Elo 1302L: 13″ Full HD PCAP touchscreen with edge-to-edge glass, 10-point multi-touch, and VESA mount. Ideal for retail, hospitality & kiosks.
Overview
The Elo 1302L delivers a compact, high-performance 13″ touchscreen solution with 10-point PCAP interactivity and razor-sharp Full HD imagery. Its zero-bezel glass front, wide 178° viewing angles, and durable design make it perfect for space-constrained POS stations, interactive kiosks, and table-side ordering.
Product Description
Built for demanding commercial environments, the Elo 1302L integrates optical bonding and anti-glare glass to minimize reflection and enhance contrast. The PCAP sensor offers fast, accurate touch response, even with gloved hands. With HDMI, DisplayPort, and USB-C video/touch/power in a single cable, plus VESA 75×75 mounting, installation is seamless. Its sealed front resists spills and dust, reducing downtime and maintenance.
Key Features
-
13″ Full HD Display – 1920×1080 resolution for crisp text and graphics
-
PCAP Touch – Zero-bezel, 10-point multi-touch for precise interaction
-
Optical Bonding – Reduces glare, improves durability, prevents condensation
-
Wide Viewing – 178° H/V for consistent image quality from any angle
-
Sealed Front – IP54-rated against dust and splashes
-
Flexible I/O – HDMI, DisplayPort, USB-C (video + touch + up to 60 W PD), USB-A ports
Specifications
| Spec |
Details |
| Display Size |
13″ diagonal |
| Resolution |
1920×1080 (16:9) |
| Touch Technology |
PCAP, 10-point multi-touch |
| Brightness |
250 cd/m² |
| Contrast Ratio |
1000:1 |
| Viewing Angles |
178° horizontal/vertical |
| Glass |
3 mm tempered, anti-glare |
| Ingress Protection |
IP54 front panel |
| Video Inputs |
HDMI 1.4 ×1, DisplayPort 1.2 ×1 |
| Touch & Power I/O |
USB-C (video, touch, up to 60 W power) |
| USB Ports |
USB-A ×2 (for peripherals) |
| Mounting |
VESA 75×75 mm |
| Dimensions (W×H×D) |
315 × 205 × 35 mm |
| Weight |
2.4 kg |
| Operating Temperature |
0 – 40 °C |
Supported OS / Application / Industries
-
OS Compatibility: Windows, Linux, Android (via standard HID drivers)
-
Applications: POS terminals, self-service kiosks, digital signage, tabletop ordering
-
Industries: Retail, hospitality, healthcare, banking, transportation
Benefits & Compatibility
-
Space-Saving Design: Compact 13″ footprint fits tight counters and carts
-
Enhanced User Experience: Fluid multi-touch and edge-to-edge glass foster engagement
-
Low Maintenance: Sealed front prevents spills and dust ingress
-
Single-Cable Deployment: USB-C delivers video, touch, and power
Purpose of Use
Ideal for:
-
Retail point-of-sale and line-busting
-
Interactive menu ordering in cafés and restaurants
-
Self-check-in/out kiosks in healthcare or hospitality
-
Digital information points and wayfinding stations
How to Use
-
Mount using VESA 75×75 brackets or countertop stand.
-
Connect video via HDMI or DP; link touch/power via USB-C.
-
Calibrate touch if required in your OS settings.
-
Deploy your POS, kiosk, or signage application.
Packaging / Weight / Dimension
-
Box Includes: Elo 1302L monitor, power adapter, HDMI cable, USB-C cable, quick-start guide
-
Packed Weight: 3.2 kg
-
Box Size: 360 × 270 × 120 mm
-
Protection: Custom foam inserts
Warranty and FAQs
FAQs:
-
Can I use it in portrait mode? Yes, supports 90° rotation via VESA mount.
-
Is it suitable for kitchen environments? IP54 front protects against spills; consult Elo for full kitchen spec.
-
Does it support pen/stylus input? Only finger and glove touch—no active pen support.
Performance, Quality, Durability & Reliability
Certified for 24/7 operation, the Elo 1302L meets ISO 9241-307 for touch durability and TCO standards for long-life performance. Optical bonding seals out moisture and extends panel lifespan.
Best Price Guarantee
Found a lower UAE price on Elo 1302L? We’ll match it—guaranteed. Get industry-leading reliability at the best value.
Shop Today & Receive Your Delivery Across the UAE!
Enjoy next-day shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates. Secure checkout and live tracking ensure on-time delivery.
Request for Customer Reviews and Testimonials
Deploying Elo 1302L in your environment? Share your insights to help peers select the right touchscreen solution. Submit a review
After Sales Support
Elo’s support team is available via email, phone, or live chat for installation assistance, firmware updates, and troubleshooting—ensuring your touchscreen stays fully operational.
Get in Touch
Need deployment guidance or volume quotes? Contact our Elo specialists for personalized advice and rapid responses.
Stock Availability
Stock levels update daily. For urgent projects, confirm availability with our sales team before ordering. Custom bezel or anti-microbial glass options may require 7–10 business days.
Disclaimer
All specifications and pricing are for general informational purposes and subject to change without notice. Product images are illustrative. Verify final details with our sales team before ordering.
