Compact ATP201 58 mm thermal printer mechanism—150 mm/s, 203 dpi, auto-cutter ready. Ideal for kiosks, POS & embedded apps.
Overview
Meet the ATP201, a compact 58 mm direct-thermal print engine built for seamless integration. It pumps out crisp 203 dpi receipts and tickets at up to 150 mm/s, with an optional auto-cutter. Perfect for POS terminals, self-service kiosks, and embedded devices—keeping your workflow smooth and jam-free 24/7.
Product Description
The NEOTECH ATP201 is a high-performance thermal printing mechanism designed to slot into any compact device. Using direct-thermal tech—no ribbons or ink—it accepts standard 58 mm rolls on a 12.7 mm core. A precision stepper motor and optimized paper path deliver ultra-smooth feeds, while the optional cutter module gives you perfect full or partial cuts on demand.
Key Features
-
58 mm print width on 12.7 mm core
-
Up to 150 mm/s high-speed printing
-
Sharp 203 dpi thermal head
-
Auto-cutter ready (full/partial cut)
-
RS232 & USB 2.0 interfaces
-
Jam-resistant paper path design
-
Durable metal chassis
-
MTBF ≥ 20 000 hours
Specifications
| Parameter |
Details |
| Model |
ATP201 |
| Print Width |
58 mm |
| Max Speed |
150 mm/s |
| Resolution |
203 dpi |
| Core Diameter |
12.7 mm |
| Interfaces |
RS232, USB 2.0 |
| Cutter Option |
Full-cut / Partial-cut |
| MTBF |
≥ 20 000 hours |
| Power Input |
5 V DC |
| Operating Temp. |
0 °C–50 °C |
| Dimensions (L×W×H) |
100×80×60 mm |
| Weight |
450 g |
Supported OS / Applications / Industries
-
OS: Windows, Linux, Android (via SDK)
-
Apps: POS firmware, kiosk systems, ticket machines
-
Industries: Retail, Hospitality, Transportation, Vending, Banking
Benefits & Compatibility
-
Plug-and-play embed in any controller board
-
Low upkeep—no ribbons, jam-resistant path
-
High uptime via industrial-grade MTBF
-
Compact footprint for tight spaces
-
Clean cuts for pro-grade receipts & tickets
Purpose of Use
Ideal for embedding in ATMs, self-service kiosks, handheld POS, and any compact device needing reliable 58 mm thermal output.
How to Use
-
Mount ATP201 in device chassis
-
Connect RS232 or USB cable to host board
-
Load 58 mm roll (12.7 mm core)
-
(Optional) Attach cutter module
-
Supply 5 V DC and configure via SDK
-
Run test print; replace cutter blade per schedule
Packaging / Weight / Dimension
-
Includes: ATP201 mechanism, interface cables, mounting screws, user manual
-
Module size: 100×80×60 mm
-
Module weight: 450 g
-
Package weight: ~600 g
Warranty & FAQs
Performance, Quality, Durability & Reliability
Equipped with a precision stepper motor and jam-resistant path, the ATP201 delivers consistent density, smooth feeds, and long-life reliability under heavy use.
Best Price Guarantee
Spotted a cheaper equivalent? NEOTECH will match it—no drama. Shop with confidence.
Shop Today & Receive Your Delivery Across the UAE!
Order ATP201 now for express shipping to Dubai, Abu Dhabi, Sharjah, and beyond. Keep your devices online and efficient.
Request for Customer Reviews & Testimonials
Installed your ATP201? Drop a quick review and let others know how it powers your system.
After-Sales Support
Need integration tips or troubleshooting? Our UAE support team is one call or email away. If remote help doesn’t cut it, we’ll guide you through a smooth RMA.
Get in Touch
For bulk quotes, custom firmware, or SDK access, contact NEOTECH’s engineering crew. We’ve got samples, demos, and pro support ready.
Stock Availability
Confirm real-time stock with our sales team before ordering—lead times may vary for cutter-enabled units.
Disclaimer
Specs, pricing, and availability are subject to change without notice. Images are illustrative; actual mechanism may vary. Verify all details before purchase.
