24× 1G RJ-45 ports, 4× 1G SFP uplinks, 128 Gbps switching, CLI/Web UI, Layer 2, PoE-lite support, fan-less design—ideal for small core/aggregation.
Overview
The Catalyst C1000-24T-4G-L is a compact, fan-less switch built for entry core and aggregation. It offers 24× Gigabit RJ-45 ports plus 4× SFP uplinks, up to 128 Gbps capacity, and essential Layer 2 features. Perfect for small data centers, branch offices, and wiring closets needing reliable throughput.
Product Description
-
24× 10/100/1000 Mbps RJ-45 ports with auto-MDI/MDIX
-
4× 1 Gbps SFP uplinks for fiber or copper modules
-
Switching Capacity: 128 Gbps full-duplex
-
Forwarding Rate: 95 Mpps line-rate performance
-
Layer 2: VLAN, QoS, IGMP snooping, Link Aggregation
-
PoE-Lite: Up to 30 W budget per port (model-dependent)
-
Fan-less: Silent operation for office or edge
-
Management: Web UI, CLI, SNMPv2/v3, RMON
-
Security: 802.1X, DHCP snooping, Dynamic ARP Inspection
Plug in devices, link uplinks, and manage via web or script—no sweat.
Key Features
-
High-Density Gigabit: 24 copper + 4 SFP uplinks
-
Silent Design: Fan-less chassis for noise-free zones
-
Robust Layer 2: VLANs, QoS, STP, LACP
-
Flexible Uplinks: Fiber or copper SFP modules
-
Easy Management: Intuitive Web UI & full CLI
-
Secure Access: 802.1X port auth & DHCP snooping
Specifications
| Spec |
Detail |
| Ports |
24× 10/100/1000 RJ-45, 4× 1 Gbps SFP uplinks |
| Switching Cap. |
128 Gbps full-duplex |
| Forwarding Rate |
95 Mpps |
| VLANs |
Up to 256 static VLANs |
| QoS Queues |
4 priority queues |
| Link Aggregation |
8 groups, 8 ports each (LACP) |
| PoE-Lite |
Up to 30 W per port (max budget 370 W) |
| Management |
HTTP/HTTPS Web UI, CLI via console/SSH, SNMP |
| Security |
802.1X, DHCP snooping, Dynamic ARP Inspection |
| Power |
Internal PSU, 100–240 VAC, 50–60 Hz |
| Dimensions (W×D×H) |
440×245×44 mm (1RU) |
| Weight |
~3.2 kg |
| Operating Temp. |
0 °C to 45 °C |
Supported Use Cases & Industries
-
Use Cases: Small-core aggregation, branch WAN/LAN, PoE-lite edge, guest Wi-Fi backhaul
-
Industries: SMB offices, retail, education, healthcare, light-use data centers
Benefits & Compatibility
-
Plug-and-Play: Auto-MDI/MDIX & simple VLAN wizards
-
Quiet Ops: Fan-less for noise-sensitive areas
-
Fiber-Ready: SFP uplinks for long-reach or DWDM
-
Secure Access: Port-based 802.1X and DHCP guard
-
Future-Proof: Scales with module-based uplinks
Purpose of Use
Ideal for aggregating access switches, powering PoE-lite devices, and linking to core layers in small DC or branch environments.
How to Use
-
Rack-mount the 1RU unit.
-
Connect devices to RJ-45 ports.
-
Link uplinks via SFP modules to core.
-
Assign VLANs and QoS via Web UI.
-
Monitor performance with SNMP or CLI scripts.
Packaging & Dimensions
-
Includes: Switch, rack ears, power cord, Quick Start guide
-
Size: 440×245×44 mm (W×D×H)
-
Weight: ~3.2 kg
