Rugged IP65 fanless panel PC. Intel® J4125/J6412 or Core™ i3–i5, 4–16 GB DDR4, 128 GB SSD, 10‐point PCAP touch, dual LAN. Windows/Linux ready.
Overview
This CESIPC wall-mount panel PC brings fanless, maintenance-free compute to control rooms and kiosks. Choose Intel® Celeron® J4125/J6412 or Core™ i3-10110U/i5-10210U, run Windows or Linux, and enjoy a 10-point capacitive display sealed to IP65 for dust- and water-jet protection.
Product Description
Housed in die-cast aluminum with front-panel IP65 sealing, each unit integrates your CPU choice with 4–16 GB DDR4 and a 128 GB NVMe SSD (expandable). A 15″, 17″ or 19″ 10-point PCAP touchscreen supports gloves and wash-downs. Rich I/O includes 4× USB 3.0, RS-232 COM, dual Gigabit LAN and HDMI. Fanless thermal design ensures silent operation and zero moving parts to clog or fail.
Key Features
-
IP65 Front: Dust-tight & water-jet proof
-
Fanless Cooling: Silent, zero-maintenance uptime
-
CPU Options: J4125 (4×2.0 GHz) / J6412 (4×2.0 GHz) / Core™ i3-10110U / i5-10210U
-
Memory & Storage: 4–16 GB DDR4; 128 GB NVMe SSD (M.2 slot)
-
10-Point Touch: PCAP multi-touch, glove-compatible
-
I/O Suite: USB 3.0×4, RS-232×1, HDMI 1.4×1, Dual LAN×1
-
OS Support: Windows 10/11 Pro or Ubuntu/CentOS Linux
Specifications
| Parameter |
15″ Model |
17″ Model |
19″ Model |
| Display |
15″, 1024×768 PCAP |
17″, 1280×1024 PCAP |
19″, 1366×768 PCAP |
| CPU |
J4125 / J6412 / i3 / i5 |
J4125 / J6412 / i3 / i5 |
J4125 / J6412 / i3 / i5 |
| Memory |
4–16 GB DDR4 |
4–16 GB DDR4 |
4–16 GB DDR4 |
| Storage |
128 GB NVMe SSD (M.2) |
128 GB NVMe SSD (M.2) |
128 GB NVMe SSD (M.2) |
| USB Ports |
4× USB 3.0 |
4× USB 3.0 |
4× USB 3.0 |
| Serial |
1× RS-232 |
1× RS-232 |
1× RS-232 |
| Video Output |
1× HDMI 1.4 |
1× HDMI 1.4 |
1× HDMI 1.4 |
| Networking |
Dual Gigabit LAN |
Dual Gigabit LAN |
Dual Gigabit LAN |
| Power Input |
12–36 V DC |
12–36 V DC |
12–36 V DC |
| Enclosure Rating |
IP65 front; IP20 rear |
IP65 front; IP20 rear |
IP65 front; IP20 rear |
| Operating Temp |
–20 °C to +60 °C |
–20 °C to +60 °C |
–20 °C to +60 °C |
| Mounting |
VESA 75/100 mm & panel cut |
VESA 75/100 mm & panel cut |
VESA 75/100 mm & panel cut |
| Dimensions (W×H×D) |
395×275×45 mm |
445×325×50 mm |
495×350×55 mm |
| Weight |
~4.5 kg |
~5.5 kg |
~6.5 kg |
Supported OS / Applications / Industries
-
OS: Windows 10/11 Pro, Ubuntu/CentOS Linux
-
Applications: HMI/SCADA, digital signage, kiosks, automation control
-
Industries: Manufacturing, logistics, utilities, food & beverage
Benefits & Compatibility
-
Silent Reliability: No fans or filters to clean
-
Wash-Down Safe: IP65 front withstands high-pressure cleaning
-
Glove-Friendly: Touch works with industrial gloves
-
Full I/O: Legacy RS-232 plus modern USB, LAN & HDMI
Purpose of Use
Mount on walls or cabinet doors for operator consoles, machine-vision stations or info-kiosks where space is tight and uptime is critical.
How to Use
-
Cut or prep panel opening per included template.
-
Route 12–36 V DC, LAN, USB and RS-232 cables.
-
Secure via VESA or panel mounts.
-
Install Windows or Linux, then your HMI/SCADA software.
-
Power on—maintenance-free operation begins.
Packaging / Weight / Dimensions
-
Dimensions: see Specs table above
-
Weight: see Specs table above
-
Packaging: Foam-lined crate with power adapter, mounting kit, quick-start guide
Warranty & FAQs
Warranty: 1-Year Limited Warranty
FAQs
-
Can it run gloves-on? Yes — PCAP supports gloves.
-
Is storage expandable? Yes, via optional M.2 slot.
-
Is it splash-proof? Yes — front IP65 resists jets.
Performance, Quality & Reliability
Tested to IPC-Grade 3G (50 G shock, 5 G vibration) and IP65 wash-down standards. Fanless design extends MTBF beyond 100 000 hrs.
Best Price Guarantee
Found a lower UAE quote? We’ll match it — CESIPC & NEOTECH guarantee top quality at best value.
Shop Today & UAE Delivery
Order now for insured, next-day delivery to Dubai, Abu Dhabi, Sharjah and all emirates. Secure packaging ensures damage-free arrival.
Customer Reviews & Testimonials
Share your wall-mount deployment success to guide peers selecting the right panel PC.
After-Sales Support
24/7 remote diagnostics, firmware updates & priority RMA keep your systems online and optimized.
Get in Touch
For custom builds or bulk quotes, email sales@neotech.ae. Our specialists are ready to assist.
Stock Availability
Please confirm current stock and lead times before placing urgent or bulk orders.
Disclaimer
All specifications, images and pricing are subject to change without notice. Verify final details with our sales team prior to purchase.
