Rugged IP65 fanless 15″ panel PC. Intel® J6412 or Core™ i3–i7, 4–16 GB DDR4, 128 GB NVMe SSD, 4× USB 3.0, RS-232, dual LAN. Silent, maintenance-free HMI.
Overview
This CESIPC 15″ embedded panel PC delivers silent, zero-maintenance compute in a fully sealed IP65 chassis. Run Windows or Linux on Celeron® J6412 or 10th-Gen Core™ CPUs for rock-solid HMI, SCADA and automation control—even in dusty, wet, or vibration-intense environments.
Product Description
Built into die-cast aluminum with front-panel IP65 sealing, the unit pairs your choice of Intel® Celeron® J6412 or Core™ i3-10110U / i5-10210U / i7-10510U with 4–16 GB DDR4 RAM and a 128 GB NVMe SSD (expandable). A projected-capacitive 15″ touchscreen supports gloves and wash-downs. I/O: 4× USB 3.0, 1× RS-232, dual Gigabit LAN, HDMI. Fanless thermal design means no moving parts—ever.
Key Features
-
IP65 Waterproof Front: Protects against dust and high-pressure jets
-
Fanless Cooling: Silent, zero-maintenance operation
-
CPU Options: J6412 (4×2.0 GHz) or Core™ i3/i5/i7 (10th Gen)
-
Memory & Storage: 4–16 GB DDR4; 128 GB NVMe SSD (M.2 slot)
-
I/O Suite: 4× USB 3.0, RS-232 ×1, HDMI ×1, Dual LAN ×1
-
Touch Display: 15″ PCAP multi-touch, glove-compatible
Specifications
| Parameter |
Detail |
| Display |
15″ LED-backlit, 1024 × 768 PCAP multi-touch |
| Processor |
Intel® J6412 or Core™ i3-10110U/i5-10210U/i7-10510U |
| Memory |
4 GB–16 GB DDR4 (SO-DIMM) |
| Storage |
128 GB NVMe SSD (M.2 slot) |
| USB Ports |
4 × USB 3.0 |
| Serial Port |
1 × RS-232 |
| Video Output |
1 × HDMI 1.4 |
| Networking |
Dual Gigabit Ethernet |
| Power Input |
12–36 V DC |
| Enclosure Rating |
IP65 front; IP20 rear |
| Operating Temp |
–20 °C to +60 °C |
| Mounting |
VESA 75/100 mm or panel cut-out |
| Dimensions (W×H×D) |
380 × 295 × 60 mm |
| Weight |
~5.5 kg |
Supported OS / Applications / Industries
-
OS: Windows 10/11 Pro, Ubuntu 18.04+/CentOS 7+
-
Applications: HMI/SCADA, automation control, digital signage
-
Industries: Manufacturing, food & beverage, logistics, utilities
Benefits & Compatibility
-
Zero Downtime: Fanless design eliminates clogged filters
-
Wash-Down Ready: IP65 front withstands daily cleaning
-
Glove-Friendly: PCAP touch works with industrial gloves
-
Versatile I/O: Native USB, serial, HDMI & LAN integration
Purpose of Use
Deploy as an operator console, production-line HMI or outdoor kiosk where reliability, silence and water resistance are paramount.
How to Use
-
Cut panel opening per template or mount via VESA bracket.
-
Connect 12–36 V DC, Ethernet, USB and RS-232 cables.
-
Install OS and your application software.
-
Power on—enjoy maintenance-free, silent operation.
Packaging / Weight / Dimensions
-
Dimensions: 380 × 295 × 60 mm
-
Weight: ~5.5 kg
-
Packaging: Foam-lined box with power adapter, mounting kit, quick-start guide
Warranty & FAQs
Warranty: 1-Year Limited Warranty
FAQs
-
Can it run 24/7? Yes—designed for continuous industrial duty.
-
Is storage expandable? Yes, via optional M.2 slot.
-
Is it splash-proof? Yes—front IP65 resists jets.
Performance, Quality & Reliability
Tested to IPC-Grade 3G (50 G shock, 5 G vibration) and IP65 wash-down standards. Fanless convection cooling extends MTBF beyond 100 000 hrs.
Best Price Guarantee
Found a lower UAE quote? We’ll match it—CESIPC & NEOTECH guarantee top performance at the best value.
Shop Today & UAE Delivery
Order now for insured, next-day delivery to Dubai, Abu Dhabi, Sharjah and all emirates. Secure packaging ensures site-ready arrival.
Customer Reviews & Testimonials
Share your deployment success to help peers choose the right panel PC solution.
After-Sales Support
24/7 remote diagnostics, firmware updates and priority RMA keep your systems running at peak performance.
Get in Touch
For custom configurations or bulk quotes, email sales@neotech.ae. Our specialists are ready to assist.
Stock Availability
Please confirm current stock and lead times before placing urgent or bulk orders.
Disclaimer
All specifications, images and pricing are subject to change without notice. Verify final details with our sales team prior to purchase.
