Quad-beam IR sensor kit: 4× emitters, 10–250 mm range, 0.1 ms response, digital NPN/PNP, 3.3–5 V, IP64 housing, M8 cable & bracket included.
Overview
The JRP-2RAQK is a kit featuring a quad-beam reflective IR sensor plus mounting gear. It sees objects 10–250 mm away with ultra-fast 0.1 ms response. Comes with selectable NPN/PNP output, M8 cable, bracket, and quick-start guide—so you’re up and running in minutes.
Product Description
• Quad-Beam IR: Four IR emitters for max noise rejection
• Range: 10–250 mm with ±1 mm accuracy
• Response Time: < 0.1 ms for high-speed detection
• Output: Selectable NPN or PNP digital switch
• Supply: 3.3–5 V DC @ 2 mA
• Housing: Rugged IP64 metal, vibration-proof resin fill
• Connector: 4-pin M8 quick-disconnect cable (included)
• Bundle: Includes sensor, 2 m cable, mounting bracket, guide
Just mount it, plug in power and output, and start detecting reliably.
Key Features
-
Quad-Beam Tech: Rejects ambient light & reflections
-
Ultra-Fast: 0.1 ms response for rapid conveyor tracking
-
Extended Range: 10–250 mm for varied object sizes
-
Selectable Output: NPN or PNP via DIP switch
-
All-Weather: IP64-rated for dusty, damp environments
-
Complete Kit: Cable & bracket included—no extra buys
Specifications
| Spec |
Detail |
| Sensing Mode |
Reflective IR, quad-beam |
| Range |
10–250 mm |
| Accuracy |
± 1 mm |
| Response Time |
< 0.1 ms |
| Supply Voltage |
3.3–5 V DC |
| Current Draw |
2 mA |
| Output |
NPN/PNP digital switch |
| Housing Rating |
IP64 |
| Connector |
4-pin M8 quick-disconnect |
| Kit Includes |
Sensor, 2 m cable, bracket, guide |
| Operating Temp. |
–20 °C to +60 °C |
| Dimensions |
30×20×12 mm (L×W×H) |
| Weight |
~20 g |
Supported Platforms & Use Cases
-
Interfaces: PLCs, microcontrollers (Arduino, Raspberry Pi)
-
Use Cases: Object detection, count & presence, safety gates, light curtains
Benefits & Compatibility
-
Plug-and-Play: M8 cable & bracket let you install fast
-
Fail-Safe: Quad-beam cuts false triggers from dust or glare
-
High-Speed: Blazing 0.1 ms detect for conveyor & robotics
-
Industrial-Grade: IP64 & resin fill for harsh lines
-
Universal Fit: Works with 3.3–5 V logic devices out-of-the-box
Purpose of Use
Perfect for assembly-line part counting, robotic pick-and-place, packaging end-of-line checks, and safety door interlocks.
How to Use
-
Mount sensor using included bracket.
-
Wire VCC to 3.3–5 V, GND, and output to controller.
-
Set NPN/PNP mode with DIP switch.
-
Power on; LED lights on detection.
-
Integrate digital output into your PLC or MCU code.
Packaging & Dimensions
-
Includes: JRP-2RAQK sensor, 2 m M8 cable, bracket, screws, quick-start guide
-
Size: 30×20×12 mm (L×W×H)
-
Weight: ~20 g
Warranty & FAQs
Warranty: 1-year limited.
FAQs:
Performance & Reliability
Built with precision optics and temp-compensated electronics. Rated for 15 million actuation cycles.
