KS700H fixed 2D kiosk module—360° omni-scan, 640×480 CMOS, USB HID & TTL-UART. Shop at NEOTECH.
Overview
Embed high-speed barcode capture into kiosks and terminals with the KS700H. Its omni-directional mirror head decodes QR, PDF417, Data Matrix & 1D codes at up to 120 scans/sec. Stream data via USB HID or TTL-UART, all in a slim PCB-mount form factor.
Internal Link: Explore our Embedded Scanner Modules.
External Link: Learn barcode standards on the GS1 website.
Product Description
The KS700H packs a 640×480 CMOS sensor and precision mirror array onto a compact PCB (48 × 38 × 18 mm). Snap it flush into your bezel; the module auto-detects USB HID or 115 200 bps TTL-UART. LED aimer and buzzer confirm every read. Ideal for self-service kiosks, ticket dispensers, and bespoke terminals.
Key Features
-
360° omni-directional mirror scan head
-
2D & 1D decoding: QR, PDF417, Data Matrix, UPC/EAN, Code 128
-
High speed: up to 120 scans/sec
-
Interfaces: USB HID & TTL-UART (5 V TTL)
-
Low-profile PCB: 48 × 38 × 18 mm for embedded use
-
Feedback: bright LED aimer + ≥ 85 dB buzzer
-
Power: 5 V DC via USB or header
Specifications
| Parameter |
Details |
| Model |
KS-700H |
| Sensor |
640×480 CMOS |
| Decode Rate |
Up to 120 scans/sec |
| Supported Codes |
1D & 2D (QR, PDF417, Data Matrix) |
| Interfaces |
USB HID, TTL-UART (5 V TTL) |
| PCB Dimensions |
48 × 38 × 18 mm |
| Power |
5 V DC, 200 mA typical |
| Operating Temp. |
0 °C–50 °C |
| Storage Temp. |
–20 °C–70 °C |
| Indicators |
LED aimer, buzzer |
Supported OS / Applications / Industries
-
OS: Any USB HID host (Windows, Linux, Android)
-
Use Cases: Kiosks, ticket machines, POS terminals
-
Industries: Retail, Hospitality, Transportation, Self-service
Benefits & Compatibility
-
Embed-ready PCB fits tight bezel cutouts
-
Dual interfaces for maximum flexibility
-
Angle-free scanning speeds transactions
-
Plug-and-play USB HID for driverless setup
-
Low-power design suits battery-backed units
Purpose of Use
Perfect for self-service kiosks, ticket dispensers, vending machines, and any embedded terminal requiring reliable, hands-free barcode capture.
How to Use
-
Mount PCB module behind bezel with sensor window aligned
-
Connect USB or TTL headers to host
-
Power with 5 V DC
-
Present barcode to mirror head
-
Receive data via HID or UART in your application
Packaging / Weight / Dimensions
-
Includes: KS700H PCB module, USB cable, TTL jumper wires, quick-start guide
-
Module size: 48 × 38 × 18 mm
-
Package weight: ~ 40 g
Warranty & FAQs
-
Warranty: 1 year limited
-
FAQs:
-
Q: Handles curved labels?
A: Yes—omni-mirror head adapts to slight curves.
-
Q: Switch to UART mode?
A: Use jumper per manual; module auto-detects signal.
-
Q: Dust/moisture tolerance?
A: Conformal-coated PCB resists light dust and splashes.
Performance, Quality, Durability & Reliability
Engineered with precision optics and conformal coating, the KS700H achieves MTBF ≥ 30 000 hrs and delivers first-pass reads on worn or low-contrast codes.
