Reflective IR sensor: 5–150 mm range, 0.2 ms response, 0–10 V analog output, 5–30 V DC, IP65 housing, M12 connector—ideal for fast object detection.
Overview
The JRP-2RAK is a rugged reflective infrared sensor with analog output. It senses objects from 5 mm to 150 mm with ±0.2 mm repeatability and 0.2 ms response. Perfect for conveyor monitoring, fill-level checks, and part-presence detection.
Product Description
• Reflective IR: Single-beam emitter/receiver for simple target detection
• Range: 5–150 mm, adjustable with teach-in potentiometer
• Repeatability: ±0.2 mm for precise sensing
• Response Time: 0.2 ms for high-speed lines
• Output: 0–10 V analog proportional signal
• Supply: 5–30 V DC @ 15 mA
• Housing: IP65 UV-stable plastic, resistant to dust/splashes
• Connector: 4-pin M12 quick-disconnect (cable included)
• Indicator: Bicolor LED for power & teach-in feedback
Mount it, wire power and analog output, teach target—then watch your PLC read precise distances.
Key Features
-
Wide Detection: 5–150 mm for varied object sizes
-
Fast Response: 0.2 ms for real-time control
-
Analog Output: 0–10 V for proportional distance info
-
Easy Setup: Onboard teach-in button & LED feedback
-
Rugged Build: IP65 housing for industrial floors
-
Plug-and-Play: M12 connector with 2 m cable included
Specifications
| Spec |
Detail |
| Sensing Mode |
Reflective IR |
| Range |
5 – 150 mm |
| Repeatability |
±0.2 mm |
| Response Time |
0.2 ms |
| Output |
0–10 V analog |
| Supply Voltage |
5–30 V DC |
| Current Draw |
15 mA |
| Housing Rating |
IP65 |
| Connector |
4-pin M12 |
| Teach-In |
Onboard button & LED |
| Dimensions |
40×20×12 mm (L×W×H) |
| Weight |
~25 g |
| Operating Temp. |
–20 °C to +60 °C |
Supported Platforms & Use Cases
-
Interfaces: PLC analog inputs, DAQ modules, microcontrollers
-
Use Cases: Conveyor part detection, fluid level sensing, label registration
Benefits & Compatibility
-
Proportional Data: 0–10 V output gives true distance measurement
-
Quick Teach-In: One-touch setup with LED confirmation
-
Industrial-Grade: IP65 protects against dust and spray
-
Fast & Accurate: 0.2 ms response for precise timing
-
Universal Fit: 5–30 V for broad control systems
Purpose of Use
Ideal for inline quality control, packaging verification, and fill-height monitoring in factories.
How to Use
-
Mount sensor facing target surface.
-
Wire VCC (5–30 V), GND, and analog output to your controller.
-
Teach near and far points via onboard button (LED guides).
-
Power on; monitor 0–10 V signal for distance measurement.
-
Integrate analog reading into PLC or SCADA loops.
Packaging & Dimensions
-
Includes: JRP-2RAK sensor, 2 m M12 cable, mounting bracket, quick-start guide
-
Size: 40×20×12 mm (L×W×H)
-
Weight: ~25 g
Warranty & FAQs
Warranty: 1-year limited.
FAQs:
Performance & Reliability
Temperature-compensated optics and electronics ensure stable readings across –20 °C to +60 °C. Rated for 10 million cycles.
Best Price Guarantee
Spotted a lower price? Show proof—we’ll match it—anywhere in the UAE.
Shop Now & UAE Delivery
Order today for fast, tracked shipping to Dubai, Abu Dhabi, Sharjah, and all Emirates.
Customer Reviews & Testimonials
Using the JRP-2RAK? Share your success story and get featured on our site!
After-Sales Support
24/7 expert support via chat, email, or phone. From wiring tips to signal tuning—we’ve got you.
Get in Touch
Need bulk quotes, custom cables, or advanced calibration? Hit us up via live chat, email, or phone. We’re here 🤙.
Stock Availability
High-volume demand—stock moves fast. Contact us to confirm availability before ordering.
Disclaimer
All specs subject to change without notice. Images are illustrative. Verify details with your sales rep before purchase.
