2U rack: dual Xeon CPUs, 12×3.5″ HDD bays, 4 NVMe boot bays, 32 DDR4 slots (2 TB), PCIe Gen4, redundant PSUs, BMC remote mgmt.
Overview
The FusionServer 1288H V7 packs balanced compute and storage into a 2U chassis. It houses dual Intel® Xeon® Scalable CPUs, up to 2 TB DDR4, 12 hot-swap 3.5″ bays plus four front NVMe slots. Rock-solid for file serving, virtualization, and database roles.
Product Description
This server dominates data workloads with:
-
CPUs: 2× Intel® Xeon® Scalable (3rd Gen) up to 28 cores each
-
Memory: 32× DDR4-3200 DIMMs, up to 2 TB
-
HDD Bays: 12× hot-swap 3.5″ (SATA/SAS)
-
NVMe Bays: 4× front M.2 NVMe for OS & cache
-
Expansion: 3× PCIe Gen4 ×16 slots for NICs/HBAs
-
Power: Dual 1200 W Platinum PSUs, N+1 redundant
-
Cooling: Hot-swap high-flow fans optimized for drives
-
Mgmt & Security: BMC IPMI/Web UI, TPM 2.0, chassis intrusion alert
Key Features
-
Moderate Density: 12 HDD + 4 NVMe in 2U
-
Dual Xeon CPUs: Strong compute headroom
-
2 TB DDR4: Large in-memory caches & VMs
-
PCIe Gen4: Next-gen I/O lanes
-
Redundant PSUs & Fans: Zero-downtime serviceability
-
Remote BMC: Out-of-band firmware and health mgmt
Specifications
| Spec |
Detail |
| Form Factor |
2U rack |
| Processors |
2× Intel® Xeon® Scalable (3rd Gen) |
| Memory |
32× DDR4-3200 DIMMs (2 TB max) |
| 3.5″ Drive Bays |
12× hot-swap (SATA/SAS) |
| M.2 NVMe Bays |
4× front M.2 NVMe |
| PCIe Expansion |
3× PCIe Gen4 ×16 |
| Network |
1× 1 GbE BMC + optional OCP for 10/25 GbE NICs |
| Power Supplies |
2× 1200 W Platinum (1+1 redundant) |
| Cooling |
Hot-swap high-flow fans |
| Security |
TPM 2.0; chassis intrusion detection |
| Management |
BMC IPMI / Web UI / CLI |
| Dimensions (W×H×D) |
438 × 88.5 × 766 mm |
| Weight |
~32 kg |
Supported OS / Applications / Industries
-
OS: Windows Server, VMware ESXi, RHEL, SUSE, Ubuntu
-
Apps: File/print, SQL/NoSQL DB, virtualization, backup/archiving
-
Industries: Enterprise storage, finance, healthcare, telecom
Benefits & Compatibility
-
Balanced Storage: 12 bays + NVMe boot in 2U saves rack space
-
Compute Power: Dual Xeons handle mixed workloads
-
Future-Ready I/O: PCIe Gen4 for latest add-ins
-
Always-On: Redundant PSUs/fans & enterprise RAS
-
Easy Management: BMC remote firmware, BIOS, health checks
Purpose of Use
Perfect for mid-tier SAN/NAS, file-share clusters, VM hosts, and database servers requiring both capacity and compute.
How to Use
-
Rack-mount the chassis.
-
Populate CPUs, memory, drives, and NVMe modules per guide.
-
Connect power, network, and BMC LAN.
-
Configure RAID, BIOS, and firmware via BMC UI.
-
Deploy your OS or hypervisor and go live.
Packaging / Weight / Dimensions
-
Dimensions: 438 × 88.5 × 766 mm (2U)
-
Weight: ~32 kg (fully loaded)
-
Includes: Chassis, drive trays, PSUs, rail kit, quick-start guide
Warranty & FAQs
Warranty: 3 years next-business-day support.
FAQs:
-
Q: Can I mix HDD & NVMe?
A: Yes—use HDD bays for bulk data, NVMe for OS/cache.
-
Q: Which RAID levels?
A: Software RAID or optional hardware HBA supports 0/1/5/6/10.
Performance & Reliability
Enterprise-grade parts, proactive health alerts, and optimized airflow. Hot-swap modules ensure 24/7 uptime.
