Rugged IP65 fanless capacitive touch panel PC, wide-temp, multi-I/O. Perfect for HMI, automation, AGV control & machine vision.
Overview
The IP65 Fanless Industrial Capacitive Touch Panel PC is built for real-world grit. Its fully sealed front bezel repels dust and water jets, while the fanless design eliminates moving parts and downtime. A vibrant capacitive touchscreen and sturdy aluminum chassis make it ideal for factory floors, outdoor kiosks, AGV controllers, and machine-vision stations—no cap.
Product Description
Level up your edge compute and control with this panel PC:
-
All-Weather Protection: IP65-rated front panel keeps out dust and water
-
Silent Operation: Fanless thermal design runs whisper-quiet under 25 dB
-
Responsive Touch: 5- or 10-point capacitive touch with anti-glare, toughened glass
-
Versatile Compute: Choose Intel® Atom/Celeron or ARM Cortex-A53 CPU options
-
Rich I/O Suite: Gigabit LAN, USB 3.0, RS-232/422/485, HDMI, GPIO for sensors & PLCs
-
Wide Temp Range: Operates from –20 °C to +60 °C without breaking a sweat
-
Flexible OS: Supports Windows 10 IoT, Ubuntu Linux, Yocto, or custom RTOS
Plug in, mount, and run your HMI, SCADA, or vision app seamlessly—vibe intact.
Key Features
-
Display Sizes: 10.1″, 12.1″, 15.6″ IPS (up to 1920×1080)
-
Touch Technology: 5- or 10-point capacitive, anti-glare glass
-
Protection: IP65 front, IP54 full enclosure
-
CPU Options: Intel® Atom x5/Celeron J1900 or ARM Cortex-A53 J6412
-
Memory & Storage: 2–8 GB DDR3/LPDDR4 + 32–128 GB SSD/eMMC
-
I/O Ports: 2× Gigabit LAN, 4× USB 3.0/2.0, 2× RS-232/422/485, HDMI, GPIO
-
Expansion: 1× mini-PCIe slot for 4G/LTE or Wi-Fi
-
Power Input: 12–24 V DC with reverse-polarity protection
-
Operating Temp: –20 °C to +60 °C; Humidity 10 %–90 % RH non-condensing
Specifications
| Spec |
Detail |
| Display |
10.1″ / 12.1″ / 15.6″ IPS, 300–500 nits |
| Touch |
Capacitive multi-touch, anti-glare |
| CPU |
Atom x5 @1.92 GHz, J1900, or J6412 |
| RAM |
2–8 GB DDR3 / LPDDR4 |
| Storage |
32–128 GB SSD or eMMC |
| Front Protection |
IP65 |
| Full Enclosure Rating |
IP54 |
| LAN |
2× Gigabit Ethernet |
| USB |
4× USB 3.0 / USB 2.0 |
| Serial |
2× RS-232/422/485 |
| Video Out |
HDMI / optional DisplayPort |
| GPIO |
8-bit digital I/O |
| Expansion |
mini-PCIe slot |
| Power |
12–24 V DC |
| Temp Range |
–20 °C to +60 °C |
| Humidity |
10 %–90 % RH non-condensing |
| Mounting |
Panel or VESA 75×75 mm |
| Dimensions (W×H×D) |
e.g. 380×240×45 mm (15.6″ model) |
| Weight |
~2.5 kg |
Supported OS / Applications / Industries
-
OS: Windows 10 IoT, Ubuntu Linux, Yocto, custom RTOS
-
Applications: HMI/SCADA, AGV control, machine vision, data logging
-
Industries: Manufacturing, logistics, transportation, outdoor kiosks
Benefits & Compatibility
-
Zero Maintenance: Fanless, sealed design avoids dust clogs
-
High Reliability: Vibration- and shock-tested for industrial use
-
Edge-Ready: GPIO and serial ports for legacy equipment
-
Scalable Performance: Choose CPU, RAM, and storage to match your workload
-
Easy Integration: Standard I/O and mounting options for any setup
Purpose of Use
Engineered for mission-critical tasks—drive AGV fleets, inspect parts with machine vision, or run HMI panels in dust- and water-prone areas. Delivers stable performance where others bail.
How to Use
-
Cut & Mount: Create panel cut-out per template and secure with included brackets.
-
Connect Power & I/O: Link 12–24 V DC, Ethernet, USB, serial, and GPIO devices.
-
Install OS & Apps: Load Windows IoT, Linux, or RTOS via USB or network.
-
Calibrate Touch: Adjust multi-touch settings in software.
-
Deploy: Launch your control, vision, or data-logging application.
Packaging / Weight / Dimensions
-
Packaging: Foam-lined industrial box with shock absorption
-
Unit Weight: ~2.5 kg
-
Box Size: ~360×280×120 mm
-
Includes: Panel brackets, power cable, quick-start guide
Warranty and FAQs
Warranty: One-year limited warranty; extended plans available.
FAQs
Performance, Quality, Durability & Reliability
Built with industrial-grade components, conformal coating, and tested to MIL-STD-810G for vibration and shock. Runs nonstop in –20 °C to +60 °C—no cap.
Best Price Guarantee
Spotted a lower quote on an IP65 fanless panel PC? We’ll match it—no cap. Shop with confidence at NEOTECH.
Shop Today & Receive Your Delivery Across the UAE!
Order now for fast, tracked delivery across Dubai, Abu Dhabi, Sharjah, and beyond. We pack, ship, and track—hassle-free.
Request for Customer Reviews and Testimonials
Tried this panel PC? Drop a review and share your vibes. Your feedback helps everyone choose right.
After Sales Support
Our support squad is on call 24/7 for firmware updates, remote diagnostics, and integration help via chat or email.
Get in Touch
For custom builds, bulk quotes, or technical deep dives, email sales@neotech.ae or call +971 4 123 4567. We reply within one business hour.
Stock Availability
In stock now—confirm quantities before ordering. For urgent deployments, ask about our express restock service.
Disclaimer
All specs, images, and pricing are for reference only and may change without notice. Confirm details with NEOTECH before purchase. Images are illustrative only.
