supported.

  • Can it run Linux? Yes, Ubuntu and Debian are supported.

Performance, Quality, Durability & Reliability

The DEWOD RK3288 mainboard combines quad-core CPU power, wireless connectivity, and multi-display support, ensuring reliable performance for both commercial kiosks and industrial embedded projects.

Best Price Guarantee

NEOTECH guarantees the best UAE market price. Found it cheaper? We’ll match it.

Shop Today & Receive Your Delivery Across the UAE

Available for fast shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates.

Request for Customer Reviews and Testimonials

Already using this board? Share your experience to help other developers and integrators.

After Sales Support

NEOTECH provides SDKs, documentation, and technical integration support for RK3288-based boards.

Get in Touch

Explore more in NEOTECH embedded Android boards and industrial development kits.

Stock Availability

The DEWOD RK3288 Mainboard is in stock and ready for immediate dispatch.

Disclaimer

Specifications may change without notice. Images shown are for reference only.
