Overview
The JRP-2RAL24 locks onto edges with a 24 mm laser spot. It senses from 5 mm to 200 mm away in 0.05 ms. Dual analog (0–10 V) and digital outputs make it super flexible. Ideal for print registration, sheet-metal alignment, and robotics.
Product Description
• Laser Spot: 24 mm diameter for precise edge detection
• Range: 5–200 mm with ±0.1 mm repeatability
• Response Time: 0.05 ms for ultra-fast triggering
• Outputs: 0–10 V analog + NPN/PNP digital switch
• Supply: 5–30 V DC @ 10 mA
• Housing: Rugged IP67 metal for dust & splash protection
• Connector: 4-pin M12 quick-disconnect included
• Indicators: Dual-color LED for power & target detect
Mount it, wire power/output, and zero-in on any edge—no calibration fuss.
Key Features
-
Laser Precision: 24 mm spot ensures stable edge pick-up
-
Ultra-Fast: 0.05 ms response for high-speed lines
-
Wide Range: 5–200 mm for varied part sizes
-
Dual Output: 0–10 V analog plus NPN/PNP digital
-
Industrial-Rugged: IP67 metal housing for harsh zones
-
Plug-Play: M12 connector and LED feedback
Specifications
| Spec |
Detail |
| Sensing Mode |
Laser-edge detection |
| Spot Size |
24 mm diameter |
| Range |
5 – 200 mm |
| Repeatability |
±0.1 mm |
| Response Time |
0.05 ms |
| Analog Output |
0–10 V DC |
| Digital Output |
NPN/PNP selectable |
| Supply Voltage |
5–30 V DC |
| Current Draw |
10 mA |
| Housing Rating |
IP67 |
| Connector |
4-pin M12 quick-disconnect |
| Dimensions |
60×30×25 mm (L×W×H) |
| Weight |
~40 g |
| Operating Temp. |
–20 °C to +60 °C |
Supported Platforms & Use Cases
-
Interfaces: PLCs, motion controllers, vision systems
-
Use Cases: Print/web edge detection, sheet alignment, pick-and-place edge find
Benefits & Compatibility
-
Pinpoint Accuracy: Laser spot for repeatable edge detection
-
Lightning-Fast: 0.05 ms response for high-speed production
-
Versatile Outputs: Integrate analog feedback and digital triggers
-
Rugged Build: IP67 for washdown and dusty lines
-
Easy Setup: M12 plug & LED confirm instantly
Purpose of Use
Perfect for registration marks, edge guide in converting, foil tracking, and robotic alignment.
How to Use
-
Mount sensor orthogonal to edge.
-
Wire 5–30 V DC to pins 1/2; output to controller.
-
Select NPN or PNP mode via DIP.
-
Power on; LED glows on edge detect.
-
Tune analog span with onboard potentiometer.
Packaging & Dimensions
-
Includes: JRP-2RAL24 sensor, 2 m M12 cable, mounting clamp, quick-start guide
-
Size: 60×30×25 mm (L×W×H)
-
Weight: ~40 g
