Rugged IP65 capacitive touch panel PC, fanless design, wide-temp range, versatile I/O. Ideal for HMI, automation, and harsh environments.
Overview
The IP65 Fanless Industrial Touch Panel PC is built for real-world grit. Fully sealed against dust and water (IP65), its fanless thermal design means zero moving parts and zero downtime. A high-brightness capacitive touchscreen and tough aluminum chassis make it perfect for factory floors, outdoor kiosks, or any environment that’s lowkey brutal.
Product Description
Level up your control systems with this industrial-grade panel PC:
-
All-Weather Ready: IP65 front bezel shields against dust and water jets
-
Silent & Cool: Fanless design keeps noise under 25 dB and avoids dust clogs
-
Capacitive Touch: 5- or 10-point multi-touch with anti-glare toughened glass
-
Edge Compute: Intel® Atom or ARM based CPU options handle HMI, SCADA, and vision tasks
-
Versatile I/O: Multiple LAN, USB, serial, HDMI, and GPIO for sensors, cameras, and PLCs
-
Wide Temp Range: Operates from –20 °C to +60 °C without breaking a sweat
Plug it into your AGV controllers, machine vision rigs, or logistics terminals—no cap, it just works.
Key Features
-
Display: 10″–15.6″ IPS, 300–500 nits
-
Touch: 5- or 10-point capacitive, anti-glare glass
-
Protection: IP65 front / IP54 full enclosure
-
CPUs: Intel® Atom x5 / Celeron J1900 or ARM Cortex-A53 J6412
-
Memory/Storage: Up to 8 GB DDR3/LPDDR4 + 128 GB SSD/eMMC
-
I/O: 2× LAN, 4× USB, 2× RS-232/422/485, HDMI, GPIO
-
Expansion: Mini-PCIe slot for 4G/LTE or Wi-Fi modules
-
Power: 12–24 V DC wide-range input
Specifications
| Specification |
Detail |
| Display Size |
10.1″, 12.1″, 15.6″ |
| Resolution |
Up to 1920×1080 |
| Brightness |
300–500 nits |
| Touch Tech |
Capacitive multi-touch |
| Enclosure Rating |
IP65 front, IP54 rear |
| CPU Options |
Atom x5 (1.92 GHz), J1900, J6412 |
| RAM |
2–8 GB DDR3/LPDDR4 |
| Storage |
32–128 GB SSD or eMMC |
| LAN |
2× Gigabit Ethernet |
| USB Ports |
4× USB 3.0 / USB 2.0 |
| Serial Ports |
2× RS-232/422/485 |
| Video Output |
HDMI / optional DisplayPort |
| GPIO |
8-bit digital I/O |
| Expansion Slot |
1× Mini-PCIe |
| Power Input |
12–24 V DC, reverse polarity protected |
| Operating Temp |
–20 °C to +60 °C |
| Humidity |
10 %–90 % RH non-condensing |
| Mounting |
Panel-mount or VESA 75×75 mm |
| Dimensions (W×H×D) |
Varies by size, e.g. 380×240×45 mm (15.6″) |
| Weight |
~2.5 kg |
Supported OS / Applications / Industries
-
OS: Windows 10 IoT, Ubuntu Linux, Yocto, custom RTOS
-
Apps: HMI/SCADA, AGV control, machine vision, data logging
-
Industries: Manufacturing, logistics, transportation, outdoor kiosks
Benefits & Compatibility
-
Zero Maintenance: Fanless, sealed design avoids dust and water issues
-
High Reliability: Wide-temp and vibration-tested for heavy-duty use
-
Seamless Integration: Standard I/O covers legacy PLCs and modern sensors
-
Scalable Performance: CPU and memory options match your workload
-
Flexible Mounting: Panel or VESA mount for any setup
Purpose of Use
Engineered for mission-critical tasks: controlling AGVs, visual inspection, data acquisition, or remote HMI panels in dust- or splash-prone areas. Delivers stable performance where others bail.
How to Use
-
Cut & Mount: Create panel cutout per template; secure with brackets.
-
Connect Power & I/O: Hook up 12–24 V DC, Ethernet, USB, serial, and GPIO.
-
Install OS & Software: Load Windows IoT, Linux, or custom runtime.
-
Calibrate Touch: Configure multi-touch settings in OS.
-
Deploy: Launch your HMI, vision, or control app and go live.
Packaging / Weight / Dimensions
-
Packaging: Industrial-grade foam-lined box with shock absorption
-
Unit Weight: ~2.5 kg
-
Box Dimensions: ~360×280×120 mm
-
Includes: Panel brackets, power cable, quick-start guide
Warranty and FAQs
Warranty: One-year limited warranty; extended plans available.
FAQs
Performance, Quality, Durability & Reliability
Built with industrial-grade caps and conformal coating. Vibration-tested per MIL-STD-810G and shock-tested to 10 g. Operates nonstop in –20 °C to +60 °C—no cap.
Best Price Guarantee
Spotted a better deal on an IP65 fanless HMI panel? We’ll match it—no cap. Shop confidently at NEOTECH.
Shop Today & Receive Your Delivery Across the UAE!
Order now for fast, tracked delivery across Dubai, Abu Dhabi, Sharjah and beyond. We pack, ship, and track—hassle-free.
Request for Customer Reviews and Testimonials
Tried this panel PC? Drop a review and share your vibes. Your feedback helps everyone choose right.
After Sales Support
Our support squad is on call 24/7 for firmware updates, remote diagnostics, and integration help. Hit us up via chat or email anytime.
Get in Touch
For custom builds, bulk quotes, or tech deep dives, email sales@neotech.ae or call +971 4 123 4567. We reply within one business hour.
Stock Availability
In stock now—confirm quantities before ordering. For urgent deployments, ask about our express restock service.
Disclaimer
All specs, images, and pricing are for reference and may change without notice. Confirm details with NEOTECH before purchase. Images are illustrative only.
